2W005G - 2W10G
2.0A GLASS PASSIVATED BRIDGE RECTIFIER
Features
·
·
·
Glass Passivated Die Construction
Diffused Junction
Low Forward Voltage Drop, High Current
Capability
A
·
·
·
·
Surge Overload Rating to 60A Peak
Ideal for Printed Circuit Boards
WOG
Case to Terminal Isolation Voltage 1500V
B
Dim
A
Min
8.84
4.00
27.90
25.40
0.71
4.60
Max
9.86
4.60
¾
Plastic Material: UL Flammability
Classification Rating 94V-0
+
-
·
UL Listed Under Recognized Component
Index, File Number E94661
B
D
C
C
D
¾
E
Mechanical Data
E
0.81
5.60
G
·
·
Case: Molded Plastic
-
All Dimensions in mm
Terminals: Plated Leads Solderable per
MIL-STD-202, Method 208
+
G
·
·
·
·
Polarity: As marked on Body
Weight: 1.3 grams (approx.)
Mounting Position: Any
G
Marking: Type Number
@ TA = 25°C unless otherwise specified
Maximum Ratings and Electrical Characteristics
Single phase, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
2W
005G
2W
01G
2W
02G
2W
04G
2W
06G
2W
08G
2W
10G
Characteristic
Symbol
Unit
VRRM
VRWM
VR
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
50
35
100
70
200
140
400
600
420
800
560
1000
700
V
VR(RMS)
IO
RMS Reverse Voltage
280
2.0
V
A
Average Rectified Output Current
Non-Repetitive Peak Forward Surge Current
@ TA = 25°C
IFSM
8.3ms Single half sine-wave superimposed on rated load
per element (JEDEC Method)
60
A
Forward Voltage (per element)
@ IF = 2.0A
VFM
IRM
1.1
V
Peak Reverse Current
at Rated DC Blocking Voltage
@ TA = 25°C
@ TA = 125°C
5.0
500
mA
Cj
Typical Junction Capacitance
(Note 2)
16
40
pF
°C/W
°C
RqJC
Typical Thermal Resistance Junction to Case
Operating and Storage Temperature Range
Tj, TSTG
-65 to +150
Notes:
1. Thermal resistance from junction to case mounted on PC board with 13 x 13mm (0.03mm thick) land areas.
2. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
DS21204 Rev. G-2
1 of 2
2W005G - 2W10G
