Pin Connections
Package Characteristics
Package
Shock
CO-8 footprint, resistive welded package with grounded case.
PinꢀꢀꢀꢀConnection
ꢀ 1:ꢀꢀꢀꢀꢀVoltageꢀControlꢀ(Vc)
ꢀ 2:ꢀꢀꢀꢀꢀN/C
ꢀꢀ3:ꢀꢀꢀꢀꢀSupplyꢀVoltageꢀ(Vcc)
ꢀꢀ4:ꢀꢀꢀꢀꢀRFꢀOutput
ꢀꢀꢁ:ꢀꢀꢀꢀꢀGroundꢀ(Case)
Environmental Characteristics
500 G’s 1ms, Halfsine, 3 shocks per direction, per MIL-
STD 202F, Method 213B Test Condition D.
0.06” D.A. or 10G’s Peak, 10 to 500 Hz, per MIL-STD-
202F, Method 204D, Test Condition A.
5.35 G’s rms. 20 to 2000 Hz per MIL-STD-202F, Method
214,Test Condition 1A, 15 minutes each axis.
10 cycles, 95% RH, Per MIL-STD-202F, Method 112.
Per MIL-STD-202F, Method 215J.
Sinusoidal Vibration
Random Vibration
Solder Profile
Temperature
260°C
260°C
Moisture
Marking Permanency
Attachment Method PCB
220°C
180°C
150°C
120°C
Through Hole Mounted
Resistance to Solder Heat Per MIL-STD-202F, Method 210, Condition E.
Solder Process
RoHS compliant, lead free. See solder profile.
0
Notes:
10 s
1. At time of shipment after 60 minutes of operation, @25°C, Vc = 2.5 Vdc.
2. Frequency stability vs. change in temperature [± ±FmaꢀxFminꢁ)±2ꢂFoꢁꢃ.
3. 5 years from time of shipment after 72 hours of operation and Vc = 2.5 Vdc.
Up to 120 s
60 to 90 s
Typical
Typical
Meets IPC/JEDEC J-STD-020C
Package Outline
Test Circuit
0.530
Max.
13.46mm
0.035 Dia.
0.88mm Dia.
0.197
Vcc
N/C
Vc
Output
12 Vdc
5.0mm Max.
.01 uF
15 pF
1.417
Ground
36mm
5
1
2
3
1.063
27mm
0.700
Bottom View
4
0.350
8.9mm
17.78mm
Marking Diagram
0.700
17.78mm
1.000
25.4mm
1237
Date Code (YYWW)
OX200-SC
Model Number
Output Frequency
Serial # Barcode
Serial Number
10.0 MHz
123456789012
123456789012
Pin 1
Revision History
Description
New issue
Ordering Information
Revisionꢀ
Dateꢀ
00
01
02
03
04
05
11/12/09
11/30/10
04/05/12
09/18/12
04/10/13
11/19/13
OX200-SC - 010.0M
Added aging 5 years
Changed from 3ppb absolute to +/-1.5ppb
Updated marking information
Changed HCMOS to LVCMOS
Added Voltage Control
OCXO
SERIES
CENTER
FREQUENCY
Bulletin
Page
Cx194
2 of 2
Revision
Date
05
19 Nov 2013
