LZ9FD34
Single-chip Driver IC for 270 k/320 k/
410 k/470 k-pixel B/W CCDs
LZ9FD34
DESCRIPTION
PIN CONNECTIONS
The LZ9FD34 is a CMOS single-chip driver IC which
generates timing pulses for driving 270 k/320 k/
410 k/470 k-pixel B/W CCD area sensors, syn-
chronous pulses for TV signals and processing for
video signals.
48-PIN QFP
TOP VIEW
48 47 46 45 44 43 42 41 40 39 38 37
TST1 1
TST2 2
VRI 3
TVMD 4
CSYN 5
VDD 6
GND 7
CBLK 8
HD 9
36 OFDX
35 VH3X
34 VH1X
33 V4X
32 V3X
31 GND
30 VDD
FEATURES
• Designed for B/W CCD area sensors with 270 k/
320 k/410 k/470 k-pixel
• Switchable between EIA and CCIR modes
• Electronic shutter and EE control are possible
• Maximum shutter speed is 1/100 000 s
• Flicker-less function
• Non-interlace mode is possible
• External synchronization is possible
• Single +5 V power supply
29 V2X
28 V1X
VD 10
HBLK 11
TST3 12
27 TST7
26 CCD
25 TST6
13 14 15 16 17 18 19 20 21 22 23 24
• Field accumulation mode and frame accumu-
lation mode are possible
• Package :
(QFP048-P-0707)
48-pin QFP (QFP048-P-0707) 0.5 mm pin-pitch
In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP devices shown in
catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.
1
LZ9FD34
BLOCK DIAGRAM
36
35
34
33
32
31
30
29
28
27
26
25
ITCH 37
EEST 38
WIND 39
FR 40
24 FS
23 FCDS
22 EENR
21 EEUD
20 EEMD
19 FLMD
18 VDD
SHUTTER
SPEED
CONTROL
SHUTTER
UP/DOWN
CONTROL
MIX
MIX
MODE SELECT
VDD 41
1/2
MODE SELECT
DECODER
FH2 42
GND 43
FH1 44
VDD 45
1/4
H COUNTER 2
DECODER
17 ACLX
16 GND
15 TST5
14 TST4
13 BCP
RESET
1/2
OSCI 46
OSCO 47
NINT 48
OSC
H COUNTER 1
V COUNTER
1
2
3
4
5
6
7
8
9
10
11
12
2
LZ9FD34
PIN DESCRIPTION
PIN NO. SYMBOL
I/O
ICD
ICD
POLARITY
–
–
PIN NAME
Test pin 1
Test pin 2
DESCRIPTION
1
2
TST1
TST2
A test pin. Set open or to L level in the normal mode.
A test pin. Set open or to L level in the normal mode.
An input pin for resetting internal vertical counter.
The input pulse is VSYNC. (negative polarity)
An input pin to select TV standards.
3
VRI
ICSU
–
Vertical reset input
TV mode selection
input
4
TVMD
ICU
–
L level
H level or open
: EIA mode
: CCIR mode
Composite
5
CSYN
O
synchronizing pulse An output pin of composite synchronous signal pulse.
output
6
7
VDD
GND
–
–
–
–
Power supply
Ground
Supply of +5 V power.
A grounding pin.
Composite blanking
pulse output
Horizontal drive
pulse output
Vertical drive pulse
output
8
9
CBLK
HD
O
O
O
An output pin of composite blanking pulse.
The pulse occurs at the start of every line.
The pulse occurs at the start of every field.
10 VD
Horizontal blanking A pulse that corresponds to the cease period of the
11 HBLK
12 TST3
O
pulse output
Test pin 3
horizontal transfer pulse.
ICD
–
A test pin. Set open or to L level in the normal mode.
A pulse to clamp the optical black signal. This pulse
stays low during the absence of effective pixels within
the vertical blanking.
Optical black clamp
pulse output
13 BCP
O
14 TST4
15 TST5
16 GND
ICD
ICD
–
–
–
–
Test pin 4
Test pin 5
Ground
A test pin. Set open or to L level in the normal mode.
A test pin. Set open or to L level in the normal mode.
A grounding pin.
An input pin for resetting all internal circuits at power on.
Connect VDD through the diode and through the
capacitor.
17 ACLX
18 VDD
ICU
–
–
–
All clear input
Power supply
Supply of +5 V power.
An input pin to control electronic exposure mode, flicker-
less mode and WIND (pin 39) pulse output.
FLMD EEMD Electronic Shutter mode WIND
Electronic exposure
and WIND pulse
control input 1
19 FLMD
20 EEMD
ICU
ICU
–
–
L
H
L
L
L
H
H
EIA : 1/60 s, CCIR : 1/50 s WIND1
EIA : 1/100 s, CCIR : 1/120 s WIND1
Electronic exposure mode WIND1
Electronic exposure mode WIND2
Electronic exposure
and WIND pulse
control input 2
H
WIND1 : Vertical pulse
WIND2 : Composite pulse (vertical and horizontal)
3
LZ9FD34
PIN NO. SYMBOL
I/O
POLARITY
PIN NAME
DESCRIPTION
An input pin to control electronic exposure.
Electronic exposure
control input 1
21 EEUD
IC
–
EEUD EENR
Shutter Speed
up
H
H
L
L
H
H
control stopped
down
Electronic exposure
control input 2
22 EENR
IC
–
23 FCDS
24 FS
25 TST6
O4MA2
O4MA2
ICD
CDS pulse output 1 A pulse to clamp the feed-through level from CCD.
CDS pulse output 2 A pulse to sample-hold the signal from CCD.
–
–
–
Test pin 6
A test pin. Set open or to L level in the normal mode.
An input pin to select sensor type.
26 CCD
ICU
CCD selection input
H level or open
L level
: 410 k, 470 k pixel CCD
: 270 k, 320 k pixel CCD
27 TST7
28 V1X
ICD
O
Test pin 7
A test pin. Set open or to L level in the normal mode.
A vertical transfer pulse for CCD.
Connect to V1AX pin of vertical driver IC.
A vertical transfer pulse for CCD.
Connect to V2AX pin of vertical driver IC.
Supply of +5 V power.
A grounding pin.
Vertical transfer
pulse output 1
Vertical transfer
pulse output 2
Power supply
Ground
29 V2X
O
30 VDD
31 GND
–
–
–
–
Vertical transfer
pulse output 3
Vertical transfer
pulse output 4
A vertical transfer pulse for CCD.
Connect to V3AX pin of vertical driver IC.
A vertical transfer pulse for CCD.
Connect to V4AX pin of vertical driver IC.
A pulse that transfers the charge of the photo-diode to
the vertical shift register. Connect to VH1AX pin or VH1BX
pin of vertical driver IC.
A pulse that transfers the charge of the photo-diode to
the vertical shift register. Connect to VH3AX pin or VH3BX
pin of the vertical driver IC.
32 V3X
33 V4X
O
O
Readout pulse
output
34 VH1X
35 VH3X
O
O
Readout pulse
output
A pulse that sweeps the charge of the photo-diode for
the electronic shutter. Connect to OFD pin of CCD
through the vertical driver IC and DC offset circuit.
Held at H level at normal mode.
36 OFDX
37 ITCH
38 EEST
O
OFD pulse output
An input pin to select accumulation mode.
Accumulation mode
selection input
ICU
ICU
–
–
H level or open
L level
: Field accumulation mode
: Frame accumulation mode
An input pin to control electronic exposure using EEUD
Electronic exposure (pin 21) and EENR (pin 22).
control input 3
H level or open
L level
: Electronic exposure is operated.
: Electronic exposure is stopped.
4
LZ9FD34
PIN NO. SYMBOL
I/O
POLARITY
PIN NAME
DESCRIPTION
An output pin for window pulse.
EEMD FLMD
WIND
L
L
H
H
L
H
L
WIND1 (vertical pulse)
ON
H
WIND2 (composite pulse)
39 WIND
N-ch
Open
Drain
Window pulse output WIND1 : When connected to EEST (pin 38), the
operation of electronic exposure can be
(
)
stopped at the upper side of monitor.
WIND2 : A pulse that picks out the center of CCD output.
At this time, set H level or open at EEST (pin
38). As the output circuit of WIND is N-ch open
drain, connect to VDD with R (≥ 47 k$).
A pulse to reset the charge of output circuit.
Connect to ØR pin of CCD through the DC offset circuit.
40 FR
O4MA3
Reset pulse output
41 VDD
42 FH2
43 GND
44 FH1
45 VDD
–
O4MA3
–
–
–
–
Power supply
Horizontal transfer
pulse output 2
Ground
Horizontal transfer
pulse output 1
Power supply
Supply of +5 V power.
A pulse to drive horizontal CCD shift register.
Connect to ØH2 pin of CCD.
A grounding pin.
A pulse to drive horizontal CCD shift register.
Connect to ØH1 pin of CCD.
O4MA3
–
Supply of +5 V power.
An input pin for reference clock oscillation.
Connect to OSCO (pin 47) with R.
The frequencies are as follows :
TVMD CCD
Frequency
46 OSCI
OSCI
–
–
Clock input
L
L
H
H
L
H
L
19.0699 MHz (1 212 fH)
28.6364 MHz (1 820 fH)
19.3125 MHz (1 236 fH)
28.3750 MHz (1 816 fH)
fH = Horizontal frequency
H
An output pin for reference clock oscillation.
The output is the inverse of OSCI (pin 46).
47 OSCO
OSC3M
Clock output
5
LZ9FD34
PIN NO. SYMBOL
I/O
POLARITY
PIN NAME
DESCRIPTION
An input pin to select non-interlace mode.
L level or open
H level
Period of field (at non-interlace mode)
: Interlace mode
: Non-interlace mode
Non-interlace
selection input
48 NINT
ICD
–
TVMD
L
H
Field
ODD
1st
Number of Line
262H
312H
IC
ICU
ICSU
: Input pin (CMOS level)
O4MA2 : Output pin
O4MA3 : Output pin
: Input pin (CMOS level with pull-up resistor)
: Input pin (CMOS schmitt-trigger level with pull-up
resistor)
ON
: Output pin (N-ch open drain)
: Input pin for oscillation
OSCI
ICD
O
: Input pin (CMOS level with pull-down resistor)
: Output pin
OSC3M : Output pin for oscillation
SUPPLEMENTARY EXPLANATION
Shutter speed changes at electronic exposure control mode.
EIA
CCIR
Charge time
312H or 313H
302H + ß
No.
0
1
Charge Time
262H or 263H
252H + Ω
Shutter Speed
No.
0
1
Shutter Speed
∏ 1/
∏ 1/
60 s
62 s
∏ 1/
∏ 1/
50 s
52 s
•
19
•
30
•
37
•
44
•
50
•
62
•
69
70
71
(by 10H step)
72H + Ω
(by 4H step)
28H + Ω
(by 2H step)
14H + Ω
(by 1H step)
7H + Ω
(by 0.5H step)
4H + Ω
(by 0.25H step)
1H + Ω
(by 0.125H step)
0.125H + Ω
0.280H
•
24
•
35
•
42
•
49
•
55
•
67
•
74
75
76
(by 10H step)
72H + ß
(by 4H step)
28H + ß
(by 2H step)
14H + ß
(by 1H step)
7H + ß
(by 0.5H step)
4H + ß
(by 0.25H step)
1H + ß
(by 0.125H step)
0.125H + ß
0.275H
∏ 1/
∏ 1/
220 s
555 s
∏ 1/
∏ 1/
220 s
550 s
∏ 1/ 1 100 s
∏ 1/ 2 140 s
∏ 1/ 3 610 s
∏ 1/ 11 570 s
∏ 1/ 1 090 s
∏ 1/ 2 125 s
∏ 1/ 3 590 s
∏ 1/ 11 550 s
∏ 1/ 32 450 s
∏ 1/ 56 090 s
∏ 1/101 430 s
∏ 1/ 32 690 s
∏ 1/ 56 800 s
∏ 1/102 720 s
0.155H
0.152H
Ω = 0.360H
ß = 0.353H
6
LZ9FD34
ABSOLUTE MAXIMUM RATINGS
PARAMETER
Supply voltage
SYMBOL
VDD
RATING
–0.3 to +6.0
UNIT
V
Input voltage
Output voltage
Operating temperature
Storage temperature
VI
VO
TOPR
TSTG
–0.3 to VDD + 0.3
–0.3 to VDD + 0.3
–30 to +70
V
V
˚C
˚C
–55 to +150
ELECTRICAL CHARACTERISTICS
DC Characteristics
(VDD = 5.0±0.5 V, TOPR = –30 to +70 ˚C)
PARAMETER
Input "Low" voltage
SYMBOL
VIL
CONDITIONS
MIN.
TYP. MAX. UNIT NOTE
1.5
3.7
V
V
V
V
V
1
2
Input "High" voltage
Input "Low" voltage
Input "High" voltage
Hysteresis voltage
VIH
VT+
VT–
3.5
1.0
0.2
VT+ – VT–
|IIL1|
|IIH1|
|IIL2|
|IIH2|
|IIL3|
|IIH3|
VOL1
Input "Low" current
Input "High" current
Input "Low" current
Input "High" current
Input "Low" current
Input "High" current
Output "Low" voltage
Output "High" voltage
Output "Low" voltage
Output "High" voltage
Output "Low" voltage
Output "High" voltage
Output "Low" voltage
Output "High" voltage
Output "Low" voltage
Output leakage current
VI = 0 V
VI = VDD
VI = 0 V
VI = VDD
VI = 0 V
2.0
2.0
75
2.0
2.0
75
µA
µA
µA
µA
µA
µA
V
V
V
V
V
3
4
8.0
5
VI = VDD
8.0
4.0
4.0
4.0
4.0
IOL = 3 mA
IOH = –3 mA
IOL = 4 mA
IOH = –2 mA
IOL = 8 mA
IOH = –6 mA
IOL = 12 mA
IOH = –9 mA
IOL = 4 mA
High-Z
0.4
6
VOH1
VOL2
VOH2
VOL3
VOH3
VOL4
VOH4
VOL5
0.4
0.4
0.4
7
8
V
V
V
9
0.4
1.0
V
µA
10
|IOZ|
NOTES :
1. Applied to inputs (IC, ICD, ICU, OSCI).
2. Applied to input (ICSU).
3. Applied to inputs (IC, OSCI).
4. Applied to inputs (ICU, ICSU).
5. Applied to input (ICD).
6. Applied to output (OSC3M). (Output (OSC3M) measures
on condition that input (OSCI) level is 0 V or VDD.)
7. Applied to output (O).
8. Applied to output (O4MA2).
9. Applied to output (O4MA3).
10. Applied to output (ON).
7
PACKAGES FOR CCD AND CMOS DEVICES
PACKAGE
(Unit : mm)
48 QFP (QFP048-P-0707)
±0.05
0.15
TYP.
±0.08
25
0.5
0.2
36
37
24
13
48
1
(1.0)
12
(1.0)
±0.2
±0.3
±0.2
7.0
9.0
0.65
1.45
±0.2
±0.1
0.1
8
厂商 型号 描述 页数 下载

ETC

 		LZ9-00CW00 高光效冷白色LED发光器[ High Luminous Efficacy Cool White LED Emitter ] 22 页

ETC

 		LZ9-00GW00-0027 [ LED WARM WHITE 2700K 98CRI 24SMD ] 23 页

ETC

 		LZ9-00GW00-0028 [ LED WARM WHITE 2850K 98CRI 24SMD ] 23 页

ETC

 		LZ9-00GW00-0030 [ LED WARM WHITE 3000K 98CRI 24SMD ] 23 页

ETC

 		LZ9-00GW00-0230 [ LED WARM WHITE 3000K 95CRI 24SMD ] 23 页

ETC

 		LZ9-00GW00-0430 [ LED WARM WHITE 3000K 95CRI 24SMD ] 23 页

ETC

 		LZ9-00NW00 高光效中性白光LED发射器[ High Luminous Efficacy Neutral White LED Emitter ] 22 页

ETC

 		LZ9-00NW00-0040 [ LED NEUTRAL WHITE 4000K 24SMD ] 20 页

ETC

 		LZ9-00W900 高光效暖白光LED发光器[ High Luminous Efficacy Warm White LED Emitter ] 23 页

ETC

 		LZ9-00WW00 高光效暖白光LED发光器[ High Luminous Efficacy Warm White LED Emitter ] 23 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.188727s
