LYR976

型号:

LYR976

描述:

超CHIPLED超高亮LED[ Hyper CHIPLED Hyper-Bright LED ]

品牌:

OSRAM[ OSRAM GMBH ]

页数:

11 页

PDF大小:

144 K

Hyper CHIPLED
Hyper-Bright LED
LS R976, LO R976, LY R976
Besondere Merkmale
Features
Gehäusetyp: 0805
package: 0805
Besonderheit des Bauteils: extrem kleine
Bauform 2,0 mm x 1,25 mm x 0,8 mm
Wellenlänge: 632 nm (super-rot),
605 nm (orange), 587 nm (gelb)
Abstrahlwinkel: extrem breite
Abstrahlcharakteristik (160°)
feature of the device: extremely small
package 2.0 mm x 1.25 mm x 0.8 mm
wavelength: 632 nm (super-red),
605 nm (orange), 587 nm (yellow)
viewing angle: extremely wide (160°)
technology: InGaAlP
Technologie: InGaAlP
optischer Wirkungsgrad: 7 lm/W (super-rot),
11 lm/W (orange, gelb)
Verarbeitungsmethode: für alle
SMT-Bestücktechniken geeignet
Lötmethode: IR Reflow Löten
Vorbehandlung: nach JEDEC Level 2
Gurtung: 8 mm Gurt mit 4000/Rolle, ø180 mm
optical efficiency: 7 lm/W (super-red),
11 lm/W (orange, yellow)
assembly methods: suitable for all
SMT assembly methods
soldering methods: IR reflow soldering
preconditioning: acc. to JEDEC Level 2
taping: 8 mm tape with 4000/reel, ø180 mm
Anwendungen
Applications
Informationsanzeigen im Außenbereich
Einkopplung in Lichtleiter
Hinterleuchtung (LCD, Handy, Schalter,
Tasten, Displays, Werbebeleuchtung,
Allgemeinbeleuchtung)
outdoor displays
coupling into light guides
backlighting (LCD, cellular phones, switches,
keys, displays, illuminated advertising, general
lighting)
Signal- und Symbolleuchten
Markierungsbeleuchtung (z.B. Stufen,
Fluchtwege, u.ä.)
signal and symbol luminaire
marker lights (e.g. steps, exit ways, etc.)
toys
Spielsachen
2001-02-12
1
LS R976, LO R976, LY R976
Typ
Emissionsfarbe
Farbe der
Lichtaustritts-
fläche
Color of the
Light Emitting
Area
Lichtstärke
Bestellnummer
Ordering Code
Type
Color of
Emission
Luminous
Intensity
IF = 20 mA
IV (mcd)
min.
typ.
50
LS R976
LO R976
LY R976
super-red
orange
yellow
colorless diffused 18
colorless diffused 28
colorless diffused 28
Q62702-P5178
Q62702-P5176
Q62702-P5177
70
60
Helligkeitswerte werden mit einer Stromeinprägedauer von 25 ms und einer Genauigkeit von ± 11% ermittelt.
Luminous intensity is tested at a current pulse duration of 25 ms and a tolerance of ± 11%.
Anm.: gesamter Farbbereich, Lieferung in Einzelgruppen (siehe Seite 5)
Die Standardlieferform von Serientypen beinhaltet eine untere bzw. eine obere Familiengruppe,
die aus nur 3 bzw. 4 Halbgruppen besteht. Einzelne Halbgruppen sind nicht erhältlich.
In einer Verpackungseinheit / Gurt ist immer nur eine Halbgruppe enthalten.
Note: Total color tolerance range, delivery in single groups (please see page 5)
The standard shipping format for serial types includes a lower or upper family group of 3 or 4
individual groups. Individual half groups are not available.
No packing unit / tape ever contains more than one luminous intensity half group.
2001-02-12
2
LS R976, LO R976, LY R976
Grenzwerte
Maximum Ratings
Bezeichnung
Parameter
Symbol
Symbol
Wert
Value
Einheit
Unit
Betriebstemperatur
Operating temperature range
Top
Tstg
Tj
30 + 85
40 + 85
+ 95
°C
°C
°C
mA
A
Lagertemperatur
Storage temperature range
Sperrschichttemperatur
Junction temperature
Durchlassstrom
Forward current
IF
25
Stoßstrom
IFM
0.1
Surge current
tp = 10 µs, D = 0.1
Sperrspannung
Reverse voltage
VR
5
V
Leistungsaufnahme
Power consumption
Ptot
65
mW
Wärmewiderstand
Thermal resistance
Sperrschicht/Umgebung
Junction/ambient
Sperrschicht/Lötpad
Rth JA
Rth JS
800
450
K/W
K/W
Junction/solder point
Montage auf PC-Board FR 4 (Padgröße 16 mm2)
mounted on PC board FR 4 (pad size 16 mm 2)
2001-02-12
3
LS R976, LO R976, LY R976
Kennwerte (TA = 25 °C)
Characteristics
Bezeichnung
Parameter
Symbol
Symbol
Werte
Values
Einheit
Unit
LS
LO
LY
Wellenlänge des emittierten Lichtes
Wavelength at peak emission
IF = 20 mA
Dominantwellenlänge 1)
Dominant wavelength
IF = 20 mA
(typ.) λpeak
645
610
591
nm
nm
nm
(typ.) λdom
(typ.) ∆λ
(typ.) 2ϕ
633
± 6
606
± 6
588
± 8
Spektrale Bandbreite bei 50 % Irel max
Spectral bandwidth at 50 % Irel max
IF = 20 mA
16
16
15
Abstrahlwinkel bei 50 % IV (Vollwinkel)
Viewing angle at 50 % IV
160
160
160
Grad
deg.
Durchlassspannung 2)
Forward voltage
IF = 20 mA
(typ.) VF
(max.) VF
2.0
2.4
2.0
2.4
2.0
2.4
V
V
Sperrstrom
Reverse current
VR = 5 V
(typ.) IR
(max.) IR
0.01
100
0.01
100
0.01
100
µA
µA
Temperaturkoeffizient von λpeak
Temperature coefficient of λpeak
IF = 20 mA; 10°C T 100°C
(typ.) TCλpeak
(typ.) TCλdom
(typ.) TCV
0.14
0.01
2.0
7
0.13
0.07
1.7
11
0.13
0.10
2.5
11
nm/K
nm/K
mV/K
lm/W
Temperaturkoeffizient von λdom
Temperature coefficient of λdom
IF = 20 mA; 10°C T 100°C
Temperaturkoeffizient von VF
Temperature coefficient of VF
IF = 20 mA; 10°C T 100°C
Optischer Wirkungsgrad
Optical efficiency
IF = 20 mA
(typ.) ηopt
1)
Wellenlängengruppen werden mit einer Stromeinprägedauer von 25 ms und einer Genauigkeit von ±1 nm ermittelt.
Wavelength groups are tested at a current pulse duration of 25 ms and a tolerance of ±1 nm.
2)
Spannungswerte werden mit einer Stromeinprägedauer von 1 ms und einer Genauigkeit von ±0.1 V ermittelt.
Voltages are tested at a current pulse duration of 1 ms and a tolerance of ±0.1 V.
2001-02-12
4
LS R976, LO R976, LY R976
1) Wellenlängengruppen für LY R976
Wavelength groups for LY R976
Gruppe
Group
Wellenlänge
Wavelength
Einheit
Unit
min.
580
584
588
592
max.
584
588
592
596
3
4
5
6
nm
nm
nm
nm
2001-02-12
5
LS R976, LO R976, LY R976
Relative spektrale Emission Irel = f (λ), TA = 25 °C, IF = 20 mA
Relative Spectral Emission
V(λ) = spektrale Augenempfindlichkeit
Standard eye response curve
OHL00555
100
%
Ιrel
orange
super-red
80
V
yellow
λ
60
40
20
0
400
450
500
550
600
650
nm
700
λ
Abstrahlcharakteristik Irel = f (ϕ)
Radiation Characteristic
40˚
30˚
20˚
10˚
0˚
1.0
OHL00408
ϕ
50˚
0.8
0.6
0.4
0.2
0
60˚
70˚
80˚
90˚
100˚
1.0
0.8
0.6
0.4
0˚
20˚
40˚
60˚
80˚
100˚
120˚
2001-02-12
6
LS R976, LO R976, LY R976
Durchlassstrom IF = f (VF)
Forward Current
TA = 25 °C
Relative Lichtstärke IV/IV(20 mA) = f (IF)
Relative Luminous Intensity
TA = 25 °C
OHL00642
10 1
OHL00232
102
mA
5
Ι V
Ι V (20 mA)
IF
10 0
5
101
5
10 -1
5
100
5
super-red,
orange
yellow
10 -2
5
10 -3
10-1
10 -2
10 -1
10 0
10 1 mA 10 2
1
1.4
1.8
2.2
2.6
3
V 3.4
VF
Ι F
Maximal zulässiger Durchlassstrom IF = f (T)
Max. Permissible Forward Current
Relative Lichtstärke IV/IV(25 °C) = f (TA)
Relative Luminous Intensity
IF = 20 mA
OHL00420
OHL00641
30
2
mA
IV
IV (25 ˚C)
25
20
15
10
5
I F
1.6
1.2
0.8
0.4
0
orange
yellow
super-red
orange
yellow
super-red
0
0
10 20 30 40 50 60 70 80 °C 100
-20
0
20
40
60
˚C 100
TA
TA
2001-02-12
7
LS R976, LO R976, LY R976
Maßzeichnung
Package Outlines
1.35 (0.053)
1.15 (0.045)
0.9 (0.035)
0.7 (0.028)
0.4 (0.016)
0.2 (0.008)
1.25 (0.049)
1.05 (0.041)
ø0.6 (ø0.024)
ø0.4 (ø0.016)
Cathode
mark
Cathode mark
Soldering terminal
may flow in x, y direction
GEOY6024
Maße werden wie folgt angegeben: mm (inch) / Dimensions are specified as follows: mm (inch).
Gewicht / Approx. weight: 3.2 mg
2001-02-12
8
LS R976, LO R976, LY R976
Lötbedingungen
Vorbehandlung nach JEDEC Level 2
Soldering Conditions Preconditioning acc. to JEDEC Level 2
IR-Reflow Lötprofil
(nach IPC 9501)
IR Reflow Soldering Profile (acc. to IPC 9501)
OHLA0685
250
T
max = 245 ˚C
˚C
T
200
T
= 183 ˚C
t = 70 s
150
100
50
2-3 K/s
2-3 K/s
0
0:00
0:30
1:00
1:30
2:00
2:30
3:00
3:30
4:00
4:30
5:00 min 5:30
t
Empfohlenes Lötpaddesign IR Reflow Löten
Recommended Solder Pad IR Reflow Soldering
0.9 (0.035)
1.2 (0.047)
1.2 (0.047)
OHAPY607
Maße werden wie folgt angegeben: mm (inch) / Dimensions are specified as follows: mm (inch)
2001-02-12
9
LS R976, LO R976, LY R976
Gurtung / Polarität und Lage
Verpackungseinheit 4000/Rolle, ø180 mm
Method of Taping / Polarity and Orientation Packing unit 4000/reel, ø180 mm
Processive direction
1.5 (0.059)
2 (0.079)
4 (0.157)
C
A
1.6 (0.063)
Cathode mark
4 (0.157)
OHAY0530
Maße werden wie folgt angegeben: mm (inch) / Dimensions are specified as follows: mm (inch).
2001-02-12
10
LS R976, LO R976, LY R976
Revision History: 2001-02-12
Previous Version: 2001-02-12
Page
Subjects (major changes since last revision)
Published by OSRAM Opto Semiconductors GmbH & Co. OHG
Wernerwerkstrasse 2, D-93049 Regensburg
© All Rights Reserved.
Attention please!
The information describes the type of component and shall not be considered as assured characteristics.
Terms of delivery and rights to change design reserved. Due to technical requirements components may contain
dangerous substances. For information on the types in question please contact our Sales Organization.
If printed or downloaded, please find the latest version in the Internet.
Packing
Please use the recycling operators known to you. We can also help you get in touch with your nearest sales office.
By agreement we will take packing material back, if it is sorted. You must bear the costs of transport. For packing
material that is returned to us unsorted or which we are not obliged to accept, we shall have to invoice you for any costs
incurred.
Components used in life-support devices or systems must be expressly authorized for such purpose! Critical
components 1 may only be used in life-support devices or systems 2 with the express written approval of OSRAM OS.
1 A critical component is a component used in a life-support device or system whose failure can reasonably be expected
to cause the failure of that life-support device or system, or to affect its safety or the effectiveness of that device or
system.
2 Life support devices or systems are intended (a) to be implanted in the human body, or (b) to support and/or maintain
and sustain human life. If they fail, it is reasonable to assume that the health of the user may be endangered.
2001-02-12
11
厂商 型号 描述 页数 下载

INFINEON

LYR970 CHIPLED[ CHIPLED ] 6 页

INFINEON

LYR970-JO CHIPLED[ CHIPLED ] 6 页

OSRAM

LYR971 CHIPLED[ CHIPLED ] 10 页

INFINEON

LYR976 CHIPLED[ CHIPLED ] 6 页

INFINEON

LYR976-3 [ Visible LED, Diffused ] 11 页

INFINEON

LYR976-4 [ Visible LED, Diffused ] 11 页

INFINEON

LYR976-5 [ Visible LED, Diffused ] 11 页

INFINEON

LYR976-6 [ Visible LED, Diffused ] 11 页

INFINEON

LYR976-MO CHIPLED[ CHIPLED ] 6 页

OSRAM

LYR976-PS-36 [ SMT package 0805 ] 20 页

PDF索引:

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引:

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

0.163615s
