SZSL12T1G

型号:

SZSL12T1G

品牌:

ONSEMI[ ONSEMI ]

页数:

5 页

PDF大小:

95 K

SL05T1G Series
300 Watt, SOT-23 Low
Capacitance TVS for High
Speed Line Protections
This family of TVS offers transient overvoltage protection with
significantly reduced capacitance. The capacitance is lowered by
integrating a compensating diode in series. This integrated solution
offers ESD protection for high speed interfaces such as communication
systems, computers, and computer peripherals.
www.onsemi.com
2
1
3 (NC)
Features
TVS Diode in Series with a Compensating Diode Offers <5 pF
MARKING
DIAGRAM
Capacitance
3
ESD Protection Meeting IEC 61000−4−2, 4−4, 4−5
Peak Power Rating of 300 W, 8 × 20 ms
Lxx M G
1
G
Bi−Direction Protection Can Be Achieved By Using Two Devices
Flammability Rating UL 94 V−0
2
SOT−23 (TO−236)
CASE 318
SZ Prefix for Automotive and Other Applications Requiring Unique
Site and Control Change Requirements; AEC−Q101 Qualified and
PPAP Capable
Lxx = Device Code
xx = 05, 12, 15, or 24
= Date Code*
= Pb−Free Package
STYLE 26
M
G
These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
(Note: Microdot may be in either location)
Compliant
*Date Code orientation and/or overbar may vary
depending upon manufacturing location.
Mechanical Characteristics:
CASE: Void-free, transfer-molded, thermosetting plastic case
FINISH: Corrosion resistant finish, easily solderable
MAXIMUM CASE TEMPERATURE FOR SOLDERING PURPOSES:
260°C for 10 Seconds
Package designed for optimal automated board assembly
Small package size for high density applications
Available in 8 mm Tape and Reel
ORDERING INFORMATION
Device
Package
Shipping
SL05T1G
SOT−23
3000/Tape & Reel
(Pb−Free)
SZSL05T1G
SL12T1G
SOT−23
(Pb−Free)
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
Use the Device Number to order the 7 inch/3,000 unit reel.
Replace the “T1” with “T3” in the Device Number to order the
13 inch/10,000 unit reel.
SOT−23
(Pb−Free)
SZSL12T1G
SOT−23
(Pb−Free)
SL15T1G
SOT−23
(Pb−Free)
3000/Tape & Reel
3000/Tape & Reel
SZSL15T1G
SOT−23
(Pb−Free)
SL24T1G
SOT−23
(Pb−Free)
3000/Tape & Reel
3000/Tape & Reel
SZSL24T1G
SOT−23
(Pb−Free)
†For information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
DEVICE MARKING INFORMATION
See specific marking information in the device marking
column of the table on page 2 of this data sheet.
© Semiconductor Components Industries, LLC, 2001
1
Publication Order Number:
October, 2016 − Rev. 10
SL05T1/D
SL05T1G Series
MAXIMUM RATINGS
Rating
Symbol
Value
Unit
Peak Power Dissipation @ 8x20 usec (Note 1)
P
pk
300
W
@ T 25°C
L
IEC 61000−4−2
Contact Discharge
Air Discharge
IEC 61000−4−4
IEC 61000−4−5
Level 4
V
pp
8
16
40
12
kV
kV
A
EFT
Lightning
A
Total Power Dissipation on FR−5 Board (Note 2) @ T = 25°C
°P °
D
225
1.8
°mW°
mW/°C
A
Derate above 25°C
Thermal Resistance Junction to Ambient
R
556
°C/W
q
JA
Total Power Dissipation on Alumina Substrate (Note 3) @ T = 25°C
°P °
D
300
2.4
°mW
mW/°C
A
Derate above 25°C
Thermal Resistance Junction−to−Ambient
Junction and Storage Temperature Range
Lead Solder Temperature − Maximum (10 Second Duration)
R
417
− 55 to +150
260
°C/W
°C
q
JA
T , T
J
stg
T
°C
L
Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality
should not be assumed, damage may occur and reliability may be affected.
1. Non−repetitive current pulse per Figure 2
2. FR−5 = 1.0 x 0.75 x 0.62 in.
3. Alumina = 0.4 x 0.3 x 0.024 in., 99.5% alumina
ELECTRICAL CHARACTERISTICS
I
(T = 25°C unless otherwise noted)
UNIDIRECTIONAL
A
I
F
Symbol
Parameter
I
PP
Maximum Reverse Peak Pulse Current
V
C
Clamping Voltage @ I
PP
V
C
V
V
BR RWM
V
V
Working Peak Reverse Voltage
I
V
F
RWM
R
T
I
I
R
Maximum Reverse Leakage Current @ V
RWM
V
Breakdown Voltage @ I
Test Current
BR
T
I
T
I
PP
QV
Maximum Temperature Coefficient of V
Forward Current
BR
BR
I
F
Uni−Directional TVS
V
F
Forward Voltage @ I
F
Z
Maximum Zener Impedance @ I
Reverse Current
ZT
ZT
I
ZK
Z
ZK
Maximum Zener Impedance @ I
ZK
ELECTRICAL CHARACTERISTICS
Breakdown Voltage
V , Clamping Voltage
C
(Note 4)
(Note 5)
Capacitance
Max
V
@ 1 mA (Volts)
@ 1 A
(V)
@ 5 A
(V)
11
@ V = 0 V, 1 MHz (pF)
I
V
I @ V
R RWM
BR
R
PP
RWM
Device
Marking
(A)
(V)
(mA)
20
Min
Max
8.0
Typ
3.5
3.5
3.5
3.5
Max
5.0
5.0
5.0
5.0
Device
SL05
SL12
SL15
SL24
L05
L12
L15
L24
5.0
12
15
24
6.0
9.8
19
17
12
10
5.0
1.0
1.0
1.0
13.3
16.7
26.7
15.5
18.5
29
24
24
30
43
55
Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product
performance may not be indicated by the Electrical Characteristics if operated under different conditions.
4. V measured at pulse test current of 1 mA at an ambient temperature of 25°C
BR
5. Surge current waveform per Figure 2
www.onsemi.com
2

SL05T1G Series
TYPICAL CHARACTERISTICS
10
1
100
t
r
PEAK VALUE I
@ 8 ms
RSM
90
80
70
60
50
40
30
PULSE WIDTH (t ) IS DEFINED
AS THAT POINT WHERE THE
PEAK CURRENT DECAY = 8 ms
P
HALF VALUE I
/2 @ 20 ms
RSM
0.1
t
P
20
10
0
0.01
0.1
1
10
100
1000
0
20
40
t, TIME (ms)
60
80
PULSE WIDTH (ms)
Figure 1. Maximum Peak Power Rating
Figure 2. 8 × 20 ms Pulse Waveform
4
3.5
3
10
1
SL05T1
2.5
2
SL05
SL15
SL24
1.5
1
0.1
0.5
0
0.01
@ ZERO BIAS
@ 50% V
@ V
−55
25
150
RWM
RWM
TEMPERATURE (°C)
Figure 3. Typical Junction Capacitance
Figure 4. Typical Leakage Over Temperature
www.onsemi.com
3
SL05T1G Series
Applications Background
This family of TVS devices (SL05T1 series) are designed
to protect sensitive electronics such as communications
systems, computers, and computer peripherals against
damage due to ESD conditions or transient voltage
conditions. Because of their low capacitance value (less than
5 pF), they can be used in high speed I/O data lines. Low
capacitance is achieved by integrating a compensating diode
in series with the TVS which is basically based in the below
theoretical principle:
Capacitance in parallel: CT = C1+C2+....+Cn
Capacitance in series: 1/CT = (1/C1)+(1/C2)+....+(1/Cn)
The Figure 5 shows the integrated solution of the SL05T1
series device:
2
1
1
2
3
3
Figure 6.
An alternative solution to protect unidirectional lines, is to
connect a fast switching steering diode in parallel with the
SL05T1 series device. When the steering diode is
forward−biased, the TVS will avalanche and conduct in
reverse direction. It is important to note that by adding a
steering diode, the effective capacitance in the circuit will be
increased, therefore the impact of adding a steering diode
must be taken in consideration to establish whether the
incremental capacitance will affect the circuit functionality
or not. The Figure 7 shows the connection between the
steering diode and the SL05T1 series device:
COMPENSATING
DIODE
TVS
Figure 5.
In the case that an over−voltage condition occurs in the I/O
line protected by the SL05T1 series device, the TVS is
reversed−biased while the compensation diode is
forward−biased so the resulting current due to the transient
voltage is drained to ground.
SL05T1 DEVICE
If protection in both polarities is required, an additional
device is connected in inverse−parallel with reference to the
first one, the Figure 6 illustrates the inverse−parallel
connection for bi−directional or unidirectional lines:
STEERING DIODE
Figure 7.
Another typical application in which the SL05T1 series
device can be utilized, is to protect multiple I/O lines. The
protection in each of the I/O lines is achieved by connecting
two devices in inverse−parallel. The Figure 8 illustrates how
multiple I/O line protection is achieved:
INPUT
OUTPUT
Figure 8.
For optimizing the protection, it is recommended to use ground planes and short path lengths to minimize the PCB’s ground inductance.
www.onsemi.com
4

SL05T1G Series
PACKAGE DIMENSIONS
SOT−23 (TO−236)
CASE 318−08
ISSUE AR
NOTES:
D
1. DIMENSIONING AND TOLERANCING PER ASME Y14.5M, 1994.
2. CONTROLLING DIMENSION: MILLIMETERS.
3. MAXIMUM LEAD THICKNESS INCLUDES LEAD FINISH.
MINIMUM LEAD THICKNESS IS THE MINIMUM THICKNESS OF
THE BASE MATERIAL.
0.25
3
4. DIMENSIONS D AND E DO NOT INCLUDE MOLD FLASH,
PROTRUSIONS, OR GATE BURRS.
T
H
E
E
1
2
MILLIMETERS
INCHES
DIM
A
A1
b
c
D
E
e
L
L1
MIN
0.89
0.01
0.37
0.08
2.80
1.20
1.78
0.30
0.35
2.10
0°
NOM
1.00
0.06
0.44
0.14
2.90
1.30
1.90
0.43
0.54
2.40
−−−
MAX
MIN
0.035
0.000
0.015
0.003
0.110
0.047
0.070
0.012
0.014
0.083
0°
NOM
0.039
0.002
0.017
0.006
0.114
0.051
0.075
0.017
0.021
0.094
−−−
MAX
0.044
0.004
0.020
0.008
0.120
0.055
0.080
0.022
0.027
0.104
10°
L
1.11
0.10
0.50
0.20
3.04
1.40
2.04
0.55
0.69
2.64
10°
3X
b
L1
VIEW C
e
TOP VIEW
A
H
E
T
c
A1
SEE VIEW C
SIDE VIEW
STYLE 26:
PIN 1. CATHODE
2. ANODE
END VIEW
3. NO CONNECTION
RECOMMENDED
SOLDERING FOOTPRINT*
3X
2.90
0.90
3X
0.95
0.80
PITCH
DIMENSIONS: MILLIMETERS
*For additional information on our Pb−Free strategy and soldering
details, please download the ON Semiconductor Soldering and
Mounting Techniques Reference Manual, SOLDERRM/D.
ON Semiconductor and
are trademarks of Semiconductor Components Industries, LLC dba ON Semiconductor or its subsidiaries in the United States and/or other countries.
ON Semiconductor owns the rights to a number of patents, trademarks, copyrights, trade secrets, and other intellectual property. A listing of ON Semiconductor’s product/patent coverage
may be accessed at www.onsemi.com/site/pdf/Patent−Marking.pdf. ON Semiconductor reserves the right to make changes without further notice to any products herein.
ON Semiconductor makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does ON Semiconductor assume any liability
arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation special, consequential or incidental damages. Buyer
is responsible for its products and applications using ON Semiconductor products, including compliance with all laws, regulations and safety requirements or standards, regardless of
any support or applications information provided by ON Semiconductor. “Typical” parameters which may be provided in ON Semiconductor data sheets and/or specifications can and
do vary in different applications and actual performance may vary over time. All operating parameters, including “Typicals” must be validated for each customer application by customer’s
technical experts. ON Semiconductor does not convey any license under its patent rights nor the rights of others. ON Semiconductor products are not designed, intended, or authorized
for use as a critical component in life support systems or any FDA Class 3 medical devices or medical devices with a same or similar classification in a foreign jurisdiction or any devices
intended for implantation in the human body. Should Buyer purchase or use ON Semiconductor products for any such unintended or unauthorized application, Buyer shall indemnify and
hold ON Semiconductor and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees
arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that ON Semiconductor was
negligent regarding the design or manufacture of the part. ON Semiconductor is an Equal Opportunity/Affirmative Action Employer. This literature is subject to all applicable copyright
laws and is not for resale in any manner.
PUBLICATION ORDERING INFORMATION
LITERATURE FULFILLMENT:
N. American Technical Support: 800−282−9855 Toll Free
USA/Canada
Europe, Middle East and Africa Technical Support:
Phone: 421 33 790 2910
Japan Customer Focus Center
Phone: 81−3−5817−1050
ON Semiconductor Website: www.onsemi.com
Order Literature: http://www.onsemi.com/orderlit
Literature Distribution Center for ON Semiconductor
19521 E. 32nd Pkwy, Aurora, Colorado 80011 USA
Phone: 303−675−2175 or 800−344−3860 Toll Free USA/Canada
Fax: 303−675−2176 or 800−344−3867 Toll Free USA/Canada
Email: orderlit@onsemi.com
For additional information, please contact your local
Sales Representative
SL05T1/D
厂商 型号 描述 页数 下载

ONSEMI

SZSL15T1G [ Capacitance TVS ] 5 页

LITTELFUSE

SZSMF10AT1G [ Trans Voltage Suppressor Diode, 1000W, 10V V(RWM), Unidirectional, 1 Element, Silicon, ROHS COMPLIANT, PLASTIC, CASE 498, 2 PIN ] 6 页

ONSEMI

SZSMF12AT3G [ DIODE TVS DIODE, Transient Suppressor ] 6 页

LITTELFUSE

SZSMF13AT1G [ Trans Voltage Suppressor Diode, 1000W, 13V V(RWM), Unidirectional, 1 Element, Silicon, ROHS COMPLIANT, PLASTIC, CASE 498, 2 PIN ] 6 页

ONSEMI

SZSMF14AT1G [ 200 Watt SOD-123FL Transient Voltage Suppressors, 14 V, Unidirectional, SOD-123FL 2 LEAD, 3000-REEL ] 6 页

LITTELFUSE

SZSMF14AT1G [ Trans Voltage Suppressor Diode, 1000W, 14V V(RWM), Unidirectional, 1 Element, Silicon, ROHS COMPLIANT, PLASTIC, CASE 498, 2 PIN ] 6 页

ONSEMI

SZSMF15AT1G 200W的瞬态电压抑制器SOD- 123扁平引脚封装[ 200 W Transient Voltage Suppressor SOD-123 Flat Lead Package ] 6 页

LITTELFUSE

SZSMF20AT1G [ Trans Voltage Suppressor Diode, 1000W, 20V V(RWM), Unidirectional, 1 Element, Silicon, ROHS COMPLIANT, PLASTIC, CASE 498, 2 PIN ] 6 页

LITTELFUSE

SZSMF24AT1G [ Trans Voltage Suppressor Diode, 1000W, 24V V(RWM), Unidirectional, 1 Element, Silicon, ROHS COMPLIANT, PLASTIC, CASE 498, 2 PIN ] 6 页

ONSEMI

SZSMF28AT3G [ DIODE TVS DIODE, Transient Suppressor ] 6 页

PDF索引:

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引:

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

0.216292s
