P R O D UC T D ATA S H E E T
CRYSTAL CONTROLLED OSCILLATORS
Notes:
1) Frequency vs. temperature stability, Vc = 1.65V.
2) Inclusive of calibration, operating temperature range, supply voltage change, load
change, shock and vibration, 10 years aging, Vc = 1.65V.
3) After one minute of operation at 25°C, the unit will be within +/-0.5ppm of its final
stabilized frequency. The final stabilized frequency is that which is measured after 30
minutes of continuous operation at a stable 25°C ambient temperature.
4) Referenced to Fo @ 25°C, Positive Transfer Characteristic
5) Oscillator output is enabled with no connection on pin 3.
ENVIRONMENTAL CHARACTERISTICS
Temperature Cycle: Per MIL-STD-883, Method 1010, Condition B. -55°C to 125°C, 20 cycles,10 minute dwell, 1minute
transition.
Gross Leak Test: Per MIL-STD-202, Method 112, Condition D. No bubbles in flourinert (FC-43) at 125°C ±5°C for 20
seconds.
SOLDERING
Pin Solderability: Per MIL-STD-883, Method 200. 8 hour steam age prior to 254°C ±5°C Solder pot dip, 95% Coverage.
Resistance to Solder Heat: Per MIL-STD-202, Method 210, Condition C. Wave: Topside board-mount product, 260°C
±5°C for 20 Seconds.
MECHANICAL CHARACTERISTICS
Vibration: Per MIL-STD-202, Method 204, Condition A. 10G’s peak, 10Hz to 500Hz, 15minute cycles 12 times each
perpendicular axis.
Shock: Per MIL-STD-202, Method 213, Condition D. 500G’s, 1ms, halfsine, 3 shocks per direction.
Moisture Resistance: Per MIL-STD-202, Method 106. 95% RH @ 65°C, 10 cycles 10°C to 65°C.
.430 MAX
(10.922mm)
PIN
1
3
7
8
12
14
CONNECTION
CONTROL VOLTAGE
ENABLE / DISABLE
GROUND (CASE)
OUTPUT
OVEN MONITOR
+ SUPPLY
.200
(5.08mm)
OVEN
MONITOR
REF.
SUPPLY
14 12
8
3.3Vdc
3.0Vdc
3
1
7
20K
POT
ENABLE/
DISABLE
CONTROL
VOLTAGE
Specifications subject to change without notice.
06/17/05
Cx085
00
2
2
