IXFH22N60X2A
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max
gfs
VDS = 10V, ID = 0.5 • ID25, Note 1
Gate Input Resistance
8
14
S
RGi
1.0
Ciss
Coss
Crss
2190
1450
1.3
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
Effective Output Capacitance
Co(er)
Co(tr)
92
pF
pF
Energy related
Time related
VGS = 0V
VDS = 0.8 • VDSS
330
td(on)
tr
td(off)
tf
30
37
42
18
ns
ns
ns
ns
Resistive Switching Times
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
V
RG = 10 (External)
Qg(on)
Qgs
37
12
14
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
RthJC
RthCS
0.32 C/W
C/W
0.21
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max
IS
VGS = 0V
22
A
A
ISM
VSD
Repetitive, pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
88
1.4
V
trr
QRM
IRM
145
890
12
ns
IF = 11A, -di/dt = 100A/μs
nC
VR = 100V
A
Note 1. Pulse test, t 300s, duty cycle, d 2%.
ADVANCE TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are
derived from a subjective evaluation of the design, based upon prior knowledge and experi-
ence, and constitute a "considered reflection" of the anticipated result. IXYS reserves the right
to change limits, test conditions, and dimensions without notice.
