Applications
OX02A10
¬
Automotive
- 360° Surround View System
- Rear View Camera
- Lane Departure Warning /
Lane Keep Assist
- Pedestrian Detection
- Traffic Sign Recognition
- Camera Monitoring System
- Autonomous Driving
- e-Mirror
- Blind Spot Detection
- Night Vision
Ordering Information
¬
OX02A10-E85Y-PA-Z
¬
OX02A10-E85Y-RA-Z
(color, lead-free) 85-pin a-CSP™
with dual coated AR glass, packed
in tray with protective film
(color, lead-free) 85-pin a-CSP™
with dual coated AR glass, packed
in tape & reel with protective film
Product Features
¬
support for image size:
- 1824 x 940
¬
¬
horizontal and vertical sub-sampling
- VGA
serial camera control bus (SCCB)
for register programming
Product Specifications
- QVGA and any cropped size
¬
¬
¬
¬
¬
OmniHDR-S™ technology
high sensitivity
¬
¬
high speed serial data transfer with
MIPI CSI-2, parallel 12-bit DVP output
¬
active array size: 1824 x 940
¬
output formats:
- 20-bit combined RAW
¬
power supply:
- 12-bit compressed combined RAW
- separated 12-bit RAW
- 2x12 bit compressed RAW
- 16-bit log domain combined RAW
external frame synchronization
capability
- analog: 3.14 ~ 3.47V
- digital: 1.425 ~ 1.575V
- DOVDD: 1.7 ~ 1.9V
- AVDD: 1.7 ~ 1.9V
safety features
low power consumption
¬
¬
¬
embedded temperature sensor
¬
¬
¬
¬
¬
¬
¬
¬
¬
scan mode: progressive
image sensor processor functions:
- lens correction
- defective pixel cancelation
- HDR combination and tone mapping
- automatic black level correction
one time programmable (OTP) memory
¬
¬
power requirements:
- active: 450 mW
- standby: 100 µW
shutter: rolling shutter
support for LED flicker reduction
(LFR) function
maximum image transfer rate: 60 fps
sensitivity: 8.5 V/Lux-sec
max S/N ratio: 41.7 dB
temperature range:
- operating: -40°C to +105°C sensor
ambient temperature and -40°C to
+125°C junction temperature
¬
supported output formats: RAW
¬
output interfaces: 12-bit DVP,
MIPI CSI-2
dynamic range: 110 dB
pixel size: 4.2 µm x 4.2 µm
image area: 7711.2 µm x 3998.4 µm
¬
¬
¬
input clock frequency: 6 ~ 36 MHz
lens size: 1/2.09"
package dimensions:
9510 µm x 6860 µm
lens chief ray angle: 19°
Functional Block Diagram
OX02A10
image sensor core
image signal
processor
output
interface
array
AWB gain,
DPC, DNS, LENC,
HDR, ToneMap
DVP[11:0]
MIPI
column
ADC (12b)
BLC,
DigGain
stats engine
gain control
PLL PLL
timing generator and
system control logic
temperature
sensor
SCCB
interface
OTP
1
2
