MZ7410/MZ7410C
DOUBLE-BALANCED MIXER
· LO 4 TO 18 GHz
· RF 6 TO 18 GHz
· IF DC TO 3 GHz
· LO DRIVE +10 dBm (nominal)
· MINIATURE PACKAGE
· WIDE BANDWIDTH
· AVAILABLE WITH FIELD REPLACEABLE CONNECTORS
· MIL-M-28837 EQUIVALENT LEVEL SCREENING
Specifications (Rev. Date: 11/01)*
Characteristics
Typical
Guaranteed
+25°C
-54° to +85°C
SSB Conversion Loss & SSB Noise Figure (max.)
6 dB
7 dB
8 dB
9 dB
8.5 dB
9.5 dB
fR = 6 to 15 GHz,
fL = 4 to 16 GHz,
fI = 0.03 to 3 GHz
fR = 15 to 18 GHz, fL = 16 to 18 GHz, fI = 0.03 to 3 GHz
fR =
fR =
fL =
fL =
fI =
fI =
Isolation (min.)
L to R
fL =
fL =
36 dB
32 dB
23 dB
18 dB
21 dB
16 dB
4 to 14 GHz
14 to 18 GHz
fL =
L to I
fL =
35 dB
20 dB
18 dB
4 to 18 GHz
fL =
fL =
R to I
fR =
fR =
1 dB Conversion Compression
+1 dBm
+10 dBm
fL @
fL @
Input IP3
fR1
fL =
+14 dBm
=
fR2
fR2
fR2
=
=
13 GHz @ -6 dBm
14 GHz @ 10 dBm
13.01 GHz @ -6 dBm
fR1
=
fL =
fR1
=
=
fL =
Measured in a 50-ohm system with nominal LO drive and downconverter application only, unless otherwise specified. Subject to change without notice.
Absolute Maximum Ratings
Operating Temperature
Storage Temperature
Peak Input Power
Outline Drawing(s)
Package
VPAC
SMA
Figure
Model
MZ7410
MZ7410C
-54°C to 100°C
-65°C to 100°C
23 dBm max. @ +25°, °C
100 mA DC
JD
JC
Peak Input Current
Specifications subject to change without notice. • North America: 1-800-366-2266
Visit www.macom.com for complete contact and product information.
