Description
WT32 Bluetooth® Audio
Module™
WT32 is the latest generation of Bluegiga’s Bluetooth
modules. It provides the highest level of integration with
integrated 2.4GHz radio, DSP, battery charger, stereo
codec and antenna ready to hit mono and stereo audio
applications. WT32 is also completely ready to support
the latest Bluetooth 2.1 standard.
The embedded DSP core allows enhancement of
the product with features, such as, advanced audio
decoding, echo cancellation, noise reduction and data
manipulation.
WT32 combined with Bluegiga’s flexible iWRAP firmware
enables device manufacturers to easily add wireless,
secure and standard based Bluetooth connectivity into
new or existing applications with minimal development
and manufacturing effort.
Key Features
Plug n’ Play Bluetooth solution for mono and stereo
audio solutions
WT32 supports several different integration designs:
The module can be configured to operate
autonomously
Integrated DSP, stereo codec and battery charger
Integrated antenna or W.FL connector
Bluetooth 2.1+ EDR compliant
A host
processor can control the Bluetooth
functionality with ASCII commands via UART
interface
Bluetooth functions are provoked with events via
GPIO pins
Bluetooth end product, CE, IC and FCC qualified
Class 2 - range up to 30 meters
WT32Bluetoothmoduleisavailablewithseveraldifferent
firmware options for audio and data communications.
Bluegiga also provides custom firmware development
and production services, eliminating the need for
customers to perform expensive Bluetooth development,
certifications and production line configuration,
significantly reducing the implementation costs, risks
and time.
Industrial temperature range from -40ºC to +85ºC
Low power consumption
iWRAP™ Firmware for controlling connections and
configuring settings
Supported Bluetooth profiles:
SPP, DUN, OBEX OPP, HFP (v.1.5) A2DP, AVRCP, DID
and HID
By utilizing Bluegiga’s world-class integration services
and technical support, OEMs can be assured that their
products reach the market quickly and cost efficiently.
