4N32-3053
Vishay Semiconductors
Optocoupler, Photodarlington Output, High Gain,
with Base Connection
FEATURES
• Very high current transfer ratio,
500 % Min.
11
• High isolation resistance, 10 Ω typical
• Standard plastic DIP package
• Lead (Pb)-free component
1
6
A
C
B
C
E
5
4
2
3
NC
• Component in accordance to
RoHS 2002/95/EC and WEEE 2002/96/EC
i179005
DESCRIPTION
AGENCY APPROVALS
The 4N32 is an optically coupled isolators with a
• UL1577, File No. E52744 system code H or J,
Double protection
• DIN EN 60747-5-2 (VDE0884)
DIN EN 60747-5-5 pending
available with option 1
gallium arsenide infrared LED and
photodarlington sensor.
a
solicon
Switching can be achieved while maintaining a high
degree of isolation between driving and load circuits.
These optocouplers can be used to replace reed and
mercury relays with advantages of long life, high speed
switching and elimination of magnetic fields.
• BSI IEC60950 IEC60065
CUSTOMER SPECIFIC INFORMATION
• This is a custom product for ISOCOM.
• The product is unmarked.
• Product will be shipped in unmarked rails in
unmarked cartons.
• This product is of over-under double molded
construction.
ORDER INFORMATION
PART
REMARKS
4N32-3053
CTR > 500 %, DIP-6
Document Number 81721
Rev. 1.0, 27-Jun-07
For technical support, please contact: optocoupler.answers@vishay.com
www.vishay.com
1
4N32-3053
Vishay Semiconductors
1, 2)
ABSOLUTE MAXIMUM RATINGS
PARAMETER
TEST CONDITION
SYMBOL
VALUE
UNIT
INPUT
VR
IF
Peak reverse voltage
3.0
60
V
mA
Forward continuous current
Pdiss
Power dissipation
100
1.33
mW
Derate linearly
from 55 °C
mW/°C
OUTPUT
BVCEO
BVEBO
BVCBO
BVECO
IC
Collector-emitter breakdown voltage
30
8.0
50
V
V
Emitter-base breakdown voltage
Collector-base breakdown voltage
Emitter-collector breakdown voltage
Collector (load) current
V
5.0
125
150
2.0
V
mA
mW
mW/°C
Pdiss
Power dissipation
Derate linearly
COUPLER
Ptot
Total dissipation
Derate linearly
250
3.3
mW
mW/°
VRMS
Isolation test voltage
VISO
5300
(between emitter and detector,
Standard Climate:
23 °C/ 50 %RH, \\nDIN 500 14)
Leakage path
Air path
7.0
7.0
≥ 1012
mm min.
mm min.
Ω
VIO = 500 V, Tamb = 25 °C
VIO = 500 V, Tamb = 100 °C
RIO
RIO
Isolation resistance
≥ 1011
- 55 to + 150
- 55 to + 100
10
Ω
°C
°C
s
Tamb
Tstg
Storange temperature
Operating temperature
Lead soldering time
at 260 °C
Note:
1)
T
= 25 °C unless otherwise specified.
amb
2) Stresses in excess of the absolute Maximum Ratings can cause permanent damage to the device. Functional operation of the device is not
implied at these or any other conditions in excess of those given in the operational sections of this document. Exposure to absolute Maximum
Rating for extended periods of the time can adversely affect reliability.
For technical support, please contact: optocoupler.answers@vishay.com
www.vishay.com
2
Document Number 81721
Rev. 1.0, 27-Jun-07
4N32-3053
Vishay Semiconductors
1, 2)
ELECTRICAL CHARACTERISTICS
PARAMETER
TEST CONDITION
SYMBOL
MIN
TYP.
MAX
UNIT
INPUT
IF = 50 mA
VR = 3.0 V
VR = 0 V
VF
IR
Forward voltage
1.25
0.1
25
1.5
V
µ
Reverse current
100
CO
Capacitance
pF
OUTPUT
Collector-emitter breakdown
voltage3)
IC = 100 µA, IF = 0
IC = 100 µA, IF = 0
IC = 100 µA, IF = 0
IC = 100 µA, IF = 0
BVCEO
BVCBO
BVEBO
BVECO
30
50
V
V
Collector-base breakdown
voltage3)
Emitter-base breakdown
voltage3)
8.0
5.0
V
Emitter-collector breakdown
voltage3)
10
V
Collector-emitter leakage current
VCE = 10 V, IF = 0
ICEO
hFE
1.0
100
nA
I
C = 0.5 mA, VCE = 5.0 V
13
COUPLER
VCEsat
Colector emitter saturation voltage
Coupling capacitance
1.0
1.5
V
pF
Note:
1)
2)
T
= 25 °C unless otherwise specified.
amb
Minimum and maximum values are testing requirements. Typical values are characteristics of the device and are the result of engineering
evaluation. Typical values are for information only and are not part of the testing requirements.
3) Indicates JEDEC registered values.
CURRENT TRANSFER RATIO
PARAMETER
TEST CONDITION
SYMBOL
MIN
TYP.
TYP.
MAX
UNIT
VCE = 10 V, IF = 10 mA,
Current transfer ratio
CTR
500
%
SWITCHING CHARACTERISTICS
PARAMETER
Turn on time
Turn off time
TEST CONDITION
SYMBOL
MIN
MAX
5.0
UNIT
µs
VCC = 10 V, IC = 50 mA
ton
IF = 200 mA, RL = 180 Ω
toff
100
µs
Document Number 81721
Rev. 1.0, 27-Jun-07
For technical support, please contact: optocoupler.answers@vishay.com
www.vishay.com
3
4N32-3053
Vishay Semiconductors
TYPICAL CHARACTERISTICS
T
= 25 °C unless otherwise specified
amb
10000
1.2
Normalized to:
Ta = 25 °C
Vce = 5 V
Vce = 5 V
IF = 10 mA
Ta = 25 °C
1.0
0.8
0.6
0.4
0.2
0.0
8000
6000
4000
Vce = 5 V
Vce = 1 V
Vce = 1 V
2000
0
0.1
1
10
100
1000
0.01
0.1
1
10
100
IF - LED Current (mA)
Ib - Base Current (µA)
i4n32-33_02
i4n32-33_05
Figure 1. Normalized Non-saturated and Saturated CTRCE vs.
LED Current
Figure 4. Non-Saturated and Saturated HFE vs. Base Current
80
10
Normalized to:
Ta = 25 °C
IF = 10 mA
Vce = 5 V
Vce = 5 V
Vce = 1 V
Ta = 25 °C, Vcc = 5 V
1.0 kΩ
Vth = 1.5 V
1
0.1
60
220 Ω
40
470 Ω
0.01
0.001
20
100 Ω
0
100
0
5
10
15
20
10
IF - LED Current (mA)
0.1
1
i4n32-33_03
i4n32-33_06
IF - LED Current (mA)
Figure 2. Normalized Non-Saturated and Saturated
Collector-Emitter Current vs. LED Current
Figure 5. Low to High Propagation Delay vs.
Collector Load Resistance and LED Current
10
20
15
10
5
Normalized to:
Ta = 25 °C
1 kΩ
Ta = 25 °C
Vcc = 5 V
Vth = 1.5 V
1
Vcb = 3.5 V
IF = 10 mA
0.1
100 Ω
0.01
0.001
0
0
5
10
IF - LED Current (mA)
15
20
0.1
1
10
100
i4n32-33_07
i4n32-33_04
IF = LED Current (mA)
Figure 3. Normalized Collector-Base Photocurrent vs.
LED Current
Figure 6. High to low Propagation Delay vs.
Collector Load Resistance and LED Current
For technical support, please contact: optocoupler.answers@vishay.com
www.vishay.com
4
Document Number 81721
Rev. 1.0, 27-Jun-07
4N32-3053
Vishay Semiconductors
I
F
V
CC
R
L
t
R
D
V
O
t
V
O
t
PLH
I
F
V
TH
=1.5 V
t
F
t
t
S
PHL
i4n32-33_08
Figure 7. Switching Waveform and Switching Schematic
PACKAGE DIMENSIONS in inches (millimeters)
DIP-6 Package Dimensions
pin one ID
2
1
3
0.248 (6.30)
0.256 (6.50)
ISO Method A
4
5
6
0.335 (8.50)
0.343 (8.70)
0.300 (7.62)
typ.
(0.45)
0.048
0.022 (0.55)
0.039
(1.00)
Min.
0.130 (3.30)
0.150 (3.81)
18°
4°
0.114 (2.90)
0.130 (3.0)
typ.
0.031 (0.80) min.
3°- 9°
0.010 (0.25)
typ.
0.031 (0.80)
0.035 (0.90)
0.018 (0.45)
0.022 (0.55)
0.300 – 0.347
(7.62– 8.81)
0.100 (2.54) typ.
i178004
Document Number 81721
Rev. 1.0, 27-Jun-07
For technical support, please contact: optocoupler.answers@vishay.com
www.vishay.com
5
4N32-3053
Vishay Semiconductors
Ozone Depleting Substances Policy Statement
It is the policy of Vishay Semiconductor GmbH to
1. Meet all present and future national and international statutory requirements.
2. Regularly and continuously improve the performance of our products, processes, distribution and operating
systems with respect to their impact on the health and safety of our employees and the public, as well as their
impact on the environment.
It is particular concern to control or eliminate releases of those substances into the atmosphere which are known as
ozone depleting substances (ODSs).
The Montreal Protocol (1987) and its London Amendments (1990) intend to severely restrict the use of ODSs and
forbid their use within the next ten years. Various national and international initiatives are pressing for an earlier ban
on these substances.
Vishay Semiconductor GmbH has been able to use its policy of continuous improvements to eliminate the use of
ODSs listed in the following documents.
1. Annex A, B and list of transitional substances of the Montreal Protocol and the London Amendments respectively
2. Class I and II ozone depleting substances in the Clean Air Act Amendments of 1990 by the Environmental
Protection Agency (EPA) in the USA
3. Council Decision 88/540/EEC and 91/690/EEC Annex A, B and C (transitional substances) respectively.
Vishay Semiconductor GmbH can certify that our semiconductors are not manufactured with ozone depleting
substances and do not contain such substances.
We reserve the right to make changes to improve technical design
and may do so without further notice.
Parameters can vary in different applications. All operating parameters must be validated for each customer
application by the customer. Should the buyer use Vishay Semiconductors products for any unintended or
unauthorized application, the buyer shall indemnify Vishay Semiconductors against all claims, costs, damages, and
expenses, arising out of, directly or indirectly, any claim of personal damage, injury or death associated with such
unintended or unauthorized use.
Vishay Semiconductor GmbH, P.O.B. 3535, D-74025 Heilbronn, Germany
For technical support, please contact: optocoupler.answers@vishay.com
www.vishay.com
6
Document Number 81721
Rev. 1.0, 27-Jun-07
Legal Disclaimer Notice
Vishay
Notice
Specifications of the products displayed herein are subject to change without notice. Vishay Intertechnology, Inc.,
or anyone on its behalf, assumes no responsibility or liability for any errors or inaccuracies.
Information contained herein is intended to provide a product description only. No license, express or implied, by
estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Vishay's
terms and conditions of sale for such products, Vishay assumes no liability whatsoever, and disclaims any express
or implied warranty, relating to sale and/or use of Vishay products including liability or warranties relating to fitness
for a particular purpose, merchantability, or infringement of any patent, copyright, or other intellectual property right.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications.
Customers using or selling these products for use in such applications do so at their own risk and agree to fully
indemnify Vishay for any damages resulting from such improper use or sale.
Document Number: 91000
Revision: 08-Apr-05
www.vishay.com
1
厂商 型号 描述 页数 下载

MOTOROLA

 		4N30 标准通孔CASE 730A -04[ STANDARD THRU HOLE CASE 730A-04 ] 6 页

TOSHIBA

 		4N30 光电晶体管（ AC LINE /数字逻辑隔离器）[ PHOTO TRANSISTOR (AC LINE/DIGITAL LOGIC ISOLATOR) ] 5 页

QT

 		4N30 通用6 -PIN PHOTODARLINGTON光耦合器[ GENERAL PURPOSE 6-PIN PHOTODARLINGTON OPTOCOUPLERS ] 6 页

EVERLIGHT

 		4N30 6 PIN PHOTODARLINGTON PHOTOCOUPLER[ 6 PIN PHOTODARLINGTON PHOTOCOUPLER ] 13 页

ISOCOM

 		4N30 光耦合隔离器PHOTODARLINGTON输出[ OPTICALLY COUPLED ISOLATOR PHOTODARLINGTON OUTPUT ] 3 页

FAIRCHILD

 		4N30 通用6引脚光电复合光耦[ General Purpose 6-Pin Photodarlington Optocoupler ] 13 页

NJSEMI

 		4N30 光子耦合型隔离器[ Photon Coupled Isolator ] 1 页

TOSHIBA

 		4N30(TP1) [ Optocoupler - Transistor Output, 1 CHANNEL DARLINGTON OUTPUT OPTOCOUPLER, DIP-6 ] 5 页

TOSHIBA

 		4N30(TP4) [ Optocoupler - Transistor Output, 1 CHANNEL DARLINGTON OUTPUT OPTOCOUPLER, DIP-6 ] 5 页

TOSHIBA

 		4N30(TP5) [ Optocoupler - Transistor Output, 1 CHANNEL DARLINGTON OUTPUT OPTOCOUPLER, DIP-6 ] 5 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.209755s
