JV
5.-(1) Ambient temperature characteristics
(Standard 10 A type, 1 Form A)
Contact current: 10 A
5.-(2) Ambient temperature characteristics
(High capacity 15 A type, 1 Form A)
Contact current: 0 A, 10 A, 13 A, 15 A
5.-(3) Ambient temperature characteristics
(1 Form C type)
Contact current: 10 A
Allowable ambient temperatures
against % coil voltages
Allowable ambient temperatures
against % coil voltage
300
300
(max. inside the coil temperature
(max. inside the coil temperature
set as 115°C 239°F)
set as 115°C 239°F)
200
Allowable ambient
temperature against
200
200
% coil voltages
Pick-up voltage with
a hot-start condition
of 100%V on the coil
(max. inside the coil
Pick-up voltage
temperature set as
15 A
13 A
115°C 239°F)
100
Pick-up voltage with
a hot-start condition
of 100%V on the coil
100
100
Pick-up voltage
10 A Pick-up voltage
0 A
0
20
40
60 80 100 120
0
20
40
60
80
0
20
40
60 80 100 120
Ambient temperature, °C
Ambient temperature, °C
Ambient temperature, °C
5.-(4) Ambient temperature characteristics
(High sensitivity type)
Contact current: 10 A
300
High sensitivity
100 mW type
Standard
200 mW type
Allowable ambient
temperature
200
100
against % coil
voltages (max.
inside the coil temperature
set as 115°C 239°F)
0
0
20
40
60
80
100
120
Temperature rise, °C
Types dedicated to a wider variety of automotive applications are available, upon receipt of order, with the following specifications:
SPECIFICATIONS
Contact
Characteristics
Arrangement
1 Form C
100 mΩ
Max. operating speed
Initial insulation resistance
20 cpm
Min. 100 MΩ (at 500 V DC)
750 Vrms for 1 min.
1,500 Vrms for 1 min.
Approx. 5 ms
Initial contact resistance, max.
(By voltage drop 6 V DC 1 A)
Between open contacts
Initial break
Contact material
Silver alloy
down voltage
Between contacts and coil
10 A 125 V AC
6A 30 V DC
Operate time (at nominal voltage)
Release time (at nominal voltage)
Nominal switching capacity
Approx. 4 ms
Rating
(resistive
load)
1,250 V AC
180 W
Max. switching power
Temperature rise (max.)
(at nominal voltage)(at 50°C)
65°C with nominal coil voltage and at
maximum allowable contact current
Max. switching voltage
Max. switching current
Mechanical (at 300 cpm)
125 V (AC) 30 V (DC)
10 A (AC) 6 A (DC)
5×106
Functional
Shock resistance
Min. 196 m/s2 {20 G}
Min. 980 m/s2 {100 G}
Destructive
Expected
life (min.
ope.)
10 to 55 Hz at double amplitude of
1.6 mm
Functional
Vibration resistance
Destructive
Electrical
(DC 12 V motor, 6 A steady current,
20 A lock current)(at rated load)
4×104
10 to 55 Hz at double amplitude of
2 mm
Coil
Conditions for operation,
transport and storage
(Not freezing and condens-
ing at low temperature)
Ambient
temp.
–40°C to +70°C
–40°F to +158°F
Nominal voltage, V DC
5, 6, 9, 12, 18, 24
450 mW
Nominal operating power
Pick-up voltage, V DC (max.)
Drop-out voltage; V DC (min.)
Max. allowable voltage
Humidity
5 to 85%R.H.
70% of nominal voltage
5% of nominal voltage
150% of nominal voltage
Unit weight
Approx. 8 g .282 oz
For Cautions for Use, see Relay Technical Information (Page 11 to 39).
