2A Glass Passivated
Bridge Rectifier
2W005G – 2W10G
2A Glass Passivated Bridge Rectifier
Features
• Glass passivated chip junction
• High case dielectric strength
• Typical IR less than 0.5µA
• High surge current capability
• Ideal for printed circuit boards
WOG
• High temperature soldering guaranteed: 260˚C/10 seconds
0.375” (9.5mm) lead length at 5lbs.(2.3kg) tension
• This series is UL recognized under component index,
File number E194718
• RoHS compliant
Mechanical Data
Case:
Terminals:
Polarity:
Weight:
WOG, Epoxy meets UL 94V-0 flammability rating
Plated leads solderable per MIL-STD-750, Method 2026
As marked on case
0.04 ounce, 1.1 grams
Maximum Ratings And Electrical Characteristics (Tamb=25˚C)
2W
005G
2W
01G
2W
02G
2W
04G
2W
06G
2W
08G
2W
10G
Symbols
Parameter
Unit
Conditions
Maximum Repetitive Peak
Reverse Voltage
50
100
200
400
600
800
1000
V
VRRM
Maximum RMS Voltage
35
50
70
140
200
280
400
420
600
560
800
700
V
V
VRMS
VDC
Maximum DC Blocking Voltage
100
1000
Maximum Average Forward
Rectified Current at 0.375”
(9.5mm) lead length
2.0
A
I(AV)
8.3ms Single
Sine-wave
Superimposed
on Rated Load
(JEDEC
Peak Forward Surge Current
Rating for Fusing (t<8.3ms)
60
15
A
IFSM
I²t
Method)
A²sec
TAITRON COMPONENTS INCORPORATED www.taitroncomponents.com
Rev. A/AH 2008-01-22
Page 1 of 4
