IXGA20N250HV
Symbol
Test Conditions
Characteristic Values
TO-263 (HV) Outline
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
IC = 20A, VCE = 10V, Note 1
VGE = 20V, VCE = 15V, Note 1
8
13
S
A
IC(ON)
190
Cies
Coes
Cres
1190
53
pF
pF
pF
VCE = 15V, VGE = 25V, f = 1MHz
IC = 20A, VGE = 15V, VCE = 1000V
18
Qg
53
8
nC
nC
nC
Qge
Qgc
22
PIN: 1 - Gate
2 - Emitter
3 - Collector
td(on)
57
ns
Resistive Switching Times
IC = 40A, VGE = 15V, Note 1
VCE = 1250V, RG = 10Ω
tr
td(off)
160
136
ns
ns
tf
930
ns
RthJC
0.83 °C/W
Note
1. Pulse test, t < 300μs, duty cycle, d < 2%.
PRELIMANARY TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are
derived from a subjective evaluation of the design, based upon prior knowledge and experi-
ence, and constitute a "considered reflection" of the anticipated result. IXYS reserves the right
to change limits, test conditions, and dimensions without notice.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
