EXII-ASIC-C

型号:

EXII-ASIC-C

品牌:

3M[ 3M ELECTRONICS ]

页数:

4 页

PDF大小:

118 K

EX II Series
Capacitive Touch System
Electronics
Product Highlights
A World-Class Electronics Solution
• State-of-the-art accuracy
The MicroTouch EX II Series Controllers bring flexibility and feature-
and touch response
rich functionality to capacitive touch screen applications. This high
performance electronics platform is based on the innovative
MicroTouch EX II ASIC, designed to provide high resolution, on-chip
RAM, and a wide operating temperature range. With expanded
regulatory approvals, improved power modes, and enhanced ESD
and EMI protection, this controller series is a robust solution for
popular touch applications.
• Standard-setting ESD and
EMI protection
• Firmware download capability
provides flexibility
• Wide operating temperature
• High touch coordinate
resolution of 16k x 16k*
Advanced Firmware Download Capability
Culminating decades of touch technology experience, the EX II
Series electronics enables advanced firmware download capabilities,
• USB, HID, RS232-compliant
interfaces
* The maximum number of addressable
coordinates generated by the controller
optimized for MicroTouch ClearTek II and legacy ClearTek touch
screens. Standard factory-loaded firmware can be easily updated
or replaced at some future date with downloadable, newer firmware
revisions to match updated software application functionality. This field
upgrade capability can mean minimal downtime for software upgrades.
EX II Series Capacitive Touch System Electronics
USB EX II 770OHC
Serial EX II 7700SC
USB EX II 7700UC
EXII-7760UC
EXII-7730HC
EXII-7720SC
Part Numbers
USB Rev 1.1
HID (Mouse)
Serial RS-232
Communications Protocol
Optional Components
7312256 96" (2.4 m) Cable, Pearl
7315050 23" (0.58m) Cable, Pearl
7312256 96" (2.4 m) Cable, Pearl
7315050 23" (0.58m) Cable, Pearl
7310101 96" (2.4 m) Cable, Pearl
7310107 26" (0.7 m) Cable, Pearl
1.30" x 2.55" x 0.45"
33.0 x 65.0 x 11.4 mm
1.30" x 2.55" x 0.45"
33.0 x 65.0 x 11.4 mm
1.30" x 2.55" x 0.45"
33.0 x 65.0 x 11.4 mm
Dimensions
USB bus
USB bus
5K through 2-pin
connector on board
Power Connection
Touch Screen Connection
5-pin locking AMP
> 700,000 hours
5-pin locking AMP
> 700,000 hours
5-pin locking AMP
> 700,000 hours
Mean Time Between
Failure (MTBF)
8ꢀK Contact, 27ꢀK Air
0 to 95% non-condensing at +36ºC
-50º to +85º C
8ꢀK Contact, 27ꢀK Air
0 to 95% non-condensing at +36ºC
-50º to +85º C
8ꢀK Contact, 27ꢀK Air
0 to 95% non-condensing at +36ºC
-50º to +85º C
Electrostatic Discharge (ESD)
Relative Humidity
Storage Temperature
-40º to +70º C
-40º to +70º C
-40º to +70º C
Operating Temperature
Power Requirements (Typical)
5Kdc 5% 75 mA
5Kdc 5% 75 mA
5-12Kdc 5% 85 mA
UL/cUL, FCC-B, CE, VCCI,
AS/NZS 3548, RoHS
UL/cUL, FCC-B, CE, VCCI,
AS/NZS 3548, RoHS
UL/cUL, FCC-B, CE, VCCI,
AS/NZS 3548, RoHS
Regulatory
MT 7 (Win Vista, 2000, XP, XPe,
WEPOS, CE.net 4.0/5.0, Linux)
TouchWare (Win 95, 98, NT)
MSFT HID (Mouse)
Optional: MT 7 (Win Vista, 2000, XP,
XPe, WEPOS,CE.net 4.0/5.0)
MT 7 (Win Vista, 2000, XP, XPe,
WEPOS, CE.net 4.0/5.0, Linux)
TouchWare (Win 95, 98, NT)
Driver Support
5 Years
5 Years
5 Years
Warranty
EX II Series Capacitive Touch System Electronics
EX II ASIC Chipset
TouchPen System
Part Numbers
EXII-3710SP
EXII-ASIC-C
Communications Protocol
Optional Components
Serial RS-232
Serial RS-232 / USB Rev 1.1
69-901 TouchPen ꢀit (includes
stylus, stylus cable, RS232 cable)
69-502 (stylus)
N/A
7311240 (stylus cable)
7311273 (RS232 cable)
Dimensions
4.80" X 1.35" x .32"
121.9 x 34.3 x 8.2 mm
N/A
Power Connection
Touch Screen Connection
12K through RS232 cable
Based on design
5-pin locking AMP
> 700,000 hours
6-pin Molex
Mean Time Between
Failure (MTBF)
> 600,000 hours
Electrostatic Discharge (ESD)
Relative Humidity
8ꢀK Contact, 27ꢀK Air
0 to 95% non-condensing at +36ºC
-50º to +85º C
Based on design
0 to 95% non-condensing at +36ºC
-50º to +85º C
Storage Temperature
Operating Temperature
Power Requirements (Typical)
-40º to +70º C
-40º to +70º C
12Kdc 5% 100 mA
Based on design
Regulatory
UL/cUL, FCC-B, CE, VCCI,
AS/NZS 3548, RoHS
UL/cUL, FCC-B, CE, VCCI, AS/NZS
3548, RoHS
Driver Support
MT 7 (Win Vista, 2000, XP, XPe,
WEPOS, CE.net 4.0/5.0, Linux)
TouchWare (Win 95, 98, NT)
MT 7 (Win Vista,2000, XP, XPe,
WEPOS, CE.net 4.0/5.0, Linux)
TouchWare (Win 95, 98, NT)
Warranty
5 Years
1 Year
RoHS Directive compliant: In accordance with European Directive 2002/95/EC, “RoHS Directive compliant” means that the product or part does not contain any of the following sub-
stances in excess of the following maximum concentration values in any homogeneous material, unless the substance is in an application that is exempt under RoHS: (a) 0.1% (by weight)
for lead, mercury, hexavalent chromium, polybrominated biphenyls or polybrominated diphenyl ethers; or (b) 0.01% (by weight) for cadmium. Unless otherwise stated by 3M in writing, this
information represents 3M’s knowledge and belief based on information provided by third party suppliers to 3M. (9/06)
3M Touch Systems
300 Griffin Brook Park Drive
Methuen, MA 01844
U.S.A.
NOTICE: Given the variety of factors that can affect the use and performance of a 3M Touch Systems Product (the “Product”), including that solid state equipment has operation char-
acteristics different from electro mechanical equipment, some of which factors are uniquely within User’s knowledge and control, it is essential that User evaluate the 3M Touch Systems
Product and software to determine whether it is suitable for User’s particular purpose and suitable for User’s method of application. 3M Touch Systems’ statements, engineering/technical
information, and recommendations are provided for User’s convenience, but their accuracy or completeness is not warranted. 3M Touch Systems products and software are not specifically
designed for use in medical devices as defined by United States federal law. 3M Touch Systems products and software should not be used in such applications without 3M Touch Systems’
express written consent. User should contact its sales representative if User’s opportunity involves a medical device application.
1-888-659-1080
www.3M.com/touch
For more information
on 3M touch products,
IMPORTANT NOTICE TO PURCHASER: Specifications are subject to change without notice. These 3M Touch Systems’ Products and software are warranted to meet their published
specifications from the date of shipment and for the period stated in the specification. 3M Touch Systems makes no additional warranties, express or implied, including but not limited to
any implied warranties of merchantability or fitness for a particular purpose. User is responsible for determining whether the 3M Touch Systems Products and software are fit for User’s par-
ticular purpose and suitable for its method of production, including intellectual property liability for User’s application. If the Product, software or software media is proven not to have met
3M Touch Systems’ warranty, then 3M Touch Systems’ sole obligation and User’s and Purchaser’s exclusive remedy, will be, at 3M Touch Systems’ option, to repair or replace that Product
quantity or software mediator to refund its purchase price. 3M Touch Systems has no obligation under 3M Touch Systems’ warranty for any Product, software or software media that has
been modified or damaged through misuse, accident, neglect, or subsequent manufacturing operations or assemblies by anyone other than 3M Touch Systems. 3M Touch Systems shall
not be liable in any action against it in any way related to the Products or software for any loss or damages, whether non-specified direct, indirect, special, incidental or consequential
(including downtime, loss of profits or goodwill) regardless of the legal theory asserted. (7/02)
call toll-free 1-888-659-1080
MicroTouch and ClearTek are trademarks of 3M.
Printed in USA © 3M 2008 EXII-08-08
