Switchcraft
Type 12BL6M - typical Male plug with ground key-rib. Nickel-plated diecast handle.
Contact friction coupling. Flexible black strain relief. Heavy duty cable clamp.
ORDERING INFORMATION
Pin
Arrangement
Part Number
Description
¤03BL2M
05BL3M
05BL5M
09BL4M
12BL5M
12BL6M
¤15BL7M
¤15BL8M
2 pins with insulated switch actuator
3 pins at 180°
1
2
5
3
4
6
7
8
5 pins at 180°
4 pins at 210°
5 pins at 240°
6 pins at 240°
7 pins at 270°
8 pins at 270°
RIGHT-ANGLE CORD PLUG with 8 Position Barrel and 30° Lockring
Type 05YL5M - typical Right-angle chassis hugging, male plug with flexible strain
relief. Unique 8-position barrel gives you a choice of any one of eight different cable entry
angles. ground key rib 30¡ turn lockring securely fastens two halves of connector.
ORDERING INFORMATION
Pin
Arrangement
Part Number
Description
¤05YL3M
¤05YL5M
¤09YL4M
¤12YL5M
3 pins at 180°
5 pins at 180°
4 pins at 210°
5 pins at 240°
2
5
3
4
RIGHT-ANGLE CORD PLUG with 8 Position Barrel
Type 05DL5M - typical Right-angle chassis hugging, male plug with flexible black
rubber strain relief. Unique 8-position barrel offers a choice of eight different cable entry
