Part Number:
Status:
0989821021
Active
MOX Products
Overview:
Description:
2.54mm Pitch MOX Receptacle Kit, 4 Rows, 40 Circuits, Black
Documents:
3D Model
Drawing (PDF)
Application Specification AS-98982-001-001 (PDF)
RoHS Certificate of Compliance (PDF)
General
Product Family
Series
Series image - Reference only
Crimp Housings
98982
Application
Power, Wire-to-Board
63813-8300
63813-8400
MOX Products
MOX
EU ELV
Compliant
Application Tooling Part Link
Application Tooling Part Link
Overview
Product Name
UPC
EU RoHS
Compliant
China RoHS
REACH SVHC
Not Contained Per
-ED/01/2018 (15
January 2018)
Halogen-Free
Status
822348817245
Physical
Circuits (maximum)
Circuits Detail
40
40
Black
Color - Resin
Gender
Receptacle
Not Relevant
Glow-Wire Capable
Keying to Mating Part
Lock to Mating Part
Material - Resin
Net Weight
Number of Rows
Packaging Type
Panel Mount
Pitch - Mating Interface
Pitch - Termination Interface
Polarized to Mating Part
Ports
No
None
Yes
Polyester
8.350/g
4
Bag
No
2.54mm
2.54mm
Yes
1
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
Not Relevant
Compliant
RoHS Phthalates
Not Contained
Stackable
No
Search Parts in this Series
Temperature Range - Operating
-40°C to +125°C
98982 Series
Electrical
Current - Maximum per Contact
Mates With
Please Contact Molex for Details
6.0A
Solder Process Data
Lead-freeProcess Capability
N/A
Use With
98658 MOX Crimp Terminal
Material Info
Engineering Number
52591EV40M1
Reference - Drawing Numbers
Application Specification
Sales Drawing
AS-98982-001-001
SD-98982-002
