Central
CZR1-04
Semiconductor Corp.
SURFACE MOUNT
HIGH VOLTAGE RECTIFIER
DESCRIPTION:
The CENTRAL SEMICONDUCTOR CZR1-04 type
is a Silicon General Purpose Rectifier designed for
applications requiring high voltage capability.
SOT-223 CASE
MAXIMUM RATINGS: (T =25°C)
A
SYMBOL
UNITS
Reverse Voltage
Peak Reverse Voltage
V
V
RM
400
400
V
V
R
Average Forward Current
Peak Forward Surge Current, t=1.0µs
Operating and Storage
Junction Temperature
I
1.0
10
A
A
O
I
FSM
T ,T
J stg
P
-65 to +150
2.0
°C
W
Power Dissipation
D
Thermal Resistance
Θ
62.5
°C/W
JA
ELECTRICAL CHARACTERISTICS: (T =25°C unless otherwise noted)
A
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNITS
I
I
V =400V
1.0
50
µA
µA
V
R
R
R
V =400V, T =150°C
R
A
BV
I =100µA
400
R
R
V
V
I =1.0A
1.2
1.5
V
F
F
F
I =2.0A
V
F
t
I =200mA, I =200mA, I =20mA
1.0
10
µs
pF
rr
F
R
RR
C
V =0V, f=1.0MHz
J
R
