Applications
OV7735
¬
Gaming
¬
¬
Portable Media Players
Webcams
¬
DVR
Ordering Information
¬
OV07735-A42A
(color, lead-free, 42-pin CSP3)
¬
OV07735-G04A
(color, chip probing, 200 µm
backgrinding, reconstructed wafer)
Product Features
¬
ultra high performance
¬
¬
standard serial SCCB interface
¬
automatic image control functions:
- automatic exposure control (AEC)
- automatic gain control (AGC)
digital video port (DVP) parallel output
interface
- automatic white balance (AWB)
- automatic band filter (ABF)
- automatic 50/60 Hz luminance detection
- automatic black level calibration (ABLC)
¬
¬
MIPI serial output interface
Product Specifications
embedded one-time programmable
(OTP) memory for part identification,
etc.
¬
active array size: 640 x 480
¬
maximum image transfer rate:
- VGA: 60 fps
¬
power supply:
- QVGA: 120 fps
- QQVGA: 120 fps
¬
¬
programmable controls for frame rate,
mirror and flip, scaling, cropping, and
windowing
- core: 1.5 VDC ±5% (internal regulator)
- analog: 2.6 ~ 3.0 V
¬
¬
¬
on-chip phase lock loop (PLL)
programmable I/O drive capability
built-in 1.5V regulator for core
- I/ O: 1.7 ~ 3.0 V
¬
¬
¬
sensitivity: 3300 mV/lux-sec
scan mode: progressive
image quality controls: color saturation,
hue, gamma, sharpness (edge
enhancement), lens correction,
defective pixel canceling, and noise
canceling
¬
¬
¬
power requirements:
- active: 100 mW
- standby: 76 µW
maximum exposure interval:
508 x tROW
temperature range:
- operating: -30° C to 70° C
- stable image: 0° C to 50° C
¬
¬
¬
¬
pixel size: 3 µm x 3 µm
¬
¬
¬
support for output formats: 8/10-bit
RAW RGB, CCIR656 and YUV422
-
well capacity: 11 Ke
output formats: 8/10-bit RAW RGB,
8-bit YUV
support for horizontal and
vertical sub-sampling
dark current: 10 mV/s at 60°C
¬
¬
¬
¬
¬
lens size: 1/7.5"
fixed pattern noise:
1% of VPEAK-TO-PEAK
support for images sizes: VGA and any
arbitrary size scaling down from VGA
lens chief ray angle: 26.5°
input clock frequency: 6 ~ 27 MHz
S/ N ratio: 38 dB
¬
¬
image area: 1968 µm x 1488 µm
¬
¬
support for binning
package dimensions:
- CSP3: 3985 µm x 3635 µm
- COB: 4000 µm x 3650 µm
support for external frame
synchronization
dynamic range: 68 dB
Functional Block Diagram
OV7735
image sensor core
sensor
image output
interface
processor
column
sample/hold
D[9:0]
10-bit
ADC
array
AMP
MCP/N
MDP/N
50/60 Hz
gain
auto detection
control
control register bank
SCCB slave interface
PLL2 PLL1 timing generator and system control logic
