Applications
OV7251
¬
¬
¬
Cellular Phones
¬
¬
¬
PC Multimedia
Tablets
Digital Still Cameras (DSC)
Digital Video Camcorders (DVC)
Wearable Devices
Ordering Information
¬
OV07251-A35A-1J
(B&W, lead-free, 35-pin CSP)
¬
OV07251-G04A-1G
(B&W, chip probing, 200 µm
backgrinding, reconstructed wafer
with good die)
Product Features
¬
3 µm x 3 µm pixel
¬
¬
¬
¬
supports 2x2 monochrome binning
one-lane MIPI serial output interface
one-lane LVDS serial output interface
with OmniPixel3-GS™ technology
¬
¬
automatic black level calibration (ABLC)
Product Specifications
programmable controls for:
- frame rate
- mirror and flip
- cropping and windowing
embedded 256 bits of one-time
programmable (OTP) memory
for part identification
¬
active array size: 640 x 480
¬
¬
¬
¬
¬
input clock frequency: 6 ~ 27 MHz
lens chief ray angle: 29° non-linear
max S/N ratio: 39 dB
¬
power supply:
¬
¬
support output formats: 8/10-bit RAW
¬
¬
¬
¬
two on-chip phase lock loops (PLLs)
built-in 1.5V regulator for core
PWM
- core: 1.5V (optional)
- analog: 2.8V (nominal)
- I/O: 1.8V (nominal)
support for image sizes:
- 640 x 480
- 320 x 240
- 160 x 120
dynamic range: 69.6 dB @ 8x gain
¬
power requirements:
- active: 119 mW @ 120 fps, VGA output
- standby: 15 µA for AVDD,
maximum image transfer rate:
- 640x480: 120 fps
built-in strobe control
¬
¬
fast mode switching
40 µA for DOVDD without input clock,
700 µA for DOVDD with input clock
- XSHUTDOWN: 5 µA for AVDD,
5 µA for DOVDD
¬
sensitivity: 10,800 mV/(µW.cm-2.sec)
supports horizontal and vertical 2:1
and 4:1 monochrome subsampling
@ 850 nm
¬
¬
¬
¬
scan mode: progressive
¬
¬
temperature range:
- operating: -30°C to +70°C junction
temperature
- stable image: 0°C to +50°C junction
temperature
maximum exposure interval: 502 x tROW
pixel size: 3 µm x 3 µm
-
dark current: 80 e /sec
output interface: 1-lane MIPI/LVDS
serial output
@ 50°C junction temperature
¬
¬
image area: 1968 µm x 1488 µm
¬
¬
output formats: 10-bit B&W RAW
lens size: 1/7.5"
package dimensions:
- CSP: 3910 µm x 3410 µm
- COB: 3900 µm x 3400 µm
- RW: 3950 µm x 3450 µm
Functional Block Diagram
OV7251
image sensor array
output
interface
column
sample/hold
MCP/N
MDP/N
array
10-bit
ADC
AMP
gain
control
control register bank
SCCB slave interface
regulator
PLL system control logic
timing generator
