2W005 thru 2W10
REVERSE VOLTAGE - 50 to 1000Volts
FORWARD CURRENT - 2.0 Amperes
SILICON BRIDGE RECTIFIERS
WOB
.366(9.3)
.350(8.9)
FEATURES
.220(5.6)
.200(5.1)
●Surge overload rating -60 amperes peak
●Ideal for printed circuit board
●Reliable low cost construction utilizong molded plastic
technique results in expensive product
●Mounting position :Any
1.1
1.0
(27.9)
(25.4)
MIN
●Lead: Sliver plated copper lead
MIN
.032(0.81)
.028(0.71)
POS.
LEAD
.220(5.6)
.180(4.6)
.220(5.6)
.180(4.6)
SPACING
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating at 25℃ ambient temperature unless otherwise specified.
Single phase, half wave ,60Hz, resistive or inductive load.
For capacitive load, derate current by 20%
SYMBOL
UNIT
CHARACTERISTICS
Maximum Recurrent Peak Reverse Voltage
2W005
50
2W01
100
2W02
200
2W04
400
2W06
600
2W08
800
2W10
1000
VRRM
VRMS
VDC
V
V
V
Maximum RMS Voltage
35
50
70
140
200
280
400
420
600
560
800
700
Maximum DC Blocking Voltage
100
1000
Maximum Average Forward Rectified Current
I(AV)
2.0
A
0.375″（9.5mm) Lead Lengths
Peak Forward Surage Current ,
@TA=25 ℃
IFSM
60
A
8.3ms Single Half Sine-Wave
Super Imposed on Rated Load (JEDEC Method)
I2t Rating for Fusing (t＜8.3ms)
Maximum Forward Voltage Drop
Per Element at 2.0A Peak
I2t
A2s
V
15.0
1.1
VF
Maximum DC Reverse Current at Rated
DC Blocking Voltage
TA=25℃
TA=100℃
10.0
1.0
30
uA
IR
mA
Typical Junction Capacitance Per Element (Note1)
Operating Temperature Range
CJ
TJ
pF
℃
℃
-55 to +125
-55 to +125
Storage Temperature Range
TSTG
Note:1.Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
