Performance Specifications
Table 2. Electrical Performance - 3.3V LVPECL
Parameter
Symbol
Min
Typical
3.3
Maximum
Units
Supply
Voltage1
Current2
VDD
IDD
3.135
3.465
90
V
mA
Frequency
Nominal Frequency3
Absolute Pull Range 2,6, ordering option
Linearity2
fN
77.76
160.00
MHz
ppm
%
APR
Lin
KV
50, 80
5
Gain Transfer2
+80
20
ppm/V
ppm
Temperature Stability
fSTAB
Outputs
Output Logic Levels2
Output Logic High
Output Logic Low
V
VOH
VOL
VDD-1.025
VDD-0.950
VDD-0.880
V
DD-1.810
V
DD-1.700
V
DD-1.620
Rise Time2,4
Fall Time2,4
tR
tF
1
1
ns
ns
Symmetry2
Jitter, RMS 5,8 (12kHz to 20 MHz)
Jitter, RMS 5,8 (10kHz to 1MHz)
SYM
фJ
45
50
55
1
%
0.3
ps
фJ
0.3
ps
Phase Noise8
10Hz
100Hz
dBc/Hz
-60
-93
1kHz
10kHz
100kHz
1MHz
10MHz
-118
-131
-145
-149
-151
Control Voltage
Control Voltage Range for Pull Range
Control Voltage Input Impedance
Control Voltage Modulation BW
Output Enable/Disable9
Output Enabled, Option A
Output Disabled, Option A
VC
ZIN
0.3
10
10
3.0
V
MΩ
kHz
V
BW
VIH
VIL
0.9*VDD
0.1*VDD
10
Start-Up Time
TS
ms
°C
Operating Temp, Ordering Option
Package Size
TOP
0/70, -20/70, -20/85, or -40/85
5.0 x 7.0 x 1.8
mm
1] The power supply should have by-pass capacitors as close to the supply and to ground as possible, for examples 0.1 and 0.01uF
2] Parameters are tested with production test circuit below as shown in Figure 3.
3] See Standard Frequencies and Ordering Information tables for more specific information
4] Measured from 20% to 80% of a full output swing as shown in Figure 4.
5] Not tested in production, guaranteed by design, verified at qualification.
6] Tested with Vc = 0V to 3.3V unless otherwise stated in part description
7] Broadband Period Jitter measured using Wavecrest SIA3300C, 90K samples.
8] Phase Noise is measured with an Agilent E5052A.
9] The Output is Enabled if the Enable/Disable is left open.
