Fuse Holders
INLINE SPLASHPROOF FUSE HOLDER
for MINI® Style Blade Fuse
Specifications
Housing:
Color:
Out of thermoplastic (UL 94-V0, heat-resistant)
Black
IP Rating:
IP67
Ordering Information
Part Number
Package Size
0FHM000xLXN
0FHM000xZXJ
50
1000
Description
Used with MINI / FK1 Fuse. Includes protective cover for harsh
environment. This product is compatible with a MINI diode. Protected
to a rating of IP67.
Dimensions
Dimensions in mm
17.00±0.25
22±0.25
18±0.25
14±0.25
13±2
13±2
94±5
56±1.5
94±5
Ratings
Part Number
Description
Fuse Rating
0FHM0001_
0FHM0002_
14AWG/2.1mm2 stranded black wire
12AWG/3.3mm2 stranded orange wire
20 A
30 A
Wire length, color and diameter can be customized upon request.
Customization requires minimum order quantities depending on nature of modifications.
134
