Product Name
Series
Type
Chip Beads Array
MZA Series
1210 Type
Part Number
MZA1210D680CT000
Product Lifecycle Stage PROD
Specification
Summary/Applications/Feature
The MZA series provide effective EMC
Mounting Method Flag
Processing
Yes
suppression in signal lines through simple in-
series implementation. 4lines array component.
It is applicable for lead free soldering.
MULTI-LAYER
Chip-Array
Summary
Shape
Number of Circuits
Material Code
Size Code
Nom
2
Applications PC,DVD,CDMA,LCD,PDC
The MZA series provide effective EMC
D
suppression in signal lines through simple in-
series implementation.
2lines array component.
1210
Feature
Body Length(L)
Body Breadth(W)
Body Height(T)
Impedance
Nom
Nom
Nom
Min
1.25 m m
1 m m
It is applicable for lead free soldering.
0.5 m m
Packaging
Packing
51 Ohm
Punched (Paper)Taping
[180mm Reel]
Impedance
Nom
Min
68 Ohm
-25 %
Minumum Package Qty Nom
Minimum Order Qty Nom
5000 Pcs
5000 Pcs
Impedance Tolerance
Max
Nom
Max
Max
Min
25 %
Frequency of Impedance
Rated Current
100 M Hz
0.05 A
DC Resistance
0.5 Ohm
10 M Ohm
Insulation Resistance
Soldering Method
Reflow,Iron Soldering
Min
Max
Min
Max
Nom
-55 Cel
125 Cel
-55 Cel
125 Cel
0.003 g
Category Temperature
Range
Storage Temperature Range
Weight
[ Caution ]
Specifications which provide more details for the proper
and safe use of the described product are available upon request.
[ Notice of Revision and Improve ]
All specifications are subject to change without notice.
