DC-DC Converter
JWE06 Series
Input
Characteristic
Minimum
9.0
Typical
Maximum
Units
Notes & Conditions
24 V nominal
36
75
VDC
VDC
Input Voltage Range
Input Filter
18.0
48 V nominal
Internal Pi type
ON at ≥9 V, OFF at <8 V
ON at ≥18 V, OFF at <16 V
24 V models
48 V models
12 V models
24 V models
48 V models
Undervoltage Lockout
25
50
Input Surge
VDC for 1 s
100
Output
Characteristic
Minimum
Typical
Maximum
Units
VDC
%
Notes & Conditions
Output Voltage
3.3
30
See Models and Ratings table
At full load
Initial Set Accuracy
Output Voltage Balance
Minimum Load
2.0
2.0
1.0
%
For dual output with balanced laods
No minimum load required
From minimum to maximum input at full load
From 0 to full load
A
Line Regulation
Load Regulation
0.2
0.5
0.8
1.0
%
%
On dual output models when one load is varied between
25% and 100% and other is fixed at 100%
Cross Regulation
Transient Response
Ripple & Noise
5.0
5
%
Recovery within 1% in less than 250 µs for a 25% load
change.
3
% deviation
20 MHz bandwidth. Measured using 0.47 µF ceramic
capacitor.
55
mV pk-pk
%
Overload Protection
150
Short Circuit Protection
Maximum Capacitive Load
Temperature Coefficient
Continuous Trip & Restart (Hiccup mode), with auto recovery
See Models and Ratings table
0.02
%/˚C
General
Characteristic
Minimum
Typical
Maximum
Units
%
Notes & Conditions
See Models and Ratings table
60 s/1 s
Efficiency
88
Isolation: Input to Output
Isolation Resistance
Isolation Capacitance
Switching Frequency
Power Density
1500/1800
VDC
Ω
9
10
At 500 VDC
500
pF
370
kHz
3
38.0
W/in
Mean Time Between Failure
Weight
MHrs
lb (g)
MIL-HDBK-217F, +25 °C GB
0.013 (6.1)
Environmental
Characteristic
Operating Temperature
Storage Temperature
Case Temperature
Humidity
Minimum
-40
Typical
Maximum
+105
Units
°C
Notes & Conditions
See Derating Curve.
-50
+125
°C
+105
95
°C
%RH
Non-condensing
Cooling
Natural convection
Case Flammability
UL 94V-0 Rated
EMC: Emissions
Phenomenon
Standard
EN55032
Test Level
Notes & Conditions
Conducted
Class A
No filter required
www.xppower.com
2
