Bidirectional Converters
EZA11K-320240New
Product
Sales Region
Series
Worldwide
EZA
Status
Production
Option
Option Lineup
Recommended EMC Filter
Accessories
Please refer to the catalog
Electrical Characteristics
240V
LV Side Rated Voltage[DC]
LV Side Voltage Range[DC]
HV Side Rated Voltage[DC]
HV Side Voltage Range[DC]
Maximum Output Power
150 to 300V
320V
240 to 400V
11kW
Efficiency(at rated input/output)
Maximum Efficiency
95% Typ.
95% Typ.
Cases Shape & Size
Case’ shape
Width(W)
Height(H)
Depth(D)
Weight
1U (19inch full rack)
422.8mm Nom.
43.6mm Nom.
530mm Nom.
20kg Max.
Other
Operating Temp. Range
-10 to 50°C
RS485 (original protocol)
Insulation
External Control
Isolation/non-Isolation(input-output)
Parallel Operation
Yes
Change of Power Conversion Direction
Safety Standard(Certified)
external control operation/self-communicating operation selectable
This page only shows representative characteristics. Please refer to the
technical data for detailed specifications and conditions.
