DSS 6-0045AS
IFAV = 6 A
VRRM = 45 V
VF = 0.5 V
Power Schottky Rectifier
TO-252 AA
A
C
VRSM
V
VRRM
V
Type
marking
on product
A
A
45
45
DSS 6-0045AS
6Y045AS
C (TAB)
A = Anode, C = Cathode , TAB = Cathode
Symbol
Conditions
Maximum Ratings
Features
• International standard package
• Very low VF
• Extremely low switching losses
• Low IRM-values
• Epoxy meets UL 94V-0
IFRMS
IFAV
20
6
A
A
TC = 165°C; rectangular, d = 0.5
IFSM
TVJ = 45°C; tp = 10 ms (50 Hz), sine
IAS = 13 A; L = 180 µH; TVJ = 25°C; non repetitive
VA =1.5 • VRRM typ.; f=10 kHz; repetitive
80
24
A
mJ
A
EAS
IAR
1.3
Applications
• Rectifiers in switch mode power
supplies (SMPS)
• Free wheeling diode in low voltage
converters
(dv/dt)cr
1000
V/µs
TVJ
TVJM
Tstg
-55...+175
175
-55...+150
°C
°C
°C
Ptot
TC = 25°C
50
W
g
Advantages
• High reliability circuit operation
• Low voltage peaks for reduced
protection circuits
Weight
typical
0.3
• Low noise switching
• Low losses
Symbol
IR ꢀ
VF
Conditions
Characteristic Values
typ.
max.
TVJ = 25°C VR = VRRM
TVJ = 125°C VR = VRRM
0.3
2.5
mA
mA
Dimensions see Outlines.pdf
IF = 6 A;
IF = 6 A;
IF = 12 A;
TVJ = 125°C
TVJ 25°C
TVJ = 125°C
0.50
0.63
0.59
V
V
V
=
RthJC
3.0
K/W
Pulse test: ꢀPulse Width = 5 ms, Duty Cycle < 2.0 %
Data according to IEC 60747 and per diode unless otherwise specified
IXYS reserves the right to change limits, Conditions and dimensions.
© 2003 IXYS All rights reserved
1 - 2
