ADVANCE TECHNICAL INFORMATION
Trench Power MOSFET IXUC 120N10
V
I
= 100 V
= 120 A
= 9.5 mΩ
DSS
ISOPLUS220TM
D25
Electrically Isolated Back Surface
R
DS(on)
ISOPLUS 220TM
Symbol
Test Conditions
Maximum Ratings
G
D
S
VDSS
VGS
TJ = 25°C to 150°C
100
V
V
Continuous
±20
Isolated back surface*
D = Drain,
ID25
ID90
IS25
IS90
ID(RMS)
EAS
TC = 25°C; Note 1
TC = 90°C, Note 1
120
90
A
A
G = Gate,
S = Source
* Patent pending
TC = 25°C; Note 1, 2
TC = 90°C, Note 1, 2
120
90
A
A
Package lead current limit
TC = 25°C
45
A
tlbmJ
W
Features
l Silicon chip on Direct-Copper-Bond
substrate
- High power dissipation
- Isolated mounting surface
- 2500V electrical isolation
l Trench MOSFET
- very low RDS(on)
- fast switching
- usable intrinsic reverse diode
l Low drain to tab capacitance(<15pF)
l Unclamped Inductive Switching (UIS)
rated
PD
TC = 25°C
300
TJ
-55 ... +175
175
°C
°C
°C
TJM
Tstg
-55 ... +150
TL
1.6 mm (0.062 in.) from case for 10 s
RMS leads-to-tab, 50/60 Hz, t = 1 minute
Mounting force
300
°C
VISOL
FC
2500
V~
11 ... 65 / 2.4 ...11 N/lb
Weight
2
g
Applications
l Automotive 42V systems
- electronic switches to replace relays
and fuses
- choppers to replace series dropping
resistors used for motors, heaters, etc.
- inverters for AC drives, e.g. starter
generator
Symbol
RDS(on)
Test Conditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
- DC-DC converters, e.g. 12V to 42V, etc.
l Power supplies
- DC - DC converters
min. typ. max.
- Solar inverters
VGS = 10 V, ID = 90 A, Note 3
VGS = 10 V, ID = ID90
7.3
18
9.5 mΩ
mΩ
l Battery powered systems
- choppers or inverters for motor control
in hand tools
,
TJ = 125°C Note 3
- battery chargers
VGS(th)
IDSS
VDS = VGS, ID = 2 mA
2
4
V
Advantages
l Easy assembly: no screws or isolation
foils required
l Space savings
l High power density
VDS = VDSS
VGS = 0 V
TJ = 25°C
TJ = 125°C
20 µA
mA
0.2
IGSS
VGS = ±20 VDC, VDS = 0
±200 nA
98901 (2/02)
© 2002 IXYS All rights reserved
