o Part Numbering
Ceramic Trimmer Capacitors
(Part Number)
TZ Y2
R
3
200
4
A
5
C01 R00
1
2
6
7
1Product ID
5Terminal Shape
Product ID
Code
A
Terminal Shape
Top Adjustment: TZR1, TZY2, TZC3, TZW4, TZB4
Top Adjustment: TZB4
TZ
Trimmer Capacitors
B
2Series/Terminal
Please refer to dimensions for terminal details.
Code
B4
Series/Terminal
4mm Size SMD Type
4mm Size SMD Type
3mm Size SMD Type
2mm Size SMD Type
1mm Size SMD Type
6Individual Specifications
W4
C3
Code
001
C01
A01
A10
B10
Individual Specifications
TZR1, TZW4 Standard Type
TZY2 Standard Type
Y2
R1
TZC3 Standard Type
TZB4 No-cover Film Standard Type
TZB4 with Cover Film Standard Type
3Temperature Characteristics
Code
Temperature Characteristics
NP0ppm/°C
7Packaging
Z
R
K
P
N750ppm/°C
Code
B00
Packaging
Bulk
N1000ppm/°C
N1200ppm/°C
R00
Reel (Taping ø180mm)
Reel (Taping ø330mm)
Please refer to ratings for tolerance of temperature characteristics.
R01*
* TZB4 only.
4Maximum Capacitance
Expressed by three-digit alphanumerics. The unit is pico-farad
(pF). The first and second figures are significant digits, and the
third figure expresses the number of zeros that follow the two
numbers. If there is a decimal point, it is expressed by the capital
letter "R". In this case, all figures are significant digits.
