OVM12F3x7 series
Electrical Specificaꢀons
Absolute Maximum Raꢀngs (TA = 25° C unless otherwise noted)
Storage Temperature Range
-40 ~ +80 °C
-30 ~ +50 °C
15 V
Operaꢁng Temperature Range
Input Voltage
Power Dissipaꢁon
1.5 W
LED Juncꢁon Temperature
125 oC
Electrostaꢁc Discharge Classificaꢁon (JEDEC-JESD22-A114F)
Class 1C
Notes:
1. Lead Solder ꢁme less than 10 seconds at temperature extreme.
2. No Heat sink is required if the string is operated at ambient temperature < 35°C. For long term performance the drive voltage at 12 V is recommend-
Electrical Characterisꢀcs (TA = 25° C unless otherwise noted)
SYMBOL
PARAMETER
Red/Yellow/Green/Blue/White
Input Voltage
MIN
TYP
MAX
UNITS
TEST CONDITIONS
0.5
0.3
Power Consumpꢁon
- - -
W
VDC = 12 V
VDC
- - -
- - -
- - -
- - -
V
g
12
16
Net Weight
Per module
VDC = 12 V
See
chart
λD
Dominant Wavelength
50% Power Angle
- - -
----
2 Θ½
120
----
deg
If an entire string is not required for the application, clip wires at mid-span:
Modules can be secured onto a mounting surface with two #6 screws. Modules are waterproof and can be used outdoors.
The installer is responsible for waterproofing the connection to the power source. The installer is also responsible for the
use of an exterior approved power source.
General Note
TT Electronics | OPTEK Technology
1645 Wallace Drive, Carrollton, TX 75006|Ph: +1 972 323 2200
TT Electronics reserves the right to make changes in product specificaꢁon without
noꢁce or liability. All informaꢁon is subject to TT Electronics’ own data and is
www.ꢀelectronics.com | sensors@ꢀelectronics.com
considered accurate at ꢁme of going to print.
Issue B 11/2016 Page 2
