ZOWIE
Bridge Rectifier
(600V~1000V / 2A)
WZ4GP20JLH THRU WZ4GP20MLH
OUTLINE DIMENSIONS
Case : Z4PAK
FEATURES
Unit : mm
*
*
*
*
*
*
*
Halogen-free type
Internal structure with GPRC (glass passivated rectifier chip) inside
Compliance to RoHS product
Mounting Pad Layout
4.10 ± 0.1
5.30 ± 0.1
3.30 ± 0.05
Lead less chip form, no lead damage
Low power loss, High efficiency
High current capability
Plastic package has Underwriters Laboratory Flammability
Classification 94V-0
~
~
*
Patented ZPAKTM Package Technology
1.10 ± 0.1
0.90 ± 0.05
1.20 ± 0.15
4
1
APPLICATION
*
*
AC/DC Power Supply
Communication Equipment
3
2
MECHANICAL DATA
MARKING
Case : Packed with FRP substrate and epoxy underfilled
Terminals : Pure Tin plated (Lead-Free),
solderable per MIL-STD-750, Method 2026.
Polarity : Laser marking symbols
Z4GP = Series code
20 = Amps class (2.0A)
J = Voltage class
J = 600V
Z4GP
20JL
YWW .
Weight : 0.11 gram
K = 800V
~
~
M = 1000V
L = Low VF
.
= Halogen-free type
PACKING
Y = Last digit of the year
0 = 2010
1 = 2011
WW = Mfg week
01 = First week
*
*
*
5,000 pieces per 13" (330mm ± 2mm) reel
2 reels per box
02 = Second week
03 = Third week
2 = 2012
5 boxes per carton
Absolute Maximum Ratings (Ta = 25 oC)
ITEM
Rating
Symbol
Conditions
Unit
WZ4GP20JLH WZ4GP20KLH WZ4GP20MLH
Repetitive peak reverse voltage
Average forward current
VRRM
IF(AV)
600
800
2.0
60
1000
V
A
A
Peak forward surge current
IFSM
8.3ms single half sine-wave
Operating junction and storage temperature Range
Tj,TSTG
-55 to +175
oC
Electrical characteristics (Ta = 25 oC)
ITEM
Symbol
Conditions
Min.
Typ.
Max.
Unit
Forward voltage
VF
IF = 2.0A
-
0.92
0.95
V
Repetitive peak reverse current
IRRM
I2t
VR = Max. VRRM , Ta = 25 oC
t < 8.3ms , Ta = 25 oC
-
-
0.08
14.9
2
uA
-
A2s
pF
Current squared time
Junction capacitance
Cj
-
-
-
-
VR = 4V, f = 1.0 MHz
35
80
Rth(JA)
Junction to ambient (NOTE)
oC/W
Thermal resistance
Rth(JL)
Junction to lead (NOTE)
-
20
-
NOTES :
Mounted on P.C.B. with 1.5 x 1.0mm copper pads.
REV. 1
2012/06
