Crystal Clock Oscillator
NZ3225SH
Standard Type
Application
■
For Automotive navigation system, Automotive audio equipment and Camera
For Smartphone, Tablet computers, Notebook PC, PC card, etc.
For Audioequipment and Wireless module
For Communication equipment for SDH/SONET, WiMAX, LTE, etc. and Base station
Features
■
● Supports a wide temperature range from –40 to +125°C.
● Compact and light. Dimensions : 3.2 x 2.5 x 0.9 mm, weight : 0.02 g.
● This crystal clock oscillator can support low frequencies (from 1.5MHz) not easily
achieved with crystal units of the same size.
● Taped units enable automatic mounting IR Reflow (lead free) is possible.
● Lead-free.
Absolute maximum rating
Supply Voltage (VCC) –0.3 to +4.0 V
Storage Temperature Range –55 to +125 °C
Specifications
■
Model
NZ3225SH
Item
Output Specification
CMOS
Nominal Frequency Range
Overall Frequency Tolerance
Operating Temperature Range
Supply Voltage
(MHz)
×10–6
1.5 ≤ F ≤ 80
(
)
±100
±50
±50
–40 to +85
+1.8 to +3.3
2.5 to 9.0
20
±30
±20
(°C)
(V)
–40 to +125
–40 to +105
–10 to +70
–10 to +60
Current
During Operation +25 °C
(mA)
(μA)
(V)
Consumption
Max.
During Standby
+25 °C
VOL Max. / VOH Min.
0.1 VCC / 0.9 VCC
+1.8 V
6 / 6 ( at 0.1 VCC to 0.9 VCC )
Tr Max. / Tf Max.
(ns)
+2.5 to +3.3V
5 / 5 ( at 0.1 VCC to 0.9 VCC )
Symmetry Min. to Max.
Load (CL) Max.
(%)
(pF)
(ms)
45 to 55
15
Start-up Time Max.
Standby function
4
Available (Three-state)
Dimensions
Output Waveform <CMOS>
■
■
mm
3.2 0.1
Tf
Tr
Terminal land connections
#4
#3
VOH
#1 STAND-BY #3 OUTPUT
0.9VCC
#2
GND
#4
VCC
1/2VCC
0.1VCC
#1
#2
VOL
(0.6)
0V
t
T
1.2 0.1
C0.3
Land pattern (Typical)
1.2
Symmetry = t/T × 100 [%]
#1
#2
#3
#3
#4
Standby Function
■
#4
0.9
1.0
#1 Input
#3 Output
Level H (0.7 VCC ≤ VIH ≤ VCC)
or OPEN is selected.
#1
#2
2.2
Oscillation output ON
High impedance
Cby=0.01μF
Mount an approx. 0.01μF bypass capacitor between VCC and GND (close to the product).
Level L (VIL ≤ 0.3 VCC) is selected.
