GXO-L72L 2/5
SPECIFICATIONS
PACKAGE DRAWING
Frequency range
Dimensions
Storage
80.0 ~ 200MHz
7.0 x 5.0 x 1.65mm
-40 to +85°C
temperature range
Supply voltage
(VDD)
+3.3V (±5%)
Supply current
Output
70mA max, 50mA typ
LVDS
Offset voltage
1.25V typ
Differential output 0.33V typ
voltage
Output load
Logic levels
100Ω
‘0’ level = 0.9V max
‘1’ level = 1.6V min
10ms max
Start up time
Waveform
symmetry
45:55 max @ 50%VP-P
Rise / fall time
Output enable /
disable time
1.0ns max (20 ~ 80%VP-P)
2ms / 200ns max
Stand-by current 30µA max
Phase jitter RMS 1ps max (0.3ps typ), 12kHz~20MHz
ORDERING INFORMATION
ENABLE / DISABLE FUNCTION
To request a quotation for the GXO-L72L please use the
configurable options form to choose the options you require
and then submit your configured product to our team. Our
expert advisers are always happy to help with your
requirements and can be contacted on +44 1460 256 100 or
at sales@golledge.com.
Input (pad
1)
Output 1
(pad 4)
Output 2
(pad 5)
Open
Enabled
Enabled
Enabled
Enabled
'1' level (≥0.7
VDD)
Following product selection you will be issued with a seven
character Golledge part number. Your Golledge part number is
the internationally accepted Golledge manufacturing part
number (MPN) that should be used for all project
documentation, including bills of materials (BoMs) and
purchase orders.
'0' level (≤0.3
VDD)
High
Impedanceive
High Impedance
If you have any queries regarding any of our documentation
our dedicated sales team will be happy to help.
v1.0
