5SMX 12H1273
2)
IGBT characteristic values
Parameter
Symbol Conditions
min typ max Unit
Collector (-emitter)
breakdown voltage
V(BR)CES VGE = 0 V, IC = 1 mA, Tvj = 25 °C
1200
1.7
V
Tvj = 25 °C
Tvj = 125 °C
Tvj = 25 °C
Tvj = 125 °C
1.9
2.1
2.3
V
V
Collector-emitter
saturation voltage
VCE sat
IC = 50 A, VGE = 15 V
100
µA
µA
nA
V
Collector cut-off current
ICES
VCE = 1200 V, VGE = 0 V
200
Gate leakage current
Gate-emitter threshold voltage
Gate charge
IGES
VGE(TO)
Qge
-200
4.5
200
6.5
VCE = 0 V, VGE = ±20 V, Tvj = 125 °C
IC = 2 mA, VCE = VGE, Tvj = 25 °C
IC = 50 A, VCE = 600 V, VGE = -15 ..15 V
470
4.72
0.29
0.19
5
nC
Input capacitance
Cies
VCE = 25 V, VGE = 0 V, f = 1 MHz,
Tvj = 25 °C
nF
Output capacitance
Coes
Cres
Reverse transfer capacitance
Internal gate resistance
RGint
W
Tvj = 25 °C
Tvj = 125 °C
Tvj = 25 °C
Tvj = 125 °C
Tvj = 25 °C
Tvj = 125 °C
Tvj = 25 °C
Tvj = 125 °C
170
195
60
VCC = 600 V, IC = 50 A,
RG = 15 W, VGE = ±15 V,
Ls = 60 nH,
Turn-on delay time
Rise time
td(on)
ns
tr
ns
ns
ns
inductive load
65
410
470
45
VCC = 600 V, IC = 50 A,
RG = 22 W, VGE = ±15 V,
Ls = 60 nH,
Turn-off delay time
Fall time
td(off)
tf
inductive load
70
VCC = 600 V, IC = 50 A,
VGE = ±15 V, RG = 15 W,
Ls = 60 nH,
Tvj = 25 °C
Tvj = 125 °C
4.1
6.3
Turn-on switching energy
Eon
mJ
inductive load,
FWD: 5SLX12E1200
VCC = 600 V, IC = 50 A,
VGE = ±15 V, RG = 22 W,
Ls = 60 nH,
Tvj = 25 °C
Tvj = 125 °C
2.9
4.7
Turn-off switching energy
Short circuit current
Eoff
mJ
A
inductive load
tpsc ≤ 10 μs, VGE = 15 V, Tvj = 125 °C,
ISC
290
VCC = 900 V, VCEM ≤ 1200 V
2)
Characteristic values according to IEC 60747 - 9
