IXGP 30N60B2
Symbol
gfs
Test Conditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
IC = 24 A; VCE = 10 V,
18
26
S
Pulse test, t ≤ 300 µs, duty cycle ≤ 2 %
Cies
Coes
Cres
1500
115
40
pF
pF
pF
VCE = 25 V, VGE = 0 V, f = 1 MHz
IC = 24 A, VGE = 15 V, VCE = 300 V
Inductive load, TJ = 25°C
Qg
Qge
Qgc
66
9
22
nC
nC
nC
td(on)
tri
td(off)
tfi
13
15
110
82
ns
ns
200 ns
150 ns
0.6 mJ
Pins: 1 - Gate
2 - Drain
4 - Drain
3 - Source
IC = 24 A, VGE = 15 V
VCE = 400 V, RG = 5 Ω
Eoff
0.32
td(on)
tri
Eon
td(off)
tfi
13
17
0.22
200
150
0.9
ns
ns
mJ
ns
ns
mJ
Inductive load, TJ = 125°C
IC = 24 A, VGE = 15 V
VCE = 400 V, RG = 5 Ω
Eoff
RthJC
RthCH
0.65 K/W
K/W
0.25
