Applications
OV9762
¬
Cellular Phones
¬
¬
Digital Video Camcorders (DVC)
PC Multimedia
¬
Digital Still Cameras (DSC)
Ordering Information
¬
OV09762-G04A
Product Features
(color, chip probing, 200 µm backgrinding, reconstructed wafer with good die)
¬
OV09762-G05A
¬
automatic black level calibration (ABLC)
¬
¬
standard serial SCCB interface
(color, chip probing, 150 µm backgrinding, reconstructed wafer with good die)
¬
programmable controls for frame rate,
mirror and flip, cropping and windowing
supports MIPI data transfer rate
of up to 1 Gbps
¬
¬
¬
¬
image quality controls:
defective pixel canceling
¬
¬
one-lane MIPI serial output interface
with slew rate control
Product Specifications
supports output formats:
10-bit RAW RGB MIPI
embedded 8K bits one-time
programmable (OTP) memory
for part identification, etc.
¬
active array size: 1376 x 960
¬
¬
¬
¬
input clock frequency: 6 ~ 27 MHz
max S/N ratio: 38.6 dB
supports horizontal and
vertical subsampling
¬
power supply:
¬
¬
¬
¬
¬
two on-chip phase lock loop (PLL)
programmable I/O drive capability
built-in 1.2V regulator for core
built-in temperature sensor
- core: 1.08 ~ 1.32V
- analog: 2.7 ~ 3.0V
- I/O: 1.62 ~ 1.98V
dynamic range: 73 dB @ 16x gain
supports images sizes: 1376x960,
688x480, 344x240
maximum image transfer rate:
- 1376 x 960: 30 fps
- 688 x 480: 60 fps
- 344 x 240: 120 fps
¬
¬
power requirements:
- IDD-A: 23 mA
¬
¬
fast mode switching
support 2x2 binning
- IDD-IO: 37 mA
- XSHUTDOWN: 5 µA
ambient light sensor (ALS) mode
¬
¬
¬
¬
¬
sensitivity: 1450 mV/lux-sec
scan mode: progressive
temperature range:
- operating: -40°C to 85°C junction
temperature
- stable image: -15°C to 65°C junction
temperature
maximum exposure interval: 1000 x tROW
pixel size: 1.87 µm x 1.87 µm
¬
¬
¬
output formats: 10-bit RAW RGB data
lens size: 1/5.7"
-
dark current: 31 e /sec
@ 60°C junction temperature
lens chief ray angle: 28.1°
¬
image area: 2618 µm x 1840.08 µm
Functional Block Diagram
OV9762
image sensor array
output
interface
sensor
column
sample/hold
processor
MCP/N
MDP/N
AMP
10-bit
ADC
array
gain control
control register bank regulator
SCCB slave interface
PLL
system control logic
timing generator
