1SS422_15

型号:

1SS422_15

品牌:

WINNERJOIN[ SHENZHEN YONGERJIA INDUSTRY CO.,LTD ]

页数:

2 页

PDF大小:

137 K

RoHS
1SS422
1SS422 High Speed SWITCHING Diodes
1.20
1.60
0.80
0.30
FEATURES
Small surface mounting type
High Speed
z
z
z High reliability with high surge current handing capability
0.10
0.65
MARKING: 6
SOD-523
Maximum Ratings and Electrical Characteristics, Single Diode @TA= 25
Parameter
Peak reverse voltage
DC reverse voltage
Symbol
VRM
VR
Limits
100
85
Unit
V
V
Peak forward current
Mean rectifying current
IFM
500
150
mA
mA
IO
Junction temperature
Storage temperature
Tj
125
Tstg
-55~+125
Electrical Ratings @TA= 25℃
Parameter
Symbol Min. Typ. Max. Unit
Conditions
IF=150mA
Forward voltage
VF
IR
1.2
0.1
3.0
V
Reverse current
VR=85V
µA
pF
Capacitance between terminals
CT
VR=0.5V, f=1MHZ
WEJ ELECTRONIC CO.,LTD
Reverse recovery time
trr
4
ns
VR=6V,IF=10mA,RL=100Ω
Http:// www.wej.cn
E-mail:wej@yongerjia.com
WEJ ELECTRONIC CO.
RoHS
1SS422
WTD
Http:// www.wej.cn
E-mail:wej@yongerjia.com
WEJ ELECTRONIC CO.
