IXGP28N60A3M
Symbol Test Conditions
(TJ = 25°C Unless Otherwise Specified)
Characteristic Values
OVERMOLDED TO-220
(IXGP...M)
Min.
Typ.
Max.
gfs
IC = 24A, VCE = 10V, Note 1
17
30
S
Cies
Coes
Cres
1790
100
26
pF
pF
pF
VCE = 25V, VGE = 0V, f = 1MHz
Qg(on)
Qge
Qgc
66
13
24
nC
nC
nC
1
2
3
IC = 24A, VGE = 15V, VCE = 0.5 • VCES
td(on)
tri
Eon
td(off)
tfi
18
26
ns
ns
Inductive load, TJ = 25°C
IC = 24A, VGE = 15V
0.7
300
260
2.4
mJ
ns
VCE = 480V, RG = 10
ns
Note 2
Eof
mJ
f
Terminals: 1 - Gate
2 - Collector
td(on)
tri
20
26
ns
ns
Inductive load, TJ = 125°C
3 - Emitter
IC = 24A, VGE = 15V
Eon
td(off)
tfi
1.4
470
400
4.2
mJ
ns
VCE = 480V, RG = 10
ns
Note 2
Eoff
mJ
RthJC
RthCS
1.94 °C/W
°C/W
0.50
Notes:
1. Pulse test, t 300μs, duty cycle, d 2%.
2. Switching times & energy losses may increase for higher VCE(clamp), TJ or RG.
