EZWFDU02 data sheet
Device features
IEEE 802.11b compliant
USB 1.1 compliant
USB to A-Type host interface
64-, 128 bit WEP
Frequency Range 2412 to 2484 GHz
USB powered @5.0V
Indoor range of upto 300 feet
over USB.
Outdoor range of upto 1750 feet
over USB.
Supports Device Firmware Upgrade
over USB.
EZWFDU02
Operating Temperature Range of 0° C to
70°C
WLAN 802.11b USB adapter
Product Information Data Sheet
Storage Temperature Range of -20° C to
85°C
November, 2003
Dimension
(30.0mm x 13.3mm x 78.5mm) w/o cradle
General Description
Applications
Ad-Hoc Networking
The EZWFDU02 is a low-cost wireless USB
adapter with USB 1.1 interface. It is capable
of data transfer rates of up to 11 Mbps. It
can operate with other 802.11b WLAN
compliant wireless adapters, access points
and routers.
Infrastructure Networking
The EZWFDU02 USB adapter is based on
the Intersil Prism 3 chipset.
Key Features
Radio
Baseband
14 dBm output power
Receiver sensitivity:
Data Rates of 1-, 2-, 5.5-, 11Mbps
Modulation Techniques supported:
-
-
-
-
-93 dBm @1Mbps
-91 dBm @2Mbps
-88 dBm @5.5Mbps
-85 dBm @11Mbps
-
-
-
-
CCK(11Mbps)
CCK(5.5Mbps)
DQPSK(2Mbps)
DBSK(1Mbps)
39 dB Adjacent Channel Rejection
64-, 128 bit WEP encryption
@8%PER
Copyright © EAZIX, Inc. 2003. All Rights Reserved
1
