PLASTIC FILM CAPACITORS
Metallized Polyester Film Capacitor
XNseries (Extended Standard Type)
Highly reliable and superior performance in high frequency applications, self-healing and non-
inductive construction, using a dielectric made of polyethylene terephthalate film covered with
vacuum-evaporated metal.
Large capacitance in small dimensions.
Finished by inner dipping with liquid epoxy resin and outer coating with flame-retardant epoxy
resin, those double coating provides excellent humidity resistance.
Designed 1mm max. of epoxy on lead wire for best performance at soldering process on P.C.
board assemblies.
Taping type (capacitor width (W) must be 20.0mm or less.) for automatic
insertion systems is also available.
Applications
Type numbering system
(Example : 630V 0.01µF)
General electronic and communications equipment. Contact us for details
for use in AC circuits.
F size
7.5
Code
7FG
7FJ
However, do not use this product for across-the-line applications.
10.0
15.0
22.5
27.5
1
2
3
4
5
6
7
8
9 10 11
7FM
7FT
7FX
Q X N 2 J 1 0 3 K T P
Specifications
Cut / formed lead type
Configuration
(TP : Polyester film, Soldered CP wire)
Capacitance tolerance (J : ±5% K : ±10%)
Rated Capacitance (0.01µF)
Item
Performance Characteristics
Category Temperature Range
Rated Voltage (U )
RatedCapacitance Range
Capacitance Tolerance
Dielectric Loss Tangent
Insulation Resistance
–40 ~ +105˚C (Rated temperature : 85˚C)
100, 250, 400, 630V.D.C.
0.01 ~ 10µF
R
± 5% (J), ± 10% (K)
0.8% or less (at 1kHz 20˚C)
<
Rated voltage (630V)
C
0.33µF : 9000 MΩ or more C > 0.33µF : 3000 ΩF or more
=
Series name
Type
Between Terminals
: Rated Voltage × 175%, 1 ~ 5 secs.
Withstand Voltage
Encapsulation
Between Terminals and Coverage : Rated Voltage × 200%, 1 ~ 5 secs.
WMAX
TMAX
TMAX
WMAX
Flame retardant epoxy resin
×
Category voltage = U 0.7
R
AC Rated Voltage
AC rated voltage (Operating at 50 / 60Hz AC circuit)
H+0.5MAX
5MAX
H+0.5MAX
Drawing
1MAX
shall be as follows.However, do not use this product for across-the-line applications.
φd ± 0.05
4.5 ± 0.5
25MIN
φd ± 0.05
DC Rated Voltage
AC Rated Voltage
100VDC
050VAC
250VDC
125VAC
400VDC
200VAC
630VDC
250VAC
F±1.5
When operating capacitors in the high frequency circuit, maximum permissible value (VAC) can be calculated
from table 2, provided that the effective current (le) and the effective VA (Ve x Ve) shall not exceed
P±1.5
Straight lead type.
Cut / formed lead type.
Unit : mm
the values specified in table 5.
Dimensions
V(Code)
160VDC (2A)
250VDC (2E)
400VDC (2G)
630VDC (2J)
Size
Cap.(µF)
T
103
123
153
183
223
273
333
393
473
563
683
823
104
124
154
184
224
274
334
394
474
564
684
824
105
125
155
185
225
275
335
395
475
565
685
825
106
W
H
d
P
F
T
W
H
d
P
F
T
W
H
d
P
F
T
W
H
d
P
F
0.01
4.4 10.5 7.6 0.6 7.5 7.5 4.4 10.5 7.6 0.6 7.5 7.5 4.4 13.0 9.0 0.6 10.0 10.0
4.7 10.5 8.2 0.6 7.5 7.5 4.7 10.5 8.2 0.6 7.5 7.5 4.4 13.0 9.0 0.6 10.0 10.0
5.0 10.5 8.2 0.6 7.5 7.5 5.0 10.5 8.2 0.6 7.5 7.5 4.7 13.0 9.3 0.6 10.0 10.0
4.4 10.5 8.0 0.6 7.5 7.5 4.3 10.5 8.4 0.6 7.5 7.5 4.8 13.0 10.0 0.6 10.0 10.0
4.4 10.5 8.0 0.6 7.5 7.5 4.3 10.5 7.9 0.6 7.5 7.5 5.1 13.0 10.3 0.6 10.0 10.0
4.4 10.5 8.0 0.6 7.5 7.5 4.6 10.5 8.2 0.6 7.5 7.5 5.5 13.0 10.7 0.6 10.0 10.0
4.4 10.5 8.0 0.6 7.5 7.5 4.9 10.5 8.6 0.6 7.5 7.5 5.9 13.0 11.1 0.6 10.0 10.0
4.6 10.5 8.3 0.6 7.5 7.5 4.5 13.0 9.1 0.6 10.0 10.0 6.5 13.0 11.1 0.6 10.0 10.0
4.0 10.5 7.6 0.6 7.5 7.5 4.7 13.0 9.3 0.6 10.0 10.0 6.4 13.0 13.2 0.6 10.0 10.0
4.2 10.5 7.9 0.6 7.5 7.5 4.7 13.0 9.6 0.6 10.0 10.0 5.4 18.0 10.6 0.6 15.0 15.0
4.7 10.5 8.2 0.6 7.5 7.5 5.4 13.0 10.0 0.6 10.0 10.0 5.8 18.0 11.0 0.6 15.0 15.0
4.8 10.5 8.5 0.6 7.5 7.5 5.8 13.0 10.4 0.6 10.0 10.0 5.9 18.0 12.7 0.6 15.0 15.0
5.2 10.5 8.9 0.6 7.5 7.5 6.1 13.0 11.2 0.6 10.0 10.0 6.4 18.0 13.2 0.6 15.0 15.0
5.6 10.5 9.2 0.6 7.5 7.5 5.0 18.0 10.3 0.6 15.0 15.0 6.4 18.0 14.8 0.6 15.0 15.0
6.1 10.5 9.8 0.6 7.5 7.5 5.1 18.0 11.9 0.6 15.0 15.0 7.1 18.0 15.4 0.6 15.0 15.0
5.2 13.0 10.4 0.6 10.0 10.0 5.5 18.0 12.3 0.6 15.0 15.0 8.3 18.0 15.0 0.6 15.0 15.0
5.9 13.0 10.5 0.6 10.0 10.0 5.9 18.0 12.7 0.6 15.0 15.0 9.6 18.0 14.8 0.6 15.0 15.0
6.2 13.0 11.4 0.6 10.0 10.0 6.5 18.0 13.3 0.6 15.0 15.0 7.2 25.0 15.5 0.8 22.5 22.5
6.7 13.0 11.9 0.6 10.0 10.0 7.6 18.0 12.8 0.6 15.0 15.0 7.9 25.0 16.2 0.8 22.5 22.5
5.1 18.0 11.9 0.6 15.0 15.0 8.2 18.0 13.4 0.6 15.0 15.0 8.5 25.0 16.9 0.8 22.5 22.5
5.5 18.0 12.3 0.6 15.0 15.0 8.3 18.0 15.1 0.6 15.0 15.0 9.4 25.0 17.7 0.8 22.5 22.5
5.5 18.0 13.8 0.6 15.0 15.0 6.6 25.0 15.0 0.8 22.5 22.5 10.2 25.0 18.6 0.8 22.5 22.5
6.0 18.0 14.3 0.6 15.0 15.0 7.2 25.0 15.6 0.8 22.5 22.5 11.3 25.0 19.6 0.8 22.5 22.5
6.5 18.0 14.8 0.6 15.0 15.0 7.9 25.0 16.3 0.8 22.5 22.5 10.8 30.0 19.4 0.8 27.5 27.5
7.1 18.0 15.5 0.6 15.0 15.0 8.7 25.0 17.1 0.8 22.5 22.5 12.0 30.0 20.5 0.8 27.5 27.5
8.3 18.0 15.1 0.6 15.0 15.0 9.6 25.0 17.9 0.8 22.5 22.5 13.2 30.0 21.7 0.8 27.5 27.5
9.9 18.0 15.1 0.6 15.0 15.0 9.4 30.0 18.0 0.8 27.5 27.5 14.8 30.0 23.3 0.8 27.5 27.5
7.4 25.0 15.7 0.8 22.5 22.5 10.3 30.0 18.9 0.8 27.5 27.5 16.3 30.0 24.8 0.8 27.5 27.5
8.1 25.0 16.5 0.8 22.5 22.5 11.5 30.0 20.0 0.8 27.5 27.5 18.5 30.0 27.5 0.8 27.5 27.5
9.0 25.0 17.4 0.8 22.5 22.5
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.1
4.4 10.5 8.0 0.6 7.5 7.5
4.4 10.5 8.0 0.6 7.5 7.5
4.4 10.5 8.0 0.6 7.5 7.5
4.4 10.5 8.0 0.6 7.5 7.5
4.4 10.5 8.0 0.6 7.5 7.5
4.7 10.5 8.4 0.6 7.5 7.5
5.1 10.5 8.7 0.6 7.5 7.5
4.5 10.5 11.3 0.6 7.5 7.5
4.8 10.5 11.6 0.6 7.5 7.5
5.2 13.5 10.4 0.6 10.0 10.0
5.6 13.5 10.8 0.6 10.0 10.0
6.0 13.5 11.2 0.6 10.0 10.0
6.5 13.5 11.7 0.6 10.0 10.0
5.4 18.5 12.2 0.6 15.0 15.0
5.9 18.5 12.7 0.6 15.0 15.0
6.4 18.5 13.2 0.6 15.0 15.0
7.1 18.5 13.8 0.6 15.0 15.0
6.2 26.0 13.0 0.8 22.5 22.5
6.8 26.0 13.6 0.8 22.5 22.5
6.9 26.0 15.2 0.8 22.5 22.5
7.5 26.0 15.9 0.8 22.5 22.5
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
10.0 25.0 18.3 0.8 22.5 22.5
3.9
10.9 25.0 19.2 0.8 22.5 22.5
4.7
12.0 25.0 20.3 0.8 22.5 22.5
5.6
11.5 30.0 20.1 0.8 27.5 27.5
6.8
12.7 30.0 21.3 0.8 27.5 27.5
8.2
14.1 30.0 22.6 0.8 27.5 27.5
10.0
F : lead pitch for cut / formed lead wires
15.6 30.0 24.2 0.8 27.5 27.5
