8XL196NP

型号：

8XL196NP

描述：

商业CHMOS 16位微控制器[ COMMERCIAL CHMOS 16-BIT MICROCONTROLLER ]

品牌：

INTEL[ INTEL ]

页数：

34 页

PDF大小：

532 K

下载PDF手册
8XL196NP COMMERCIAL
CHMOS 16-BIT MICROCONTROLLER
n 14 MHz Operation at 2.7–3.3 Volts
n Chip-select Unit
— 6 Chip Select Pins
n 1 Mbyte of Linear Address Space
n Optional 4 Kbytes of ROM
n 1000 Bytes of Register RAM
n Register-register Architecture
n 32 I/O Port Pins
— Dynamic Demultiplexed/Multi-
plexed Address/Data Bus for Each
Chip Select
— Programmable Wait States (0, 1, 2,
or 3) for Each Chip Select
— Programmable Bus Width (8- or 16-
bit) for Each Chip Select
n 16 Prioritized Interrupt Sources
n 4 External Interrupt Pins and NMI Pin
— Programmable Address Range for
Each Chip Select
n 2.0µs 16 × 16 Unsigned Multiplication
n 3.4µs 32/16 Unsigned Division
n 2 Flexible 16-bit Timer/Counters with
Quadrature Counting Capability
n 3 Pulse-width Modulator (PWM) Outputs
n 100-pin SQFP or 100-pin QFP Package
with High Drive Capability
n Complete System Development
n Full-duplex Serial Port with Dedicated
Support
Baud-rate Generator
n High-speed CHMOS Technology
n Peripheral Transaction Server
n Event Processor Array (EPA) with 4 High-
speed Capture/Compare Channels
®
The 8XL196NP is a member of Intel’s 16-bit MCS 96 microcontroller family. The device features 1 Mbyte of
linear address space, a demultiplexed bus, and a chip-select unit. The external bus can dynamically switch
between multiplexed and demultiplexed operation. When operating at 14 MHz in demultiplexed mode, the
8XL196NP can access a 200 ns memory device with zero wait states. The 8XL196NP is available without
ROM (80L196NP) or with 4 Kbytes of ROM (83L196NP).
Information in this document is provided solely to enable use of Intel products. Intel assumes no liability whatsoever, including infringe-
ment of any patent or copyright, for sale and use of Intel products except as provided in Intel’s Terms and Conditions of Sale for such
products. Information contained herein supersedes previously published specifications on these devices from Intel.
© INTEL CORPORATION, 1996
March 1996
Order Number: 272824-001
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
16
CPU
4K Bytes
ROM (optional)
1000
RALU
Interrupt
Controller
Byte
Register
File
Chip Select
CS5:0#
Memory Controller
with
Peripheral
Transaction
Server
Microcode
Engine
24 Bytes
CPU SFRs
Chip Select
Control
Signals
Queue
8
A19:16/
EPORT3:0
16
A15:0
Pulse
Width
Modulator
Baud
Rate
Gen
Serial
Port
Timer 1
Timer 2
Event
Processor
Array
AD15:0
Port
3
Port
4
Port 1
Port 2
Port 3/
EXTINT3:2 PWM2:0
Port 4/
Port 1/
Port 2/
Hold Control,
SIO,
EPA3:0,
Timer 1,
Timer 2
EXTINT1:0
A2351-01
Figure 1. 8XL196NP Block Diagram
2
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
1.0 NOMENCLATURE OVERVIEW
X
XX
8
X
X
XXXXX XX
A2815-01
Figure 2. 8XL196NP Family Nomenclature
Table 1. Description of Product Nomenclature
Parameter
Options
Description
Temperature and Burn-in Options
no mark
Commercial operating temperature range (0°C to 70°C)
with Intel standard burn-in.
Packaging Options
S
QFP
SB
SQFP
Program–memory Options
0
3
No ROM
ROM
Process Information
Product Family
Device Speed
L
Low Voltage CHMOS
196NP
no mark
14 MHz
3
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
2.0 PINOUT
V
AD0
NC
RESET#
NMI
1
2
3
4
5
6
7
8
80
79
78
77
76
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
SS
A18 / EPORT.2
A19 / EPORT.3
WR# / WRL#
RD#
BHE# / WRH#
ALE
INST
READY
RPD
ONCE
V
V
V
A8
A9
EA#
A0
A1
V
CC
V
9
SS
A2
A3
A4
A5
A6
A7
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
SS
S8XL196NP
CC
SS
V
CC
V
A10
A11
A12
A13
A14
A15
SS
NC
P3.0 / CS0#
P3.1 / CS1#
P3.2 / CS2#
P3.3 / CS3#
View of component as
mounted on PC board
V
V
SS
SS
P3.4 / CS4#
P3.5 / CS5#
P3.6 / EXTINT2
NC
XTAL1
XTAL2
V
P2.7 / CLKOUT
NC
P2.6 / HLDA#
P2.5 / HOLD#
SS
P3.7 / EXTINT3
P1.0 / EPA0
V
CC
A4318-01
Figure 3. 8XL196NP 100-pin SQFP Package
4
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
Table 2. 8XL196NP 100-pin SQFP Pin Assignment
Pin
1
Name
RESET#
Pin
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Name
EXTINT3/P3.7
EPA0/P1.0
VCC
Pin
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
Name
Pin
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
Name
WR#/WRL#
EPORT.3/A19
EPORT.2/A18
VSS
CLKOUT/P2.7
†
2
NMI
EA#
A0
NC
3
VSS
4
EPA1/P1.1
EPA2/P1.2
EPA3/P1.3
T1CLK/P1.4
T1DIR/P1.5
VCC
XTAL2
XTAL1
VSS
5
A1
VCC
6
VCC
VSS
A2
EPORT.1/A17
EPORT.0/A16
AD15
†
7
NC
8
A15
9
A3
A14
AD14
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
A4
T2CLK/P1.6
VSS
A13
AD13
A5
A12
AD12
A6
T2DIR/P1.7
PWM0/P4.0
PWM1/P4.1
PWM2/P4.2
P4.3
A11
AD11
A7
A10
AD10
VCC
VSS
A9
AD9
A8
VSS
†
NC
VSS
AD8
†
NC
VCC
VCC
VCC
CS0#/P3.0
CS1#/P3.1
CS2#/P3.2
CS3#/P3.3
VSS
VSS
VSS
AD7
TXD/P2.0
RXD/P2.1
EXTINT0/P2.2
BREQ#/P2.3
EXTINT1/P2.4
HOLD#/P2.5
HLDA#/P2.6
ONCE
RPD
READY
INST
ALE
AD6
AD5
AD4
AD3
CS4#/P3.4
CS5#/P3.5
EXTINT2/P3.6
AD2
BHE#/WRH#
RD#
AD1
100 AD0
†
To be compatible with future versions of the Nx family, tie the no connection (NC) pins as follows:
Pin 57 = VSS, Pin 16 = VCC, Pin 17 = VSS (5 volts on this pin will enable a clock doubler on future
devices), and Pin 52 = VCC
.
5
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
Table 3. 100-pin SQFP Pin Assignment Arranged by Functional Categories
Address & Data
Name Pin
Address & Data (cont)
Input/Output
Name
Power & Ground
Name
Pin
85
Pin
18
19
20
21
23
24
27
29
30
31
82
81
78
77
46
47
48
49
50
51
25
26
41
38
39
40
45
32
33
35
37
44
Name
Pin
A0
4
5
AD13
AD14
AD15
CS0#/P3.0
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
6
A1
84
CS1#/P3.1
CS2#/P3.2
CS3#/P3.3
CS4#/P3.4
CS5#/P3.5
EPA0/P1.0
EPA1/P1.1
EPA2/P1.2
EPA3/P1.3
EPORT.0
EPORT.1
EPORT.2
EPORT.3
P2.2
14
28
34
42
67
80
92
7
A2
8
83
A3
9
A4
10
11
12
13
65
64
63
62
61
60
59
58
82
81
78
77
100
99
98
97
96
95
94
93
91
89
88
87
86
Bus Control & Status
A5
Name
Pin
73
74
47
49
50
72
75
71
76
A6
ALE
A7
BHE#/WRH#
BREQ#
HOLD#
HLDA#
A8
A9
15
22
36
43
53
56
66
68
79
90
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
AD0
AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8
AD9
INST
RD#
READY
WR#/WRL#
P2.3
Processor Control
Name Pin
CLKOUT
P2.4
P2.5
51
3
P2.6
EA#
P2.7
EXTINT0
EXTINT1
EXTINT2
EXTINT3
NMI
46
48
25
26
2
P3.6
No Connection
Name
P3.7
Pin
16
17
52
57
P4.3
NC
NC
NC
NC
PWM0/P4.0
PWM1/P4.1
PWM2/P4.2
RXD/P2.1
T1CLK/P1.4
T1DIR/P1.5
T2CLK/P1.6
T2DIR/P1.7
TXD/P2.0
ONCE
69
1
RESET#
RPD
70
55
54
XTAL1
XTAL2
AD10
AD11
AD12
6
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
RESET#
NMI
EA#
A0
1
2
3
4
5
6
7
8
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
RD#
BHE# / WRH#
ALE
INST
READY
RPD
A1
V
CC
V
ONCE
SS
V
V
V
A2
A3
A4
A5
A6
A7
SS
9
CC
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
SB8XL196NP
SS
A8
A9
A10
A11
A12
A13
A14
A15
NC
V
CC
V
SS
NC
NC
View of component as
mounted on PC board
P3.0 / CS0#
P3.1 / CS1#
P3.2 / CS2#
P3.3 / CS3#
V
SS
XTAL1
XTAL2
V
SS
V
P3.4 / CS4#
P3.5 / CS5#
P3.6 / EXTINT2
SS
NC
P2.7 / CLKOUT
A4317-01
Figure 4. 8XL196NP 100-pin QFP Package
7
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
Table 4. 8XL196NP 100-pin QFP Pin Assignment
Pin
1
Name
Pin
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Name
EXTINT2/P3.6
No Connection
EXTINT3/P3.7
EPA0/P1.0
VCC
Pin
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
Name
HOLD#/P2.5
HLDA#/P2.6
No Connection
CLKOUT/P2.7
VSS
Pin
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
Name
AD0
RD#
2
No Connection
WR#/WRL#
EPORT.3/A19
EPORT.2/A18
VSS
3
RESET#
4
NMI
5
EA#
6
A0
EPA1/P1.1
EPA2/P1.2
EPA3/P1.3
T1CLK/P1.4
T1DIR/P1.5
VCC
XTAL2
XTAL1
VSS
VCC
7
A1
EPORT.1/A17
EPORT.0/A16
AD15
8
VCC
9
VSS
A15
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
A2
A14
AD14
A3
A13
AD13
A4
T2CLK/P1.6
VSS
A12
AD12
A5
A11
AD11
A6
T2DIR/P1.7
PWM0/P4.0
PWM1/P4.1
PWM2/P4.2
P4.3
A10
AD10
A7
A9
AD9
VCC
A8
VSS
VSS
VSS
AD8
No Connection
CS0#/P3.0
CS1#/P3.1
CS2#/P3.2
CS3#/P3.3
VSS
VCC
VCC
VCC
VSS
AD7
VSS
ONCE
RPD
AD6
TXD/P2.0
RXD/P2.1
EXTINT0/P2.2
BREQ#/P2.3
EXTINT1/P2.4
AD5
READY
INST
AD4
AD3
CS4#/P3.4
CS5#/P3.5
ALE
AD2
BHE#/WRH#
100 AD1
8
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
Table 5. 100-pin QFP Pin Assignment Arranged by Functional Categories
Address & Data
Name Pin
Address & Data (cont)
Input/Output
Name
Power & Ground
Name
Pin
86
Pin
19
20
21
22
24
25
29
31
32
33
83
82
79
78
48
49
50
51
52
54
26
28
43
40
41
42
47
34
35
37
39
46
Name
Pin
A0
6
7
AD13
AD14
AD15
CS0#/P3.0
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
8
A1
85
CS1#/P3.1
CS2#/P3.2
CS3#/P3.3
CS4#/P3.4
CS5#/P3.5
EPA0/P1.0
EPA1/P1.1
EPA2/P1.2
EPA3/P1.3
EPORT.0
EPORT.1
EPORT.2
EPORT.3
P2.2
16
30
36
44
68
81
93
9
A2
10
11
12
13
14
15
66
65
64
63
62
61
60
59
83
82
79
78
1
84
A3
A4
Bus Control & Status
A5
Name
Pin
74
75
49
51
52
73
76
72
77
A6
ALE
A7
BHE#/WRH#
BREQ#
HOLD#
HLDA#
A8
A9
17
23
38
45
55
58
67
69
80
91
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
AD0
AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8
AD9
INST
RD#
READY
WR#/WRL#
P2.3
Processor Control
Name Pin
CLKOUT
P2.4
P2.5
54
5
P2.6
EA#
P2.7
EXTINT0
EXTINT1
EXTINT2
EXTINT3
NMI
48
50
26
28
4
P3.6
No Connection
Name
100
99
98
97
96
95
94
92
90
89
88
87
P3.7
Pin
2
P4.3
NC
NC
NC
NC
PWM0/P4.0
PWM1/P4.1
PWM2/P4.2
RXD/P2.1
T1CLK/P1.4
T1DIR/P1.5
T2CLK/P1.6
T2DIR/P1.7
TXD/P2.0
18
27
53
ONCE
70
3
RESET#
RPD
71
57
56
XTAL1
XTAL2
AD10
AD11
AD12
9
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
3.0 SIGNALS
Table 6. Signal Descriptions
Name
A15:0
Type
Description
I/O
System Address Bus
These address pins provide address bits 0–15 during the entire external memory
cycle during both multiplexed and demultiplexed bus modes.
A19:16
I/O
Address Pins 16–19
These address pins provide address bits 16–19 during the entire external memory
cycle during both multiplexed and demultiplexed bus modes, supporting extended
addressing of the 1-Mbyte address space.
NOTE: Internally, there are 24 address bits; however, only 20 external address
pins (A19:0) are implemented. The internal address space is 16 Mbytes
(000000–FFFFFFH) and the external address space is 1 Mbyte (00000–
FFFFFH). The microcontroller resets to FF2080H in internal memory or
F2080H in external memory.
A19:16 share package pins with EPORT.3:0.
AD15:0
I/O
Address/Data Lines
The function of these pins depends on the bus width and mode.
16-bit Multiplexed Bus Mode:
AD15:0 drive address bits 0–15 during the first half of the bus cycle and drive or
receive data during the second half of the bus cycle.
8-bit Multiplexed Bus Mode:
AD15:8 drive address bits 8–15 during the entire bus cycle. AD7:0 drive address
bits 0–7 during the first half of the bus cycle and drive or receive data during the
second half of the bus cycle.
16-bit Demultiplexed Mode:
AD15:0 drive or receive data during the entire bus cycle.
8-bit Demultiplexed Mode:
AD7:0 drive or receive data during the entire bus cycle. AD15:8 drive the data that
is currently on the high byte of the internal bus.
ALE
O
Address Latch Enable
This active-high output signal is asserted only during external memory cycles. ALE
signals the start of an external bus cycle and indicates that valid address
information is available on the system address/data bus (A19:16 and AD15:0 for a
multiplexed bus; A19:0 for a demultiplexed bus).
An external latch can use this signal to demultiplex address bits 0–15 from the
address/data bus in multiplexed mode.
10
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
Table 6. Signal Descriptions (Continued)
Name
BHE#
Type
Description
†
O
Byte High Enable
During 16-bit bus cycles, this active-low output signal is asserted for word and high-
byte reads and writes to external memory. BHE# indicates that valid data is being
transferred over the upper half of the system data bus. Use BHE#, in conjunction
with address bit 0 (A0 for a demultiplexed address bus, AD0 for a multiplexed
address/data bus), to determine which memory byte is being transferred over the
system bus:
BHE#
AD0 or A0 Byte(s) Accessed
0
0
1
0
1
0
both bytes
high byte only
low byte only
BHE# shares a package pin with WRH#.
†
When this pin is configured as a special-function signal (P5_MODE.5 = 1), the
chip configuration register 0 (CCR0) determines whether it functions as BHE# or
WRH#. CCR0.2 = 1 selects BHE#; CCR0.2 = 0 selects WRH#.
BREQ#
O
Bus Request
This active-low output signal is asserted during a hold cycle when the bus controller
has a pending external memory cycle. When the bus-hold protocol is enabled
(WSR.7 is set), the P2.3/BREQ# pin can function only as BREQ#, regardless of the
configuration selected through the port configuration registers (P2_MODE,
P2_DIR, and P2_REG). An attempt to change the pin configuration is ignored until
the bus-hold protocol is disabled (WSR.7 is cleared).
The microcontroller can assert BREQ# at the same time as or after it asserts
HLDA#. Once it is asserted, BREQ# remains asserted until HOLD# is deasserted.
BREQ# shares a package pin with P2.4.
Clock Output
CLKOUT
O
Output of the internal clock generator. The CLKOUT frequency is ½ the internal
operating frequency (f). CLKOUT has a 50% duty cycle.
CLKOUT shares a package pin with P2.7.
Chip-select Lines 0–5
CS5#:0
O
The active-low output CSx# is asserted during an external memory cycle when the
address to be accessed is in the range programmed for chip select x. If the external
memory address is outside the range assigned to the six chip selects, no chip-
select output is asserted and the bus configuration defaults to the CS5# values.
Immediately following reset, CS0# is automatically assigned to the range FF2000–
FF20FFH (F2000–F20FFH if external).
CS5:0# share package pins with P3.5:0.
11
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
Table 6. Signal Descriptions (Continued)
Name
EA#
Type
Description
I
External Access
This input determines whether memory accesses to special-purpose and program
memory partitions (FF2000–FF2FFFH) are directed to internal or external memory.
These accesses are directed to internal memory if EA# is held high and to external
memory if EA# is held low. For an access to any other memory location, the value
of EA# is irrelevant.
EA# is not latched and can be switched dynamically during normal operating mode.
Be sure to thoroughly consider the issues, such as different access times for
internal and external memory, before using this dynamic switching capability.
Always connect EA# to VSS when using a microcontroller that has no internal
nonvolatile memory.
EPA3:0
I/O
I/O
I
Event Processor Array (EPA) Capture/Compare Channels
High-speed input/output signals for the EPA capture/compare channels.
EPA3:0 share package pins with P1.3:0.
EPORT.3:0
Extended Addressing Port
This is a 4-bit, bidirectional, memory-mapped port.
EPORT.3:0 share package pins with A.19:16.
EXTINT0
EXTINT1
EXTINT2
EXTINT3
External Interrupts
In normal operating mode, a rising edge on EXTINTx sets the EXTINTx interrupt
pending bit. EXTINTx is sampled during phase 2 (CLKOUT high). The minimum
high time is one state time.
In standby and powerdown modes, asserting the EXTINTx signal for at least 50 ns
causes the device to resume normal operation. The interrupt does not need to be
enabled, but the pin must be configured as a special-function input. If the EXTINTx
interrupt is enabled, the CPU executes the interrupt service routine. Otherwise, the
CPU executes the instruction that immediately follows the command that invoked
the power-saving mode.
In idle mode, asserting any enabled interrupt causes the device to resume normal
operation.
EXTINT0 shares a package pin with P2.2, EXTINT1 shares a package pin with
P2.4, EXTINT2 shares a package pin with P3.6, and EXTINT3 shares a package
pin with P3.7.
HLDA#
O
Bus Hold Acknowledge
This active-low output indicates that the CPU has released the bus as the result of
an external device asserting HOLD#. When the bus-hold protocol is enabled
(WSR.7 is set), the P2.6/HLDA# pin can function only as HLDA#, regardless of the
configuration selected through the port configuration registers (P2_MODE,
P2_DIR, and P2_REG). An attempt to change the pin configuration is ignored until
the bus-hold protocol is disabled (WSR.7 is cleared).
12
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
Table 6. Signal Descriptions (Continued)
Description
Name
HOLD#
Type
I
Bus Hold Request
An external device uses this active-low input signal to request control of the bus.
When the bus-hold protocol is enabled (WSR.7 is set), the P2.5/HOLD# pin can
function only as HOLD#, regardless of the configuration selected through the port
configuration registers (P2_MODE, P2_DIR, and P2_REG). An attempt to change
the pin configuration is ignored until the bus-hold protocol is disabled (WSR.7 is
cleared).
HOLD# shares a package pin with P2.5.
Instruction Fetch
INST
O
When high, INST indicates that an instruction is being fetched from external
memory. The signal remains high during the entire bus cycle of an external
instruction fetch. INST is low for data accesses, including interrupt vector fetches
and chip configuration byte reads. INST is low during internal memory fetches.
NMI
I
I
Nonmaskable Interrupt
In normal operating mode, a rising edge on NMI generates a nonmaskable
interrupt. NMI has the highest priority of all prioritized interrupts. Assert NMI for
greater than one state time to guarantee that it is recognized.
ONCE
On-circuit Emulation
Holding ONCE high during the rising edge of RESET# places the device into on-
circuit emulation (ONCE) mode. This mode puts all pins into a high-impedance
state, thereby isolating the device from other components in the system. The value
of ONCE is latched when the RESET# pin goes inactive. While the device is in
ONCE mode, you can debug the system using a clip-on emulator.
To exit ONCE mode, reset the device by pulling the RESET# signal low. To prevent
inadvertent entry into ONCE mode, connect the ONCE pin to VSS
.
P1.7:0
P2.7:0
I/O
I/O
Port 1
This is a standard, 8-bit, bidirectional port that shares package pins with individually
selectable special-function signals.
Port 1 shares package pins with the following signals: P1.0/EPA0, P1.1/EPA1,
P1.2/EPA2, P1.3/EPA3, P1.4/T1CLK, P1.5/T1DIR, P1.6/T2CLK, and P1.7/T2DIR.
Port 2
This is a standard, 8-bit, bidirectional port that shares package pins with individually
selectable special-function signals.
Port 2 shares package pins with the following signals: P2.0/TXD, P2.1/RXD,
P2.2/EXTINT0, P2.3/BREQ#, P2.4/EXTINT1, P2.5/HOLD#, P2.6/HLDA#, and
P2.7/CLKOUT.
P3.7:0
I/O
Port 3
This is a standard, 8-bit, bidirectional port that shares package pins with individually
selectable special-function signals.
Port 3 shares package pins with the following signals: P3.0/CS0#, P3.1/CS1#,
P3.2/CS2#, P3.3/CS3#, P3.4/CS4#, P3.5/CS5#, P3.6/EXTINT2, and
P3.7/EXTINT3.
13
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
Table 6. Signal Descriptions (Continued)
Name
P4.3:0
Type
Description
I/O
Port 4
This ia a 4-bit bidirectional, standard I/O port with high-current drive capability.
Port 4 shares package pins with the following signals: P4.0/PWM0, P4.1/PWM1,
and P4.2/PWM2. P4.3 has a dedicated package pin.
PWM2:0
RD#
O
O
Pulse Width Modulator Outputs
These are PWM output pins with high-current drive capability.
PWM2:0 share package pins with P4.2:0.
Read
Read-signal output to external memory. RD# is asserted only during external
memory reads.
RD# shares a package pin with OE#. (While most signals that share package pins
are connected to the pin by programming their associated control registers, both of
these signals are always connected to the pin.)
READY
I
Ready Input
This active-high input can be used to insert wait states in addition to those
programmed in the chip configuration byte 0 (CCB0) and the bus control x register
(BUSCONx). CCB0 is programmed with the minimum number of wait states (0–3)
for an external fetch of CCB1, and BUSCONx is programmed with the minimum
number of wait states (0–3) for all external accesses to the address range assigned
to the chip-select x channel. If READY is low when the programmed number of wait
states is reached, additional wait states are added until READY is pulled high.
READY shares a package pin with P5.6.
Reset
RESET#
I/O
A level-sensitive reset input to and open-drain system reset output from the
microcontroller. Either a falling edge on RESET# or an internal reset turns on a pull-
down transistor connected to the RESET# pin for 16 state times. In the powerdown,
standby, and idle modes, asserting RESET# causes the chip to reset and return to
normal operating mode. After a device reset, the first instruction fetch is from
FF2080H (or F2080H in external memory). For the 80L196NP, the program and
special-purpose memory locations (FF2000–FF2FFFH) reside in external memory.
For the 83L196NP, these locations can reside either in external memory or in
internal ROM.
RPD
I
Return from Powerdown
Timing pin for the return-from-powerdown circuit.
If your application uses powerdown mode, connect a capacitor between RPD and
V
SS if the internal oscillator is the clock source.
The capacitor causes a delay that enables the oscillator and PLL circuitry to
stabilize before the internal CPU and peripheral clocks are enabled.
The capacitor is not required if your application uses powerdown mode and if an
external clock input is the clock source.
If your application does not use powerdown mode, leave this pin unconnected.
14
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
Table 6. Signal Descriptions (Continued)
Description
Name
RXD
Type
I/O
Receive Serial Data
In modes 1, 2, and 3, RXD receives serial port input data. In mode 0, it functions as
either an input or an open-drain output for data.
RXD shares a package pin with P2.1.
Timer 1 External Clock
T1CLK
I
External clock for timer 1. Timer 1 increments (or decrements) on both rising and
falling edges of T1CLK. Also used in conjunction with T1DIR for quadrature
counting mode.
and
External clock for the serial I/O baud-rate generator input (program selectable).
T1CLK shares a package pin with P1.4.
T2CLK
T1DIR
T2DIR
TXD
I
I
Timer 2 External Clock
External clock for timer 2. Timer 2 increments (or decrements) on both rising and
falling edges of T2CLK. It is also used in conjunction with T2DIR for quadrature
counting mode.
T2CLK shares a package pin with P1.6.
Timer 1 External Direction
External direction (up/down) for timer 1. Timer 1 increments when T1DIR is high
and decrements when it is low. Also used in conjunction with T1CLK for quadrature
counting mode.
T1DIR shares a package pin with P1.5.
Timer 2 External Direction
I
External direction (up/down) for timer 2. Timer 2 increments when T2DIR is high
and decrements when it is low. It is also used in conjunction with T2CLK for
quadrature counting mode.
T2DIR shares a package pin with P1.7.
Transmit Serial Data
O
In serial I/O modes 1, 2, and 3, TXD transmits serial port output data. In mode 0, it
is the serial clock output.
TXD shares a package pin with P2.0.
VCC
VSS
PWR Digital Supply Voltage
Connect each VCC pin to the digital supply voltage.
GND Digital Circuit Ground
These pins supply ground for the digital circuitry. Connect each VSS pin to ground
through the lowest possible impedance path.
†
WR#
O
Write
This active-low output indicates that an external write is occurring. This signal is
asserted only during external memory writes.
WR# shares a package pin with WRL#.
†
When this pin is configured as a special-function signal (P5_MODE.2 = 1), the
chip configuration register 0 (CCR0) determines whether it functions as WR# or
WRL#. CCR0.2 = 1 selects WR#; CCR0.2 = 0 selects WRL#.
15
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
Table 6. Signal Descriptions (Continued)
Name
WRH#
Type
Description
†
O
Write High
During 16-bit bus cycles, this active-low output signal is asserted for high-byte
writes and word writes to external memory. During 8-bit bus cycles, WRH# is
asserted for all write operations.
WRH# shares a package pin with BHE#.
†
When this pin is configured as a special-function signal (P5_MODE.5 = 1), the
chip configuration register 0 (CCR0) determines whether it functions as BHE# or
WRH#. CCR0.2 = 1 selects BHE#; CCR0.2 = 0 selects WRH#.
†
WRL#
O
Write Low
During 16-bit bus cycles, this active-low output signal is asserted for low-byte writes
and word writes to external memory. During 8-bit bus cycles, WRL# is asserted for
all write operations.
WRL# shares a package pin with WR#.
†
When this pin is configured as a special-function signal (P5_MODE.2 = 1), the
chip configuration register 0 (CCR0) determines whether it functions as WR# or
WRL#. CCR0.2 = 1 selects WR#; CCR0.2 = 0 selects WRL#.
XTAL1
XTAL2
I
Input Crystal/Resonator or External Clock Input
Input to the on-chip oscillator and the internal clock generators. The internal clock
generators provide the peripheral clocks, CPU clock, and CLKOUT signal. When
using an external clock source instead of the on-chip oscillator, connect the clock
input to XTAL1. The external clock signal must meet the VIH specification for XTAL1.
O
Inverted Output for the Crystal/Resonator
Output of the on-chip oscillator inverter. Leave XTAL2 floating when the design
uses an external clock source instead of the on-chip oscillator.
16
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
4.0 ADDRESS MAP
Table 7. 8XL196NP Address Map
Description
External device (memory or I/O) connected to address/data bus
Address
(Note 1)
Notes
FF FFFFH
FF 3000H
2
FF 2FFFH Internal ROM or external device (memory or I/O) connected to address/data bus
FF 2000H (determined by EA# pin)
2, 3
FF 1FFFH
External device (memory or I/O) connected to address/data bus
FF 0100H
2
FF 00FFH
Reserved for ICE
FF 0000H
4
2
FE FFFFH Overlaid memory (reserved for future devices);
0F 0000H locations xF0000–xF00FFH are reserved for ICE
0E FFFFH
896 Kbytes of external device (memory or I/O) connected to address/data bus
01 0000H
2
00 FFFFH
External device (memory or I/O) connected to address/data bus
00 3000H
2
00 2FFFH External device (memory or I/O) connected to address/data bus or
00 2000H remapped internal ROM
2, 5, 6
2, 4, 7
4, 7, 9
6
00 1FFFH
Memory-mapped peripheral special-function registers (SFRs)
00 1FE0H
00 1FDFH
Internal peripheral special-function registers (SFRs)
00 1F00H
00 1EFFH
External device (memory or I/O) (reserved for future devices)
00 0400H
00 03FFH
Upper register file (general-purpose register RAM)
00 0100H
8, 9
00 00FFH
Lower register file (general-purpose register RAM and stack pointer)
00 0018H
8, 10
4, 7, 8, 10
00 0017H
Lower register file (CPU SFRs)
00 0000H
NOTES:
1. Internally, there are 24 address bits (A23:0); however, only 20 address lines (A19:0) are bonded out.
The external address space is 1 Mbyte (00000–FFFFFH).
2. Address with indirect, indexed, or extended modes.
3. The 8XL196NP resets to internal address FF2080H (FF2080H in internal ROM or F2080H in external
memory).
4. Unless otherwise noted, write 0FFH to reserved memory locations and write 0 to reserved SFR bits.
5. These areas are mapped into internal ROM if the REMAP bit (CCB1.2) is set and EA# is at logic 1.
Otherwise, they are mapped to external memory.
6. WARNING: The contents or functions of these memory locations may change with future device revi-
sions, in which case a program that relies on one or more of these locations may not function properly.
7. Refer to the 8XC196NP, 80C196NU Microcontroller User’s Manual.
8. Code executed in locations 000000H to 0003FFH will be forced external.
9. Address with indirect, indexed, or extended modes or through register windows.
10. Address with direct, indirect, indexed, or extended modes.
17
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
5.0 ELECTRICAL CHARACTERISTICS
ABSOLUTE MAXIMUM RATINGS*
NOTICE: This document contains information on
products in the design phase of development. The
specifications are subject to change without notice.
Do not finalize a design with this information.
Revised information will be published when the
product is available. Verify with your local Intel
sales office that you have the latest datasheet
before finalizing a design.
Storage Temperature ................................. –60°C to +150°C
Supply Voltage with Respect to VSS............. –0.5 V to +7.0 V
Power Dissipation ........................................................ 1.5 W
OPERATING CONDITIONS*
TA (Ambient Temperature Under Bias) ..............0°C to +70°C
V
F
CC (Digital Supply Voltage) ............................ 2.7 V to 3.3 V
XTAL1 (Input Frequency for VCC = 2.7–3.3 V)
(Note 1).............. 8 MHz to 14 MHz
*WARNING: Stressing the device beyond the “Absolute
Maximum Ratings” may cause permanent damage. These
are stress ratings only. Operation beyond the “Operating
Conditions” is not recommended and extended exposure
beyond the “Operating Conditions” may affect device reli-
ability.
NOTES:
1.
This device is static and should operate below 1 Hz, but
has been tested only down to 8 MHz.
5.1 DC Characteristics
Table 8. DC Characteristics at VCC = 2.7 – 3.3 V
(1)
Symbol
ICC
Parameter
Min
Typ
Max
Units Test Conditions
VCC Supply Current
Idle Mode Current
28
40
mA
XTAL1 = 14MHz
VCC = 3.3V
Device in Reset
IIDLE
IPD
ILI
14
50
25
75
mA
µA
µA
XTAL1 = 14MHz
VCC = 3.3 V
Powerdown Mode Current
(Note 2)
VCC = 3.3V
Input Leakage Current
(all input pins except RESET)
±10
VSS < VIN < VCC
VIL
Input Low Voltage (all pins)
Input High Voltage
–0.5
0.2 VCC +1.3
–0.5
0.4
V
V
V
V
VIH
VCC + 0.5
0.3 VCC
VCC + 0.5
VIL1
Input Low Voltage XTAL1
Input High Voltage XTAL1
VIH1
0.7 VCC
NOTES:
1. Typical values are based on a limited number of samples and are not guaranteed. The values listed
are at room temperature and with VCC = 3.0 V.
2. For temperatures below 100°C, typical is 10 µA.
3. For all pins except P4.3:0, which have higher drive capability.
4. If VOL is held above 0.45 V or VOH is held below Vcc–0.7 V, current on pins must be externally limited to
the following values: IOL and IOH maximum on all output pins is 12 mA.
5. For all pins that were weakly pulled high during RESET. This excludes ALE, INST, and NMI, which
were weakly pulled low (see VOL2) and ONCE, which was pulled medium low (see VOL3).
6. Pin capacitance is not tested. CS is based on design simulations.
18





8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
Table 8. DC Characteristics at VCC = 2.7 – 3.3 V(Continued)
(1)
Symbol
VOL
Parameter
Min
Typ
Max
Units Test Conditions
Output Low Voltage (output
configured as complemen-
tary) (Note 3,4)
0.3
V
V
IOL = 200 µA
0.45
IOL = 3.2 mA
VOH
Output High Voltage (output
configured as complemen-
tary) (Note 4)
VCC – 0.3
VCC – 0.7
V
V
I
OH = –200 µA
IOH = –3.2 mA
VOH2
Output High Voltage on
XTAL2
VCC – 0.3
VCC – 0.7
V
V
I
OH = –100 µA
IOH = –500 µA
OL = 8 mA
IOL = 10 mA
VOL
Output Low Voltage on P4.x
(output configured as comple-
mentary)
0.45
0.6
V
V
I
1
VOL
Output Low Voltage in
RESET on ALE, INST, and
NMI
0.45
V
IOL = 2 µA
2
VOH
Output High Voltage in
RESET (Note 5)
VCC – 0.7
V
V
IOH = –2 µA
IOL = 30 µA
1
VOL
Output Low Voltage in
RESET for ONCE pin
0.8
3
VOL
Output Low Voltage on
XTAL2
0.3
V
V
IOL = 100 µA
IOL = 500 µA
4
0.45
VTH+–VTH– Hysteresis voltage width on
0.3
V
RESET# pin
CS
Pin Capacitance (any pin to
VSS) (Note 6)
10
95
pF
kΩ
RRST
RESET Pull-up Resistor
9
VCC = 3.3V,
VIN = 2.0V
NOTES:
1. Typical values are based on a limited number of samples and are not guaranteed. The values listed
are at room temperature and with VCC = 3.0 V.
2. For temperatures below 100°C, typical is 10 µA.
3. For all pins except P4.3:0, which have higher drive capability.
4. If VOL is held above 0.45 V or VOH is held below Vcc–0.7 V, current on pins must be externally limited to
the following values: IOL and IOH maximum on all output pins is 12 mA.
5. For all pins that were weakly pulled high during RESET. This excludes ALE, INST, and NMI, which
were weakly pulled low (see VOL2) and ONCE, which was pulled medium low (see VOL3).
6. Pin capacitance is not tested. CS is based on design simulations.
19
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
35
30
25
20
15
10
5
IIDLE@VCC = 3.0 V
CC@VCC = 3.0 V
I
0
2
4
6
8
10 12 14 16 18 20
Frequency (MHz)
A4319-01
Figure 5. ICC, IIDLE versus Frequency
20
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
5.2 AC Characteristics — Multiplexed Bus Mode
Test Conditions: Capacitive load on all pins = 50 pF, Rise and Fall Times = 3 ns.
Table 9. AC Characteristics, Multiplexed Bus Mode
VCC = 2.7 V – 3.3 V
Symbol
Parameter
Units
Min
The 8XL196NP Will Meet These Specifications
Max
FXTAL
Input frequency on XTAL1
Period, 1/FXTAL
8
14
MHz
ns
1
TXTAL
71
20
125
110
1
1
TXHCH
TCLCL
TCHCL
TAVRL
TAVWL
XTAL1 High to CLKOUT High/Low
CLKOUT Cycle Time
ns
2TXTAL
ns
1
CLKOUT High Period
TXTAL1 – 10
TXTAL1 + 15
ns
A15:0, CSx# Valid to RD# Low
A15:0, CSx# Valid to WR# Low
A19:16, CSx# Hold after WR# Rising Edge
A19:16, CSx# Hold after RD# Rising Edge
CLKOUT Low to ALE High
2TXTAL1 – 30
ns
2TXTAL1 – 15
ns
TW
0
HSH
TRHSH
TCLLH
TLLCH
TLHLH
0
–12
–10
10
15
ns
ns
ALE Low to CLKOUT High
ALE Cycle Time
4TXTAL
ns (1)
1
TLHLL
ALE High Period
TXTAL1 – 15
TXTAL1 – 18
TXTAL1 – 25
TXTAL1 – 30
5
TXTAL1 + 5
ns
ns
TAVLL
AD15:0 Valid to ALE Low
AD15:0 Hold after ALE Low
ALE Low to RD# Low
RD# Low to CLKOUT Low
RD# Low Period
TLLAX
ns
TLLRL
ns
TRLCL
TRLRH
TRHLH
TRLAZ
TLLWL
TCLWL
TQVWH
TCHWH
TWLWH
NOTES:
30
ns
TXTAL1 – 10
TXTAL1 – 5
ns (1)
RD# High to ALE High
RD# Low to Address Float
ALE Low to WR# Low
CLKOUT Low to WR# Low
Data Valid before WR# High
CLKOUT High to WR# High
WR# Low Period
TXTAL1 + 20 ns (2)
5
ns
ns
TXTAL1 – 30
–18
10
10
ns
TXTAL1 – 23
–10
ns (1)
ns
TXTAL1 – 10
ns (1)
1. If wait states are used, add 2TXTAL1 × n, where n = number of wait states.
2. Assuming back-to-back bus cycles.
3. 8-bit bus only.
21
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
Table 9. AC Characteristics, Multiplexed Bus Mode (Continued)
V
CC = 2.7 V – 3.3 V
Min Max
The 8XL196NP Will Meet These Specifications
Symbol
Parameter
Units
TWHQX
TWHLH
TWHBX
TWHAX
TRHBX
Data Hold after WR# High
TXTAL1 – 33
TXTAL1 – 12
TXTAL1 – 10
TXTAL1 – 30
TXTAL1 – 10
TXTAL1 – 25
ns
WR# High to ALE High
TXTAL1 + 20 ns (2)
BHE#, INST Hold after WR# High
A15:8 Hold after WR# High
BHE#, INST Hold after RD# High
A15:8 Hold after RD# High
ns
ns (3)
ns
TRHAX
ns (3)
NOTES:
1. If wait states are used, add 2TXTAL1 × n, where n = number of wait states.
2. Assuming back-to-back bus cycles.
3. 8-bit bus only.
22
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
Table 10. AC Characteristics, Multiplexed Bus Mode
VCC = 2.7 V – 3.3 V
Min Max
The External Memory System Must Meet These Specifications
Symbol
Parameter
Units
TAVYV
TYLYH
TCLYX
TAVDV
TRLDV
TSLDV
TCLDV
TRHDZ
TRXDX
NOTES:
AD15:0 Valid to READY Setup
Non READY Time
2TXTAL1 – 60
No Upper Limit
ns
ns
READY Hold after CLKOUT Low
AD15:0 Valid to Input Data Valid
RD# Active to Input Data Valid
Chip-select Low, A19:16 Valid to Data Valid
CLKOUT Low to Input Data Valid
End of RD# to Input Data Float
Data Hold after RD# Inactive
0
TXTAL1 – 20 ns (1)
3TXTAL1 – 55 ns (2)
TXTAL1 – 25 ns (2)
4TXTAL1 – 75
TXTAL1 – 50
TXTAL1 – 10
ns
ns
ns
0
1. Exceeding the maximum specification causes additional wait states.
2. If wait states are used, add 2TXTAL1 × n, where n = number of wait states.
Table 11. AC Timing Symbol Definitions
Signals
Conditions
High
†
A
B
C
D
Address
BHE#
H
HOLD#
HLDA#
ALE
S
W
X
CSx#
H
L
HA
L
WR#, WRH#, WRL#
XTAL1
Low
CLKOUT
Data
V
X
Z
Valid
Q
R
Data Out
RD#
Y
READY
No Longer Valid
Floating
G
Buswidth
BR BREQ#
†
Address bus (demultiplexed mode) or Address/data bus (multiplexed mode)
23
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
T
XTAL1
XTAL1
T
T
T
T
CHCL
CLCL
XHCH
CLKOUT
RLCL
T
T
CLLH
LLCH
T
LHLH
ALE
RD#
T
T
T
T
RHLH
T
LHLL
RLRH
LLRL
LLAX
T
T
RLDV
T
RHDZ
AVLL
T
RLAZ
Address Out
Data
AD15:0
(read)
T
AVDV
T
T
T
WHLH
LLWL
WLWH
WR#
T
T
WHQX
QVWH
AD15:0
(write)
Address Out
Data Out
Address Out
T
T
RHBX
WHBX
BHE#,
INST
Valid
T
RHAX
T
WHAX
AD15:8
Address Out
T
SLDV
Address Out
A19:16
CSx#
T
WHSH
T
RHSH
A2844-01
Figure 6. System Bus Timing Diagram (Multiplexed Bus Mode)
24
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
T
(max)
CLYX
CLKOUT
T
AVYV
T
(min)
CLYX
READY
ALE
T
+ 2T
XTAL1
LHLH
T
+ 2T
XTAL1
RLRH
RD#
T
+ 2T
RLDV
+ 2T
XTAL1
T
AVDV
XTAL1
AD15:0
(read)
Address Out
Address Out
Data In
T
+ 2T
WLWH
XTAL1
+ 2T
WR#
T
QVWH
XTAL1
AD15:0
(write)
Data Out
BHE#, INST
A19:16
Extended Address Out
CSx#
A3250-01
Figure 7. READY Timing Diagram (Multiplexed Bus Mode)
25
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
5.3 AC Characteristics — Demultiplexed Bus Mode
Test Coditions: Capacitive load on all pins = 50 pF, Rise and Fall Times = 3 ns.
Table 12. AC Characteristics, Demultiplexed Bus Mode
VCC = 2.7 V – 3.3 V
Symbol
Parameter
Units
Min
The 8XL196NP Will Meet These Specifications
Input requency on XTAL1
Period, 1/FXTAL
Max
FXTAL
8
14
MHz
ns
1
TXTAL
71
20
125
110
1
1
TXHCH
TCLCL
TCHCL
TAVRL
TAVWL
TCLLH
TLLCH
TLHLH
XTAL1 High to CLKOUT High/Low
CLKOUT Cycle Time
ns
2TXTAL
ns
1
CLKOUT High Period
TXTAL1 – 10 TXTAL1 + 15
2TXTAL1 – 48
ns
A19:0, CSx# Valid to RD# Low
A19:0, CSx# Valid to WR# Low
CLKOUT Low to ALE High
ALE Low to CLKOUT High
ALE Cycle Time
ns
2TXTAL1 – 37
ns
– 12
– 15
10
15
ns
ns
4TXTAL
ns (1)
1
TLHLL
ALE High Period
TXTAL1 – 12 TXTAL1 + 10
ns
ns
TRLCH
TRLRH
TRHLH
TWLCH
TQVWH
TCHWH
TWLWH
TWHQX
TWHLH
TWHBX
TWHAX
TRHBX
TRHAX
NOTES:
RD# Low to CLKOUT High
RD# Low Period
– 5
20
2TXTAL1 – 10
ns (1)
RD# High to ALE High
TXTAL1 – 5 TXTAL1 + 20 ns (2)
WR# Low to CLKOUT High
Data Valid before WR# High
CLKOUT High to WR# High
WR# Low Period
– 10
10
ns
ns (1)
ns
3TXTAL1 – 55
– 15
5
2TXTAL1 – 13
TXTAL1 – 25
ns (1)
ns
Data Hold after WR# High
WR# High to ALE High
TXTAL1 – 10 TXTAL1 + 20 ns (2)
BHE#, INST Hold after WR# High
A19:0, CSx# Hold after WR# High
BHE#, INST Hold after RD# High
A19:0, CSx# Hold after RD# High
TXTAL1 – 10
ns
ns
ns
ns
0
TXTAL1 – 10
0
1. If wait states are used, add 2TXTAL1 × n, where n = number of wait states.
2. Assuming back-to-back bus cycles.
26
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
Table 13. AC Characteristics, Demultiplexed Bus Mode
VCC = 2.7 V – 3.3 V
Min Max
The External Memory System Must Meet These Specifications
Symbol
Parameter
Units
TAVYV
TYLYH
TCLYX
TAVDV
TRLDV
TCLDV
TRHDZ
TRXDX
NOTES:
A19:0, CSx# Valid to READY Setup
Non READY Time
3TXTAL1 – 88
No Upper Limit
ns
ns
READY Hold after CLKOUT Low
A19:0, CSx# Valid to Input Data Valid
RD# Active to Input Data Valid
CLKOUT Low to Input Data Valid
End of RD# to Input Data Float
Data Hold after RD# Inactive
TXTAL1 – 30 ns (1)
4TXTAL1 – 75 ns (2)
2TXTAL1 – 33 ns (2)
TXTAL1 – 50
TXTAL1 – 5
ns
ns
ns
0
1. Exceeding the maximum specification causes additional wait states.
2. If wait states are used, add 2TXTAL1 × n, where n = number of wait states.
27
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
T
XTAL1
XTAL1
T
T
T
CLCL
CHCL
XHCH
CLKOUT
T
CLDV
T
T
LLCH
CLLH
T
LHLH
ALE
RD#
T
T
T
RHLH
LHLL
RLRH
T
RLCH
T
T
RHDZ
RLDV
AD15:0
(read)
Valid
T
AVDV
T
CHWH
T
WHLH
T
WLWH
T
WLCH
WR#
T
T
QVWH
WHQX
AD15:0
(write)
Valid
T
RHBX
T
WHBX
BHE#,
INST
Valid
T
T
RHAX
WHAX
A19:0
CSx#
Address Out
Address
A2845-01
Figure 8. System Bus Timing Diagram (Demultiplexed Bus Mode)
28
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
T
(max)
CLYX
CLKOUT
READY
T
(min)
CLYX
T
AVYV
T
+ 2T
LHLH
XTAL1
+ 2T
ALE
RD#
T
RLRH
XTAL1
T
+ 2T
RLDV
+ 2T
XTAL1
XTAL1
T
AVDV
AD15:0
(read)
Data
T
+ 2T
XTAL1
WLWH
WR#
T
+ 2T
QVWH
XTAL1
AD15:0
(write)
Data Out
BHE#, INST
A19:0
Extended Address Out
CSx#
A3256-01
Figure 9. READY Timing Diagram (Demultiplexed Bus Mode)
29
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
5.4 HOLD#/HLDA# Timing
Table 14. HOLD#/HLDA# Timings
V
CC = 2.7 V – 3.3V
Symbol
Parameter
Units
Min
Max
THVCH
HOLD# Setup Time (to guarantee recognition at next clock)
CLKOUT Low to HLDA# Low
83
ns
ns
ns
ns
ns
ns
ns
ns
ns
TCLHAL
TCLBRL
THALAZ
THALBZ
TCLHAH
TCLBRH
THAHAX
THAHBV
–15
–15
15
15
33
25
15
25
CLKOUT Low to BREQ# Low
HLDA# Low to Address Float
HLDA# Low to BHE#, INST, RD#, WR# Weakly Driven
CLKOUT Low to HLDA# High
–25
–25
–20
–20
CLKOUT Low to BREQ# High
HLDA# High to Address No Longer Floating
HLDA# High to BHE#, INST, RD#, WR# Valid
CLKOUT
THVCH
THVCH
Hold Latency
HOLD#
HLDA#
BREQ#
TCLHAL
TCLHAH
TCLBRL
TCLBRH
THALAZ
THAHAX
A19:0, AD15:0
THALBZ
THAHBV
Weakly held inactive
TCLLH
CSx#, BHE#,
INST, RD#, WR#
WRL#, WRH#
ALE
Start of strongly driven ALE
A2460-03
Figure 10. HOLD#/HLDA# Timing Diagram
30
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
5.5 AC Characteristics — Serial Port, Shift Register Mode
Table 15. Serial Port Timing — Shift Register Mode
V
CC = 2.7 V – 3.3V
Symbol
Parameter
Serial Port Clock period
Units
Min
Max
TXLXL
(BRR ≥ x002H)
6TXTAL
4TXTAL
ns
ns
1
1
(BRR = x001H) (Note 1)
TQVXH
TXHQX
TXHQV
TDVXH
TXHDX
TXHQZ
NOTE:
Output data setup to clock high
Output data hold after clock high
Next output data valid after clock high
Input data setup to clock high
Input data hold after clock high
Last clock high to output float
3TXTAL1 – 30
ns
ns
ns
ns
ns
ns
2TXTAL1 – 90
2TXTAL1 + 50
2TXTAL1 + 50
0
5TXTAL1+ 30
1. The minimum baud-rate register value for receptions is x002H and the minimum baud-rate register
value for transmissions is x001H.
T
XLXL
TXD
T
T
XHQV
XLXH
T
T
XHQZ
T
XHQX
5
QVXH
RXD
0
T
1
2
7
4
6
3
(Out)
T
DVXH
XHDX
Valid
RXD
(In)
Valid
Valid
Valid
Valid
Valid
Valid
Valid
A2080-02
Figure 11. Serial Port Waveform — Shift Register Mode
31
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
5.6 External Clock Drive
Table 16. External Clock Drive
Symbol
1/TXLXL
Parameter
Input frequency
Min
8
Max
14
Units
MHz
ns
TXLXL
TXHXX
TXLXX
TXLXH
TXHXL
Period (TXTAL
High Time
Low Time
Rise Time
Fall Time
)
71
125
1
0.35TXTAL
0.35TXTAL
0.65TXTAL
0.65TXTAL
10
ns
1
1
1
ns
1
ns
10
ns
TXHXL
TXHXX
TXLXH
0.7 VCC + 0.5 V
0.7 VCC + 0.5 V
0.3 VCC – 0.5 V
TXLXL
TXLXX
0.3 VCC – 0.5 V
A2119-02
Figure 12. External Clock Drive Waveforms
5.7 Test Output Waveforms
2.5 V
1.6 V
0.5 V
1.6 V
0.5 V
Test Points
0.25 V
AC testing inputs are driven at 2.5 V for a logic "1" and 0.25 V for
a logic "0". Timing measurements are made at 1.6 V for a logic
"1" and 0.5 V for a logic "0".
A2740-01
Figure 13. AC Testing Output Waveforms During 3.0 Volt Testing
32
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
VLOAD + 0.15 V
VLOAD
VOH – 0.15 V
Timing Reference
Points
VOL + 0.15 V
VLOAD – 0.15 V
For timing purposes, a port pin is no longer floating when a
150 mV change from load voltage occurs and begins to float
when a 150 mV change from the loading VOH/VOL level occurs
with IOL/IOH ≤10 mA.
A2739-01
Figure 14. Float Waveforms During 3.0 Volt Testing
33
8XL196NP COMMERCIAL CHMOS 16-BIT MICROCONTROLLER
6.0 THERMAL CHARACTERISTICS
All thermal impedance data is approximate for static
air conditions at 1 watt of power dissipation. Values
will change depending on operating conditions and
the application. The Intel Packaging Handbook
(order number 240800) describes Intel’s thermal
impedance test methodology.
Table 17. Thermal Characteristics
Package Type
100-pin SQFP
100-pin QFP
θ
θ
JC
JA
55°C/W
56°C/W
14°C/W
16°C/W
7.0 8XL196NP ERRATA
Change identifiers have been used on embedded
products since 1990. The change identifier is the
last character in the FPO number. The FPO number
is typically a nine character number located on the
second line of the topside package mark. The
following errata listing is applicable to the B–step
(denoted by a “B” or “C” at the end of the topside
tracking number):
1. Any jump, conditional jump, or call instruction
located within six bytes of the top of a page,
i.e., 0FFFA–0FFFFH, may cause a jump to the
wrong page. To ensure this problem does not
occur, place at least six NOPs at the top of
each page.
8.0 DATASHEET REVISION HISTORY
This datasheet is valid for devices with an “A” at the
end of the topside tracking number. Datasheets are
changed as new device information becomes
available. Verify with your local Intel sales office that
you have the latest version before finalizing a
design or ordering devices.
34
厂商 型号 描述 页数 下载

INTEL

 		8XL51FA 低电压CHMOS单片8位微控制器[ LOW VOLTAGE CHMOS SINGLE-CHIP 8-BIT MICROCONTROLLERS ] 20 页

ETC

 		8XL51FB 低电压CHMOS单片8位微控制器\n[ LOW VOLTAGE CHMOS SINGLE-CHIP 8-BIT MICROCONTROLLERS ] 20 页

ETC

 		8XL51FC 低电压CHMOS单片8位微控制器\n[ LOW VOLTAGE CHMOS SINGLE-CHIP 8-BIT MICROCONTROLLERS ] 20 页

INTEL

 		8XL52 低电压CHMOS单片8位微控制器[ LOW VOLTAGE CHMOS SINGLE-CHIP 8-BIT MICROCONTROLLERS ] 20 页

ETC

 		8XL54 低电压CHMOS单片8位微控制器\n[ LOW VOLTAGE CHMOS SINGLE-CHIP 8-BIT MICROCONTROLLERS ] 20 页

ETC

 		8XL58 低电压CHMOS单片8位微控制器\n[ LOW VOLTAGE CHMOS SINGLE-CHIP 8-BIT MICROCONTROLLERS ] 20 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.228257s
