IXGP 28N120B
Symbol
gfs
TestConditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
TO-220 Outline
IC = 28A; VCE = 10 V,
18
25
S
Pulse test, t ≤ 300 µs, duty cycle ≤ 2 %
Cies
Coes
Cres
2700
170
60
pF
pF
pF
VCE = 25 V, VGE = 0 V, f = 1 MHz
Qg
Qge
Qgc
92
15
30
nC
nC
nC
IC = 28A, VGE = 15 V, VCE = 0.5 VCES
Pins: 1 - Gate
3 - Source
2 - Drain
4 - Drain
td(on)
tri
td(off)
tfi
30
20
180
160
2.0
ns
ns
280 ns
320 ns
5.0 mJ
Inductive load, TJ = 25°C
IC = 28 A, VGE = 15 V
VCE = 0.8 VCES, RG = Roff = 5 Ω
Eoff
td(on)
tri
Eon
td(off)
tfi
35
28
1.4
250
300
ns
ns
mJ
ns
ns
Inductive load, TJ = 125°C
IC = 28A, VGE = 15 V
VCE = 0.8 VCES, RG = Roff = 5 Ω
Eoff
8.0
mJ
RthJC
RthCK
0.5 K/W
K/W
0.25
IXYS reserves the right to change limits, test conditions, and dimensions.
IXYSMOSFETs andIGBTsarecovered byoneormore
ofthefollowingU.S.patents:
4,835,592 4,881,106 5,017,508 5,049,961 5,187,117 5,486,715 6,306,728B1 6,259,123B1 6,306,728B1
4,850,072 4,931,844 5,034,796 5,063,307 5,237,481 5,381,025 6,404,065B1 6,162,665 6,534,343
