TDA0161
ABSOLUTE MAXIMUM RATINGS
Symbol
Parameter
Value
35
Unit
V
oC
oC
VCC
Tj
Supply Voltage
Junction Temperature
Storage Temperature Range
+150
Tstg
–55 to +150
ELECTRICAL CHARACTERISTICS
TDA0161DP
TDA0161FP
-40oC < Tamb < +100oC
-40oC < Tamb < +100oC
Ptot < 150mW, unless otherwise specified
Symbol
Parameter
Min.
Typ.
Max.
Unit
V
VCC
Supply Voltage
4
35
Reverse Voltage Limitation (ICC = -100 mA)
Supply Current, Close Target (Tamb = +25oC)
+4V < VCC < +35V
TDA0161
TDA0161
TDA0161
1
V
ICC
ICC
mA
8
10
12
1
Supply Current, Remote Target
+4V < VCC < +35V
mA
Supply Current Transition Time
µs
C3 = 0
1
C3 ≠ 0
(100 x C3 (nF))
fosc
fO
Oscillator Tuning Frequency
Output Frequency (C3 = 0)
10
10
20
MHz
kHz
µA
0
∆ICC
Rn
Output Current Ripple - C3 = 0, C2 (pF) > 150/fosc (MHz)
Negative Resistance on Terminals A and E
4kΩ < R1 < 50kΩ, fosc< 3 MHz
0.9 R1
0.5
R1
1.1 R1
5
Hyst
Hysteresis at Detection Point C2 (Pf) > 150/fosc (MHz)
%
* If the circuit is used at a frequency higher than 3MHz, it is recommended to connect a capacitor of 100pF between terminals E and D.
OPERATING MODE
supply current will be ICC = 10mA (pins G and D).
The oscillation sustains when loss resistance Rpof
tuned circuit becomes higher than R1. Then, the
supply current will be ICC 1mA(pins G and D).
Between terminals A and E, the integrated circuit
acts like a negative resistance equalto the external
resistor R1 connected between terminals B and H.
The oscillation stops when loss resistance Rp of
tuned circuit becomes smaller than R1. Then, the
Eddy currents inducedby coil L1 in a metallic body,
determine loss resistance Rp.
2/6
