Chip Resistor Array
■ Ratings
Item
Specifications
10 Ω to 1 MΩ : E24 series
J : 5 ꢀ
Item
Specifications
14V,18V
2HV
12.5 V
25 V
Resistance Range
Limiting Element Voltage(1)
Resistance Tolerance
24V,28V,N8V,38V,34V,V4V,V8V 50 V
S8V
100 V
25 V
50 V
14V,24V,V4V,34V
4 terminal
14V,18V
2HV
Number of Terminals 18V,28V,N8V,38V,V8V,S8V 8 terminal
Maximum Overload
Voltage (2)
2HV
16 terminal
2 element
24V,28V,N8V,38V,34V,V4V,V8V 100 V
S8V
200 V
14V,24V,V4V,34V
T.C.R.
200×10-6/°C
Number of Resistors 18V,28V,N8V,38V,V8V,S8V 4 element
2HV
8 element
Category Temperature Range
–55 °C to 125 °C
0.5 A
14V,N8V
18V
0.031 W/element
14V,18V
0.031 W/element
(0.1 W/package)
Rated Current 2HV,24V,28V,N8V,38V,34V,V4V,V8V 1 A
Power Rating at 70 °C 24V,28V,V4V,34V,V8V,38V 0.063 W/element
S8V
2 A
1 A
14V,18V
S8V
2HV
0.1 W/element
Maximum Overload
Current
2HV,24V,28V,N8V,38V,34V,V4V,V8V 2 A
S8V
0.063 W/element
(0.25 W/package)
4 A
√
(1) Rated Continuous Working Voltage (RCWV) shall be determined from RCWV= Power Rating × Resistance Value, or Limiting Element Voltage listed
above, whichever less.
(2) Overload (Short-time Overload) Test Voltage (SOTV) shall be determined from SOTV=2.5 × Power Rating or max. Overload Voltage listed above whichever less.
–55 °C
70 °C
100
80
60
40
20
0
Power Derating Curve
For resistors operated in ambient temperature above
70 °C, power rating shall be derated in accordance
with the figure on the right.
125 °C
–60 –40 –20
0
20 40 60 80 100 120 140 160 180
Ambient Temperature (°C)
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
