QTFT-2MB1_19

型号:

QTFT-2MB1_19

品牌:

RALSTON[ RALSTON INSTRUMENTS. ]

页数:

1 页

PDF大小:

525 K

Part No.
QTFT-2MB0
1/4" male NPT x male Quick-test, no check-valve, with cap
and chain , brass
A removable cap provides easy access to
connect a Quick-test hose to the process for
calibration purposes and is easily sealed
bubble-tight again when calibration is
complete
QTFT-2MB0
Specs/Attributes
Country of origin
Has Check Valve
Materials
USA
No
Brass
Max Pressure
Max Temperature
Max Vacuum
5000 PSI / 345 bar / 35 MPa
225 °F / 105 °C
0.00 InHg / 0.0 kPa
Buna-N
Seal Materials
Wrench Size
9/16 In
15 mm
Dimensions
H: 1.85 in (4.7 cm) x W: 0.71 in (1.8 cm)
Ralston Instruments Inc. | ralstoninst.com | Toll Free 800-347-6575 | Phone 440-564-1430 | Fax 440-564-1480
