5SDD54N4000

型号：

5SDD54N4000

描述：

整流器器二极管[ Rectifier Diode ]

品牌：

ABB[ THE ABB GROUP ]

页数：

6 页

PDF大小：

359 K

下载PDF手册
VRSM
IF(AV)M
IF(RMS)
IFSM
=
=
=
=
=
=
4000 V
5200 A
8200 A
85×103 A
0.8 V
Rectifier Diode
5SDD 54N4000
VF0
rF
0.086
mΩ
Doc. No. 5SYA1171-00 Dec. 03
• Patented free-floating silicon technology
• Very low on-state losses
• Optimum power handling capability
Blocking
Maximum rated values 1)
Parameter
Symbol Conditions
VRRM f = 50 Hz, tp = 10ms, Tj = 0...150°C
Value
3600
4000
Unit
V
Repetitive peak reverse voltage
Non - repetitive peak reverse voltage VRSM
f = 5 Hz, tp = 10ms, Tj = 0...150°C
V
Characteristic values
Parameter
Symbol Conditions
min
typ
typ
max
400
Unit
Max. (reverse) leakage current
IRRM
VRRM, Tj = 150°C
mA
Mechanical data
Maximum rated values 1)
Parameter
Symbol Conditions
min
81
max
Unit
kN
m/s2
m/s2
Mounting force
Acceleration
Acceleration
FM
90
108
50
a
a
Device unclamped
Device clamped
100
Characteristic values
Parameter
Symbol Conditions
min
typ
max
Unit
kg
Weight
m
2.8
Housing thickness
Surface creepage distance
Air strike distance
H
FM = 90 kN, Ta = 25 °C
35.9
mm
mm
mm
DS
Da
56
22
1) Maximum rated values indicate limits beyond which damage to the device may occur
ABB Switzerland Ltd, Semiconductors reserves the right to change specifications without notice.
5SDD 54N4000
On-state
Maximum rated values 1)
Parameter
Symbol Conditions
IF(AV)M 50 Hz, Half sine wave, TC = 85 °C
min
typ
max
5200
Unit
Max. average on-state
current
A
8200
85×103
Max. RMS on-state current IF(RMS)
A
A
Max. peak non-repetitive
surge current
IFSM
tp = 10 ms, Tj = 150°C,
VR = 0 V
36.3×106
90×103
Limiting load integral
I2t
A2s
A
Max. peak non-repetitive
surge current
IFSM
tp = 8.3 ms, Tj = 150°C,
VR = 0 V
34.6×106
Limiting load integral
I2t
A2s
Characteristic values
Parameter
Symbol Conditions
min
typ
max
Unit
V
1.23
On-state voltage
Threshold voltage
Slope resistance
VF
IF = 5000 A, Tj = 150°C
0.8
V(T0)
rT
Tj = 150°C
IT = 2500...7500 A
V
0.086
mΩ
Switching
Characteristic values
Parameter
Symbol Conditions
min
typ
max
Unit
Qrr
18000
µAs
Recovery charge
diF/dt = -10 A/µs, VR = 200 V
IFRM = 4000 A, Tj = 150°C
ABB Switzerland Ltd, Semiconductors reserves the right to change specifications without notice.
Doc. No. 5SYA1171-00 Dec. 03
page 2 of 6
5SDD 54N4000
Thermal
Maximum rated values 1)
Parameter
Symbol Conditions
min
typ
typ
max
Unit
Operating junction
temperature range
Tvj
0
150
°C
Storage temperature range Tstg
Characteristic values
Parameter
-40
150
°C
Symbol Conditions
min
max
Unit
Thermal resistance junction Rth(j-c)
to case
Double-side cooled
Fm = 81...108 kN
5.7
K/kW
Rth(j-c)A Anode-side cooled
Fm = 81...108 kN
11.4
11.4
1
K/kW
K/kW
K/kW
K/kW
Rth(j-c)C Cathode-side cooled
Fm = 81...108 kN
Thermal resistance case to Rth(c-h)
heatsink
Double-side cooled
Fm = 81...108 kN
Rth(c-h)
Single-side cooled
Fm = 81...108 kN
2
Analytical function for transient thermal
impedance:
n
-t/τi
Z
(t) = R (1-e )
∑
th(j-c)
th i
i=1
i
1
2
3
4
Rth i(K/kW)
3.728
0.8115
1.248
0.1014
0.433
0.0089
0.292
0.0015
τi(s)
Fig. 1 Transient thermal impedance junction-to-
case.
ABB Switzerland Ltd, Semiconductors reserves the right to change specifications without notice.
Doc. No. 5SYA1171-00 Dec. 03
page 3 of 6
5SDD 54N4000
Max. on-state characteristic model:
Max. on-state characteristic model:
= A + B ⋅I +C ⋅ln(I +1)+ D ⋅ I
VF150
= A + B ⋅I +C ⋅ln(I +1)+ D ⋅ I
Tvj
Tvj
F
Tvj
F
Tvj
F
VF25
Tvj
Tvj
F
Tvj
F
Tvj
F
Valid for IF = 300 – 110000 A
Valid for IF = 300 – 110000 A
A25
486.40×10-3
B25
45.53×10-6
C25
65.82×10-3
D25
68.19×10-15
A150
B150
C150
D150
22.00×10-3
49.09×10-6
113.10×10-3
-20.75×10-15
Fig. 2 Isothermal on-state characteristics
Fig. 3 Isothermal on-state characteristics
Fig. 4 On-state power losses vs average on-state
Fig. 5 Max. permissible case temperature vs
current.
average on-state current.
ABB Switzerland Ltd, Semiconductors reserves the right to change specifications without notice.
Doc. No. 5SYA1171-00 Dec. 03
page 4 of 6
5SDD 54N4000
Fig. 6 Surge on-state current vs. pulse length. Half-
Fig. 7 Surge on-state current vs. number of pulses.
sine wave.
Half-sine wave, 10 ms, 50Hz.
Fig. 8 Recovery charge vs. decay rate of on-state
Fig. 9 Peak reverse recovery current vs. decay rate
current.
of on-state current.
ABB Switzerland Ltd, Semiconductors reserves the right to change specifications without notice.
Doc. No. 5SYA1171-00 Dec. 03
page 5 of 6
5SDD 54N4000
Fig. 10 Outline drawing. All dimensions are in millimeters and represent nominal values unless stated otherwise.
Related application notes:
Doc. Nr
Titel
5SYA 2020
5SYA 2029
5SYA 2036
Design of RC-Snubbers for Phase Control Applications
Designing Large Rectifiers with High Power Diodes
Recommendations regarding mechanical clamping of Press Pack High Power Semiconductors
Please refer to http://www.abb.com/semiconductors for actual versions.
ABB Switzerland Ltd, Semiconductors reserves the right to change specifications without notice.
ABB Switzerland Ltd
Semiconductors
Doc. No. 5SYA1171-00 Dec. 03
Fabrikstrasse 3
CH-5600 Lenzburg, Switzerland
Telephone +41 (0)58 586 1419
Fax
+41 (0)58 586 1306
Email
Internet
abbsem@ch.abb.com
www.abb.com/semiconductors
