F-213 SUPPLEMENT
SC–8P1–GT
SC–1P4–GG
SC, EZ SERIES
STANDARD, LOW PROFILE & SMT SOCKETS
Specifications:
SC–ꢁP1–
SC–3P1
SC-1P4
Contact:
BeCu
Shell:
Brass
-GG Plating:
(1,83)
.072
DIA
20µ" (0,51 µm) Au over 50µ"
(1,27 µm) Ni on contact
-GT Plating:
(1,83)
.072 DIA
20µ" (0,51 µm) Au over 50µ"
(1,27 µm) Ni on contact
Current Rating:
5A per contact
(2,41)
.095
(3,10)
.122
(0,51)
.020
(1,32)
.052
DIA
(0,76)
.030
(4,83)
.190
(5,84)
.230
Contact Resistance:
10 mΩ
(1,32)
.052
DIA
Insertion Force:
6.5oz (1,81 N) avg,
13oz (3,62 N) max
(.032" (0,81 mm) DIA probe)
Withdrawal Force:
3oz (0,83 N) avg,
2oz (0,56 N) min
(.032" (0,81 mm) DIA probe)
(0,76)
.030
DIA
(0,76)
.030
DIA
Insertion Depth = .080" to .150" (2,03 mm to 3,81 mm)
Lead DIA Accepted: .016" to .020" (0,41 mm to 0,51 mm)
Plating Available = GG, GT, TT
Insertion Depth = .105" to .170" (2,67 mm to 4,32 mm)
Lead DIA Accepted: .015" to .020" (0,38 mm to 0,51 mm)
Plating Available = GG, GT, TT
SC–4P1–, EZ–4P1–
(1,83)
.072
DIA
SC–1P4–
(3,35)
.132
(0,51)
.020
(6,10)
.240
(1,32)
.052
DIA
(2,28)
.090
DIA
(0,76)
.030
(0,51)
.020
DIA
Insertion Depth = .080" to .105" (2,03 mm to 2,67 mm)
Lead DIA Accepted: .016" to .021" (0,41 mm to 0,53 mm)
Plating Available = GG, GT, TT
(0,71)
.028
(2,18)
(9,53)
.086
DIA
.375
SC–8P1–
(1,83)
.072
DIA
(1,98)
.078
DIA
(3,18)
.125
(2,11)
.083
(0,76)
.030
DIA
(0,25)
.010
(4,19)
.165
(1,32)
.052
DIA
(0,74)
.029 DIA
Note:
Insertion Depth = .175" to .215" (4,45 mm to 5,46 mm)
Lead DIA Accepted = .032" to .038" (0,81 mm to 0,97 mm)
Plating Available = GG, GT
Insertion Depth = .085" to .140" (2,16 mm to 3,56 mm)
Lead DIA Accepted: .016" to .020" (0,41 mm to 0,51 mm)
Plating Available = GG, GT, TT
Some sizes, styles and
options are non-standard,
non-returnable.
WWW.SAMTEC.COM
