IWTT Series
Industrial Wireless Temperature Transducer
K or J Type Thermocouples
PT100 RTD Sensors
6mm stainless steel sheath
Up to 750m line-of-site range (depending on receiver)
Five year battery life at 10 second transmission update rate
Simple DIL switch pairing with the single or five channel receiver
Single or five channel receivers available
User-selectable transmission update rates
User-selectable 1-5V or 4-20mA receiver outputs
Receiver clean contacts provide process alarm functions
DESCRIPTION
The IWTT Wireless Temperature Transducer is a cost effective replacement to a
traditionally wired temperature transducer that offers the advantages of a low-cost
installation in inaccessible and expensive installation environments.
It is easily paired to the compatible IWR family of single- or five-channel wireless
receivers thus offering a “plug and play” solution to your temperature measurement
applications.
TYPICAL APPLICATIONS INCLUDE:-
- Simple cable replacement installation –
dispense with expensive cable runs
- Environmental monitoring – pumping stations,
sewage plants, water treatment
- Facilities management – boiler rooms, plant
hydraulics, plant pneumatics
- Asset monitoring – tanks farms, process
plants, HVAC and building management
- Service Contract – temporary installation for
servicing and field trials
The instrument uses either J or K type thermocouples or 3-wire RTD sensors fitted to an
acetal housing giving excellent media compatibility for the harshest of applications.
Compression fittings are available which allow the head to be orientated in the required
direction.
The IWTT sensor should be used with either an IWR-1 or IWR-5 receiver. A line-of-sight
range of up to 750m is possible depending on the wireless receiver used (refer to
datasheets IWR-1 & IWR-5 for further information).
Each device is temperature compensated, calibrated and supplied with a traceable
serial number.
System Performance
Accuracy (Non-Linearity & Hysteresis) < 0.1ꢀ ꢁ FS
Temperature Coefficent
Transmitter Temperature Ranges
Standard products are factory configured as below:-
500ppmꢁ°C
J-Type
0 to 1200°C
K-Type
0 to 1200°C
RTD type -200 to +800°C
Instrument Power Source
Battery Type
Battery Life
Transmitter Output
*Transmission Frequency
Transmit Power
User replaceable Lithium C cell
Five years at 10 second update
rate
10 years
2.4 Ghz
18 dBm
User selectable via DIL switch
Integral 0dBi
System Channel
Battery Shelf Life
Antenna
*Compliant with EN 300 328, V1.8.1
