Hybrid Thermal/EMI Absorber
CoolZorb 600 Thermal resistance at 100C (ASTM D5470)
CoolZorb 600 Percent Deflection (ASTM D575)
CoolZorb 600 Attenuation (dB/cm)
240
220
200
180
160
140
120
100
80
60
40
20
0
0
5
10 15 20 25 30 35 40 45 50 55 60 65 70 75 80
Frequency (GHz)
AVAILABILITY
Standard sheet size is 12” X 12”
Thickness availability range is .020” - .125” (0.5mm- 3.1mm)
Common standards for thickness are .020”, .040”, .060”, .080” , .100” and .125” thickness
(0.5mm, 1.0mm, 1.5mm, 2.0mm, 2.5mm and 3.1mm)
No charge samples are available in 4” X 4” size for each of the above common thicknesses
PART NUMBER SYSTEM
CoolZorb 600 series absorber sheets (12”X12”) use the following designation when ordering:
CZ600-XXX where XXX is thickness of absorber in thousands of an inch
CoolZorb 600 series no charge absorber samples (4”X4”) use the following designation when
ordering: CZ600S-XXX where XXX is thickness of absorber in thousands of an inch
Example: CZ600-020 = CoolZorb 600, .020”X12”X12” sheet size; Example: CZ600S-040 = CoolZorb
600, .040”X4”X4 no charge sample size
RFP-DS-COOLZORB 500 110915
