Part Number: XZBWR68F5MAV-3
1.0x0.5x0.2mm (0402) SMD CHIP LED LAMP
Package Schematics
Features
● Ideal for indication light on hand held products
● Long life and robust package
● Standard Package: 4,000pcs/ Reel
● MSL (Moisture Sensitivity Level): 3
● Low current IF=5mA operating.
● RoHS compliant
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
DISCHARGE
SENSITIVE
DEVICES
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is ±0.1(0.004") unless otherwise noted.
3. Specifications are subject to change without notice.
Absolute Maximum Ratings
(TA=25°C)
White
(InGaN)
Operating Characteristics
(TA=25°C)
White
(InGaN)
Unit
Unit
V
Reverse Voltage
VR
IF
5
V
Forward Voltage (Typ.)
(IF=5mA)
VF
VF
IR
x
2.9
3.1
Forward Current
10
mA
Forward Current (Peak)
1/10 Duty Cycle
0.1ms Pulse Width
Forward Voltage (Max.)
(IF=5mA)
V
iFS
50
mA
Reverse Current (Max.)
(VR=5V)
Electrostatic Discharge Threshold
(HBM)
50
uA
1000
V
Power Dissipation
PD
32
mW
0.31
0.31
Chromaticity Coordinates
(Typ.)
Operating Temperature
Storage Temperature
TA
-40 ~ +85
-40 ~ +85
°C
y
Tstg
A Relative Humidity between 40% and 60% is recommended in
ESD-protected work areas to reduce static build up during assembly
process (Reference JEDEC/JESD625-A and JEDEC/J-STD-033)
Luminous Intensity
CIE127-2007*
(IF=5mA)
Viewing
Angle
2θ 1/2
Part
Number
Emitting
Color
Emitting
Material
Lens-color
mcd
min.
40*
typ.
84*
XZBWR68F5MAV-3
White
InGaN
Yellow Fluorescent
160°
*Luminous Intensity value is in accordance with CIE127-2007 standards.
Sep 16, 2016
XDSB7629 V5-Z
Layout: Maggie L.
P. 1/5
